BOMATCHER 4 may be run off one supply providing that the power supply can furnish the required charge amps of all the TURBOMATCHER 4s. ie: two TUR-
BOMATCHER 4s charging at a maximum of 3 amps each would require a 6-amp supply.

LOADING THE CELLS

The cells must be positioned with the positive terminal towards the back of the case. The cells are numbered from left to right. After the cells are loaded,
rotate the cells one quarter to one half turn to clean the contact area on the battery and on the battery holder.

GENERAL OPERATION

There are 8 push buttons that control the TURBOMATCHER 4 and set the operating parameters. The left arrow push button advances the cursor from
one screen to the next and from one settable digit to the next from right to left. The right arrow push button moves the cursor from the present screen
to the previous one and from the present digit to the previous one from left to right. The CYCLE push button will initiate the charge/repeak/discharge cycle.
The OFF/UP ARROW push button will force a stop to the charge/repeak/discharge cycle. The OFF/UP ARROW push button will also increment any settable
digit the cursor is positioned under. The DOWN ARROW push button will decrement any settable digit the cursor is positioned under. To set any parame-
ter, push the LEFT or RIGHT ARROW push button until the desired screen is reached and the cursor is positioned under the desired digit to be set. Push
the OFF/UP ARROW push button or DOWN ARROW push button until the desired value is reached. The operating parameters selected can be saved in one
of three power down memory locations (setups). The last used setup will automatically be recalled upon power up. To start a charge/peak/discharge cycle,
simply push the CYCLE push button at any time. To start a peak/discharge only cycle, depress the REPK DISCHRG push button. To start a discharge only
cycle, depress the DISCHG push button. Upon completion of any cycle, the beeper will sound if selected to. Also, the label or graph or computer data may
automatically be outputted to the parallel port if selected. Pushing the LEFT or RIGHT arrow buttons will stop the beeper. The TURBOMATCHER 4 has 15
basic screens while it is in the idle mode and 3 of the 15 basic screens are available while it is in the run mode. The basic screens are as follows:
*All cell status
*Supply volts and actual charge amps
*Individual cell data (One screen for each of the 4 cells)
*Charge amps set (saves in setup)
*Discharge amps set (saves in setup)
*Discharge end volts set (saves in setup)
*Peak detect volts set (saves in setup)
*Flex level and on/off set (saves in setup)
