TECHNICAL DATA

Materials :
 AISI 316 Body (PVC Body optional)
 Special Glass Optics
 NBR and Sylicon O-Rings
Thread: 3/4" BSP
Measuring ranges: 0,00 to 20,00 mg/L 0-200%
Measuring method: Optical measure by
luminescence
Accuracy: +/-0,1mg/L or +/-1 %
Response: 90% of the value in less than 60
seconds
Maximum refreshing time: < 1 second
WorkingTemperature: -10÷60 ° C
Max Working Pressure: 5 bar
Maximum absorption: 2W
Mechanical Protection: IP68 Sensor+cable
Cable: 10m integral
Power Supply: 12...24Vdc
Signal interface: RS-485 Modbus RTU Protocol
Water move: No necessary move
Compensation of temperature: Via internal NTC
Luminophore diameter: 10mm
Connector IP67: yes

Order codes

9700830067
9700831067
9700832067
9700833067
9400410134
9400410135
S423/C/OPT Optical oxygen probe – Data Sheet
S423/C/OPT Optical Oxygen and Temperature Probe
S423/C/OPT PVC Optical Oxygen and Temperature Probe
S423/C/OPT 4-20mA Optical Oxygen and Temperature Probe
S423/C/OPT 4-20mA PVC Optical Oxygen and Temperature Probe
Luminescent membrane with AISI316 support for S423/C/OPT
Luminescent membrane with PVC support for S423/C/OPT
S 4 2 3 / C / O P
S 4 2 3 / C / O P
O x y g e n
O x y g e n

DIMENSIONS

CHEMITEC s.r.l.
Via Isaac Newton 28 - 50018 Scandicci (FI)
Tel. +39 055 7576801 fax +39 055 756697
Web site: www.chemitec.it
E-mail: sales@chemitec.it
T O p t i c a l
T O p t i c a l
P r o b e
P r o b e
D D a a t t a a S S h h e e e e t t
