- Page 1 MANUEL D'UTILISATION / USER GUIDE BEDIENUNGSANLEITUNG Helite www.helite.com bsafe@helite.com Airbag certifié / Certified airbag Distribué par Helite 1, rue de la petite fin Zertifizierter Airbag 21121 Fontaine-Lès-Dijon...
-
Page 2: Table Of Contents
USER GUIDE THANK YOU FOR YOUR PURCHASE To get the most out of your B’Safe airbag, please read this manual carefully. General information ...............30 First use ....................32 Safety precautions ................. 35 Technical description ..............35 Daily use ....................39 Reuse B’Safe after an inflation .......... -
Page 3: General Information
When an accident or a fall is detected, the airbag inflates automatically to protect the thorax, neck and spin and ensures an optimal protection before impact. ATTENTION B'Safe is not adapted for the following uses: mountain bike, bicycle acrobatics, BMX, scooter, motorcycle, running, segways, electric unicycle and self-balancing board. - Page 4 User Guide THE B’SAFE AIRBAG The B’Safe package contains: an airbag vest, a saddle sensor, a CO2 cartridge, a USB cable and a little magnet. It contains the airbag, a CDU (Crash Detection Unit) B’Safe vest: sensor which analyzes the situation in real time (cyclist’s motion, position and speed) and detects accidents.
-
Page 5: First Use
User Guide First use STEP 1: PAIR THE SADDLE SENSOR WITH THE VEST Before using your B’Safe vest, it is necessary to pair (which means associate) the vest with the saddle sensor. To do so, you need the vest, the saddle sensor and the magnet. - Page 6 User Guide GOOD TO KNOW It is possible to pair several “saddle sensors“ with one vest (5 maximum). For example, if you have several bicycles, the pairing process has to be done for each bike. It is possible to pair as many vests as you like with one saddle sensor. ...
- Page 7 User Guide 3. Place the sensor on the bicycle Make sure to thoroughly clean your bicycle frame before installing the sensor. • Place the sensor on the bicycle frame on the seatpost or on the seat tube. Make sure that nothing will impact the sensor during the installation (bike lock, water bottle, etc.).
-
Page 8: Safety Precautions
PRECAUTIONS Failure to follow the instructions could lead to malfunction or reduce the effectiveness of the airbag system. Once used, the CO2 cartridge must be replaced with a new Helite cartridge of the same capacity (50 cc,60 cc, or 100 cc) ... - Page 9 The vest was designed to ensure an optimal protection for 3 vital areas of the body: the thorax, the neck and the back. The airbags are made and tested in Helite‘s workshop in Dijon. They are made of strong polyamide fabric which is highly resistant and very effective to absorb shocks.
- Page 10 The CO2 cartridges are for single use only and must be replaced after each inflation. - The CO2 cartridge must be a Helite branded cartridge ( GG 50cc / GG 60cc / GG 100 cc). Do not use any other cartridge to replace the used one.
- Page 11 User Guide SIZE CHART & COLORS The vest exists in two colors: Black and Yellow Hi-Vis (high visibility). It is available in 4 different sizes: SIZE IN INCHES A - Chest line 34-37 37-40 40-43 43-46 At the widest level B - Waist line 28-31 31-35...
-
Page 12: Daily Use
User Guide Daily use THE VEST The vest is 100% autonomous. Once it switches ON, the electronic system works automatically and analyzes the movements in real time. SWITCH ON / OFF THE VEST The vest can be switched ON / OFF by pressing quickly 3 times the button We recommand to switch OFF the vest when you are not using your bike. - Page 13 To recharge B’Safe, you must use the Helite USB cable included with B’Safe. Only the cable is included, you have to plug it afterwards into a standard USB charger ( 5 Volt USB port on your computer or mobile phone charger).
- Page 14 User Guide VEST LED DESCRIPTION To know if the system is working properly, here are the 4 LED colors used and their different significations: Green LED: System operational Orange LED: Low battery Blue LED: Pairing Red LED: Problem No LED: Garment off or in sleep mode More info on page 48 about the operation of the LEDs and BEEPS.
- Page 15 However, even if it is legally allowed, it is possible that the security service or the airline will refuse you to board the aircraft with the gas cartridge. We advise you to print the IATA regulation (available on helite.com «FAQ») and to show it during the control if you are asked for further explanation.
- Page 16 User Guide SDU SADDLE SENSOR Once installed and correctly paired (see page 32), the saddle sensor is totally autonomous (about 5 years without charging). SADDLE SENSOR WORKING STATE However, we recommend to check from time to time (once a month) that the saddle sensor is working properly.
-
Page 17: Reuse B'safe After An Inflation
User Guide Reuse B’Safe after an inflation After an inflation, it is possible to reuse the vest. There are only a few steps to follow to reactivate your airbag system. It is really easy and can be done by yourself. Take off the vest. - Page 18 User Guide Install the new cartridge. Do not damage the cable while screwing the cartridge. Only connect the cartridge once it is entirely screwed (see example on the scheme below). Slide the Connect the Screw the cartridge cartridge. cartridge. cable in the cylinder.
- Page 19 Before reusing the airbag you must check the following points: the cartridge is replaced by a new Helite cartridge of the same capacity. the airbag is deflated. the new cartridge is connected with the vest.
-
Page 20: Maintenance
We recycle the empty CO2 cartridges. Put them aside and send them to the following address or return them to one of our dealers. VEST USER HELITE - 1 rue de la petite fin. B’SAFE GUIDE 21121 Fontaine Lès Dijon, FRANCE... -
Page 21: Operation & Malfunction
Red LED / 1 Beep every second (while the cartridge is not connected) If you notice any other malfunctions, please contact your dealer or our after sales service via email sav@helite.com or by phone +33 3 80 35 48 26. -
Page 22: Warranty & After Sales Service
• The system does not switch ON although the vest is charged and activated. • In the event of deterioration or significant fading of the materials. After sales service: Contact us via mail: sav@helite.com Or by phone: +33 3 80 35 48 26... -
Page 23: Disclaimer
• Please note that no body protector can prevent death or serious injuries in certain accidents. • Helite and its distributors will be held in no way responsible for any bodily injury or death, and/or property damage that may occur while using any Helite airbag garment. - Page 25 VEST USER B’SAFE GUIDE www.helite.com bsafe@helite.com @HeliteOfficial...
