- Page 1 INSTRUCTIONS FOR INSTALLATION AND USE AUTOMATION AND ELECTROMECHANICAL DRIVERS DUEVILLE FOR LINEAR SLIDING DOORS WITH ONE OR TWO PANELS original instructions COD. 0P5541 VER 0.0 REV 08.19...
-
Page 3: Table Of Contents
5.3- First card Start-up..........................pag. 41 5.4- Reset phase: Learning..........................pag. 42 5.5- Restart in case of power failure: ZERO(NEAR)..................pag. 42 5.6- Programming Parameters on the Dueville ..................pag. 43 5.7- List of Errors and Warning........................pag. 44 5.8- Self restore management of Errors C-D-E-K-N-P-Q ................. -
Page 4: 1- General Information
This manual was written by TOPP srl, which holds the copyright. No part of this manual may be reproduced or published &... -
Page 5: User
It should be applied by the installation technician in a clearly visible position on the outside of the automation unit. PROPER USE The DUEVILLE automation mechanism was designed and produced exclusively to operate (open and close) linear sliding doors in residential, public and industrial buildings. -
Page 6: Technical Data
TECHNICAL DATA Tab. 1 lists the technical data that characterize the DUEVILLE automation. Tab. 1 MODEL DUEVILLE 230V ~ 50Hz POWER SUPPLY PERIPHERAL POWER OUTPUT 500mA max 1,31A* TOTAL ABSORPTION TOTAL POWER ABSORBED 286W* TYPE OF USE Continuous Adjustable 10 ÷ 80 cm/s OPENING/CLOSING SPEED Adjustable 1 ÷... -
Page 7: Description Of Components
DESCRIPTION OF COMPONENTS INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE... -
Page 8: Models
1 LEFT DOOR PANEL VPA = net doorway width VL = gross opening LT/LC = lautomation length/ casing length BP = rail + runner on the floor VPA* PC = electric wire raceway LT/LC DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE... -
Page 9: Sliding Doors With One Panel
In some countries the laws forbid this type of assembly as there is a possible risk of getting the fingers caught. Fig. 5a Fixed door panel Sliding door panel Automation Fig. 5b Fixed door panel Sliding door panel Tubular jamb Automation Fig. Fixed door panel Sliding door panel Wall end Automation Overlap INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE... -
Page 10: Installation Contents
Before installing the automation, verify that the structure to be automated is stable, sturdy and able to withstand the weight of the automation and, if necessary, take steps to ensure that it is. Topp spa is not liable for failure to comply with the rules of good workmanship in the construction of the door panels to motorize, or for any distortions that may develop with use of the device. - Page 11 PRE-INSTALLATION PREPARATION Remove the central cover (2 no. bolts). Remove the casing covers (follow the numerical order). Remove the ceiling lamp (unscrew 10 no. screws and disconnect 3 no. connectors). INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 12 M8 x 16 16 X 8 X 1.6 M6 x 8 M6 x 12 12 X 6 X 1.6 M4 x 10 Remove electronic board assembly (unscrew 2 no. bolts). Remove the automation from the packaging. DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 13 FITTING WALL BRACKETS 168.5 Wall bracket 40±9 30±9 Fit 2 no. wall brackets (use 2 no. suitable Ø6 mm screws, not supplied). Provide cable outlet on wall (3 no. possible cable entry points on automation). INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 14 Carefully clean drilling residues from the sliding area. Drill the wall in line with the holes on the automation and fix it with suitable Ø6 mm screws (not supplied), using all the available holes. DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 15 RUNNING THE CABLES CABLE ENTRY Cable clamp plate Raceway cover seal Cable raceway (supply cable and sensor cable): maintain the indicated lengths. Fit the raceway cover seal and the cable clamp plate (2 no. screws). INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 16 Fit the runners onto the door panel, lower the anti-derailment wheel, hook the glide runners onto the crossbar, return the anti-derailment wheel to the higher position. Adjust the height of the glide runner. Adjust both the door panel stops. DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 17 Bolt M6x12 Bolt M6x12 It should be easy to pinch together If it is difficult, adjust. with thumb and finger. Fit the door panel drive brackets and the transmission belt; Check the belt tension. INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 18 16. ATTENTION: before moving on to the next step, carry out the electrical wiring (chapter 4) and the operational test of the entire automation, mounting the internal sensor provisionally. Fit the ceiling lamp (10 no. screws and connect 3 no. connectors). DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 19 FITTING COVERS AND INTERNAL SENSOR Bolt M4x10 Refit the casing covers (follow the numerical order). Fit the internal sensor to the central cover (2 no. screws). Connect the internal sensor and fix the central cover (2 no. screws). INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
-
Page 20: General Recommendations
6. Emergency battery system input 7. Gearmotor input 8. Door block 1 input 9. Door block 2 input don’t touch (pharmacy) 10. Transformer input 11. Lighted display 12. Encoder cord input 13. DOWN key 14. ENTER key DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE... -
Page 21: Pre-Wired Electrical Connections
7. GND SAFETY 1 22. EXTERNAL 31. GND 8. 24V* 15. GND RADAR 32. 24V 16. 24V 23. GND 24. 24V Ÿ Ÿ SIGNAL A Ÿ GND (shield) Ÿ SIGNAL B Ÿ * Unregolated INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE... -
Page 22: Electrical Wiring Diagram (Flow Chart)
ELECTRICAL WIRING DIAGRAM (FLOW CHART) Fig. 10 DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE... -
Page 23: Connection Of Detection Sensors
NO ACT. white white COM. ACT. grey grey grey grey +24V green/black green/black N.C. SAF white/black white/black COM. SAF yellow yellow NO ACT. white white COM. ACT. grey grey grey grey +24V INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE... - Page 24 RX1 - TX1 = First beam RX2 - TX2 = Second beam ACTIVATION yellow yellow N.O. white white grey grey grey grey +24V ACTIVATION yellow yellow N.O. white white grey grey grey grey +24V DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 25 RX2 - TX2 = Second beam yellow yellow N.O. ACT. white white grey grey grey grey +24V green/black green/black N.C. SEC. white/black white/black yellow yellow N.O. ACT. white white grey grey grey grey +24V INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 26 N.C. white white white white +24V yellow yellow N.O. ACT. white white grey grey grey grey +24V green/black green/black N.C. SEC. white/black white/black yellow yellow N.O. ACT. white white grey grey grey grey +24V DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 27 Fig. Digital program switch menu: ¬ PARAMETERS>OTHER PARAMETERS> SAFETY SENSOR LOGIC: N.C. WITHOUT TEST Or program parameter 9 with the dot IS2 EXTERNAL ACTIVATION/SAFETY IS2 INTERNAL ACTIVATION/SAFETY SENSOR SENSOR IS5 LATERAL S. N.C. N.C. INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 28 RX1 - TX1 = First beam RX2 - TX2 = Second beam ACTIVATION yellow yellow N.O. white white grey grey grey grey +24V N.C. ACTIVATION yellow yellow N.O. white white grey grey grey grey +24V DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 29 NO ACT. white white COM. ACT. grey grey grey grey +24V green/black green/black N.C.SEC white/black white/black COM.SEC yellow yellow NO ACT. white white COM. ACT. grey grey grey grey +24V N.C. N.C. INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 30 N.C. N.C. yellow yellow N.O. ACT. white white grey grey grey grey +24V green/black green/black N.C. SEC. white/black white/black yellow yellow N.O. ACT. white white grey grey grey grey +24V DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 31 RX1 - TX1 = First beam RX2 - TX2 = Second beam ACTIVATION yellow yellow N.O. white white N.C. grey grey grey grey +24V ACTIVATION N.C. yellow yellow N.O. white white grey grey grey grey +24V INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 32 ACTIVATION green green N.O. white white brown brown +24V TST- black black TEST TST+ N.C. pink pink SECURITY blue blue yellow yellow ACTIVATION green green N.O. white white brown brown +24V DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 33 SECURITY blue blue green green ACTIVATION white white N.O. black black +24V TST- brown brown TEST grey grey TST+ N.C. yellow yellow SECURITY blue blue green green ACTIVATION white white N.O. black black +24V INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 34 +24V brown brown TST- black black TEST TST+ N.C. pink pink SECURITY blue blue yellow yellow ACTIVATION green green N.O. white white brown brown +24V 11 10 16 15 13 IS5 LATERALE S. DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 35 +24V brown brown TST- TEST grey grey TST+ N.C. yellow yellow SECURUTY blue blue green green ACTIVATION white white N.O. black black +24V 16 15 13 11 10 Is5 HOTRON LATERAL S. INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 36 Digital program switch menu: ¬ PARAMETERS>OTHER PARAMETERS> SAFETY SENSOR LOGIC: N.C. WITH TEST Or program parameter 9 without the ELECTRICAL WIRING DIAGRAM FOR USING OPTEX ACTIVATION/SAFETY SENSOR MONITORED IS5 LATERAL S. 1 IS5 LATERAL S. 2 DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 37 P A R A M E T E R S > S A F E T Y SENSOR LOGIC: N.C. WITH TEST Or program parameter 9 without the ELECTRICAL WIRING DIAGRAM FOR USING HOTRON ACTIVATION/SAFETY SENSOR MONITORED Is5 HOTRON Is5 HOTRON LATERAL S. 1 LATERAL S. 2 INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
-
Page 38: Connection Of Program Switch To Ms1 Knob
Cable ‘shielding’ should only be used for cable lengths in excess of 20 meters. For shorter cables cut the wire at the level of the sheath 1 2 3 4 5 DS2 DIGITAL SELECTOR CIRCUIT DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE... -
Page 39: Connection Of Key Device
Digital program switch menu: ¬ PARAMETERS> OTHER PARAMETERS> SAFETY SENSOR LOGIC:N.C. WITH TEST Or program parameter 9 without the dot 11 12 RX1 - TX1 = First beam RX2 - TX2 = Second beam INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE... -
Page 40: Connetion Of Door Block And Pharmacy Function
RX1 - TX1 = First beam RX2 - TX2 = Second beam 4.10 CONNETION OF DOOR BLOCK AND PHARMACY FUNCTION Door block with manual Door block with manual release incorporated 1 release incorporated 2 pharmacy function DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE... -
Page 41: 5- Use And Operation
“default battery operation mode”: the “continuous operation mode” and will continue to operate as set as in the selector program. The "battery operation mode" can be changed in other modes, using the Topp DS2 digital program switch. Emergency opening or closing can be set. In the case has been selected a different mode operation than the standard one, the automation will resume to function as the program set by the selector after restoring the 230V mains. -
Page 42: Reset Phase: Learning
MS1, automation will not perform any reset (near) as long as this mode will not be changed or if the request will be 'opening to boost key or emergency opening / fire. Once changed how automation will perform the reset (near) as shown above. DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE... -
Page 43: Programming Parameters On The Dueville
1. Press the “DOWN” key and hold for 5 seconds. The sequence of characters “Radio” appears on the 7-segment display. 2. If you have the Topp remote control TS2 press the smooth side of the first key (open function). If the Topp TS1 4-channel remote control is available, press the second key (Close Function). -
Page 44: List Of Errors And Warning
Lateral sensor 1 malfunction. Lateral sensor 2 malfunction. Antipanic sensor malfunction. Obstacle not removed. Check for obstacles or friction. Motor poles inverted. Reverse the cables. Doors free. Bus voltage low. Bus voltage high. Motor bridge voltage high. DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE... -
Page 45: Self Restore Management Of Errors C-D-E-K-N-P-Q
During the slow opening in the preceding paragraph, the occupation of the side sensors causes a slow reclosing Ÿ During the movement, the contemporary employment of at least one safety sensor side and a sensor safety Ÿ compartment passage controls the stop of the door. INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE... -
Page 46: Self Restore Management Of Errors F-G-H-I-J
If the doors are smashed until the automation mode is closed and subsequently repositioned does not run no movement reset. For proper operation of the automated system with panic mounted photocells TOPP F3. 5.11 SELF RESTORE MANAGEMENT AFTER OPENING FIRE OR AN OPENING OF EMERGENCY The opening of emergency or fire causes the immediate opening of the automation, but in case where the sensors side are... -
Page 47: Digital Program Switch
(near). This allows you to decrease the value of the function selected and return to the previous menu This allows you to scroll the menu downward. Hold for 4 sec to enter the menu INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE... -
Page 48: Maintenance
In order for the automation unit to operate correctly, should be carried out periodical maintenance on the same. This maintenance activity may be carried out either by TOPP, in accordance with a specific agreement made with the user, or by the installation technician or by other competent and qualified technical personnel in possession of all legal requirements. -
Page 49: Demolition
Check the radar contacts, electromechanical block, switch not open contacts The door does not function and the display of Check the malfunction signal consulting the list of messages and the control circuit shows symbols or letters alarms INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE... -
Page 50: 7- Ec Declaration Of Incorporation Of Partly Completed Machinery
Via Galvani, 59 36066 Sandrigo (VI) Italia herewith declares that the person authorised to compile the technical file is Name: Plaza Trinidad- Topp S.r.l. Address: via Galvani,59 36066 Sandrigo (VI) and that to the partly completed machinery ELECTROMECHANICAL AUTOMATION FOR LINEAR SLIDING... -
Page 51: 8- Receiver And Remote Control Instructions
FR - Dans l’optique d’un développement continu de ses produits, le constructeur se réserve le droit d’apporter sans préavis des modifications aux données techniques et aux prestations. DE - Im Zuge einer kontinuierlichen Weiterentwicklung der Produkte behält sich der Hersteller das Recht vor technische Daten und Funktionen ohne vorherige Ankündigung zu ändern. INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE... - Page 52 DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 53 INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 54 DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 55 INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 56 DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 57 INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 58 DUEVILLE INSTRUCTIONS FOR INSTALLATION AND USE...
- Page 59 INSTRUCTIONS FOR INSTALLATION AND USE DUEVILLE...
- Page 60 TOPP S.r.l. Società a Socio Unico soggetta a direzione e coordinamento di 2 Plus 3 Holding S.p.a. Via Galvani, 59 - 36066 Sandrigo (VI) - Italia Tel. +39 0444 656700 - Fax +39 0444 656701 Info@topp.it - www.topp.it...
