*Discharge end time set (saves in setup)
*Set name on label (saves only 1 name)
*Type of data output on parallel port (saves in setup)
*Milliamp hour and Milliwatt hour and relative internal resistance display (One screen for each of the 4 cells)
*Sound horn on/off select (saves in setup)
*Store 1 of 3 setups
*Recall 1 of 3 setups

ALL CELL STATUS SCREEN

This screen shows the cell number along with the individual status of each cell. The different statuses are ready (READY), off (OFF), charging (CHRG),
repeaking (REPEK), discharging (DISCHG), delay (DELAY) and done (DONE). This screen is shown during idle and running.

SUPPLY VOLTS AND ACTUAL CHARGE AMPS SCREEN

This screen shows the supply volts at the TURBOMATCHER 4. The voltage at the TURBOMATCHER 4 will be lower than at the supply due to the voltage
drop across the power cord while charging. Also shown on the screen are the actual charge amps during charging. This type of screen is shown during idle
and running.

INDIVIDUAL CELL DATA

Each cell has its own data screen. On each screen is shown on the top line the charge time in seconds, present cell voltage, discharge time in seconds. On
the bottom line is shown the cell status, cell number and discharge average voltage. This type of screen is shown during idle and running.

CHARGE AMPS SET SCREEN

This screen shows the present charge amps setting. Positioning the cursor under the desired digit with the LEFT ARROW or the RIGHT ARROW push but-
ton and then depressing the OFF/UP ARROW push button or DOWN ARROW push button until the desired value is reached will set each digit. Default set-
ting is 4.00 amps. This number is settable in each of the three available setups.
