- Page 1 HUNTER 600—800 (3 point Hitch) MODEL USERS MANUAL, SAFETY INSTRUCTIONS & PLANTING TIPS Product PLOTMASTER™ Systems, LLC. Wrightsville, GA 31096 1-478-864-9108 or 1-888-629-4263...
- Page 2 Page 19…….Description of Plow Point Uses Page 20…….Hunter 600 Specifications Page 21…….Hunter 600 Seed Planting Chart Page 22…….Hunter 800 Specifications Page 23…….Hunter 800 Seed planting Chart Page 24…….Seasonal Seed information on planting times Page 25…….Quick Guide on How to Calibrate your Seeder Page 26…….Contact Information...
- Page 3 48” wide, The Hunter 600 will break and plow a maxi- mum of 72” wide and the Hunter 800 will break and plow a maximum of 96” wide. Q. How do you ship the PLOTMASTER™...
- Page 4 READ OPERATING INSTRUCTIONS CAREFULLY BEFORE USE!!! PLOTMASTER™ DO NOT OPERATE OVER 10 MPH. • DO NOT SIT, STAND OR RIDE ON THE • PLOTMASTER™ WHILE IN USE MAXIMUM CAPACITY OF HUNTER SERIES SEEDER • H-600 SEEDER 100 LBS H-800 SEEDER 120 LBS DO NOT PUT HANDS IN SEED BOX WHILE SEEDER •...
- Page 5 DAMAGE TO YOUR UNITS ELECTRICAL SYSTEM AND/OR YOUR TRACTOR HUNTER 600 • RECOMMENDED FOR 40 HP AND UP TRACTORS HUNTER 800 • RECOMMENDED FOR 60 HP AND UP TRACTORS (RED POSITIVE TERMINAL—BLACK NEGATIVE TERMINAL) AVOID COMING IN CONTACT WITH ANY OTHER...
- Page 6 DETAILS ABOUT YOUR PLOTMASTER™ HUNTER SERIES 600 The Mainframe and its attachments are made of heavy gauge steel components. (Drag, Cultipacker Roller, Seeder Assembly). (refer to the diagram on page 8 to locate each of the below listed) (A. Cultipacker Roller) The roller is designed for compaction of the soil over the seed for greater germination of what has been planted.
- Page 7 DETAILS ABOUT YOUR PLOTMASTER™ HUNTER SERIES 600 (H. Linkage Rod Connections for Seeder Assembly) The Seed Flow Control Handle connects to the Slide Adjustments located on each box. The Control Handle and Linkage Rods in conjunction with the Slide adjustment activates the seed flow control from the Seeder Assembly.
- Page 8 DIAGRAM OF HUNTER SERIES 600...
-
Page 9: Linkage Rod
CULTIPACKER ROLLER LEVERAGE BAR FOR ROLLER DRAG BAR WITH METAL GRATING CONNECTING PIN FOR DRAG/CULTIPACKER SEEDER MOTOR WITH COVER SEEDER GATE HANDLE RIGHT/LEFT SEEDER ASSEMBLY LINKAGE ROD “V” SHAPED REAR GANG ASSEMBLY PLOW BAR WITH 4” SWEEP PLOW TIPS PLOW BAR ADJUSTING POINT INSTRUCTION MANUAL CARRIER ADJUSTMENT FOR FRONT GANG ASSEMBLY ADJUSTABLE FRONT GANG ASSEMBLY... - Page 10 DETAILS ABOUT YOUR PLOTMASTER™ HUNTER SERIES 800 The Mainframe and its attachments are made of heavy gauge steel components. (Drag, Cultipacker Roller, Seeder Assembly). (refer to the diagram on page 8 to locate each of the below listed) (A. Cultipacker Roller) The roller is designed for compaction of the soil over the seed for greater germination of what has been planted.
- Page 11 DETAILS ABOUT YOUR PLOTMASTER™ HUNTER SERIES 800 (H. Linkage Rod Connections for Seeder Assembly) (Older Models) (H. Linkage Rod Connections for Seeder Assembly) The Linkage Rods connect the Seed Flow Control Handle to the Slide Adjustments The Seed Flow Control Handle connects to the Slide Adjustments located on each box. The cated on each box.
- Page 12 DIAGRAM OF HUNTER SERIES 800...
- Page 13 CULTIPACKER ROLLER LEVERAGE BAR FOR ROLLER DRAG BAR WITH METAL GRATING CONNECTING PIN FOR DRAG/CULTIPACKER SEEDER MOTOR WITH COVER SEEDER GATE HANDLE RIGHT/LEFT SEEDER ASSEMBLY LINKAGE ROD CONNECTOR (Older Models) “V” SHAPED REAR GANG ASSEMBLY PLOW BAR WITH 4” SWEEP PLOW TIPS PLOW BAR ADJUSTING POINT INSTRUCTION MANUAL CARRIER ADJUSTMENT FOR FRONT GANG ASSEMBLY...
- Page 14 VERSA SEEDER ASSEMBLY THE “SPLATTER PLATE” IS DESIGNED TO ALLOW SEED TO SCATTER AND SPREAD EVENLY. THE PLATE IS ADJUSTABLE AND CAN DETERMINE THE DIRECTION OF THE SEED WHEN DISPENSING. VERTICAL: DROPS SEED DIRECTLY BEHIND THE UNIT HORIZONTAL: SPLATTERS SEED MORE WIDELY. THE “SPIRAL BRUSH”...
- Page 15 VERSA SEEDER ASSEMBLY (Above) Seed Gate Control Handle (L) Seeder Motor Cover TWO SEPARATE MOTORS FOR Adjusting Bolts located on Seeder “Y” SEEDING. THIS IS ALSO FOR STRIP Brackets are for adjusting the Single PLANTING OF TWO Splatter Shield all at once. SIMILAR SIZE SEEDS.
-
Page 16: Point Hook-Up
CULTIPACKER ASSEMBLY (Above) Pin Assembly that holds Drag/Cultipacker This Pin can be removed if the user wishes to do Tillage only w/o Leveling with the Drag (Above) Cultipacker Stop on Main Frame (Above) Hard Rubber Stop for Cultipacker Roller to rest on Drag Arm when not in use. Grease Zerk on Pillow block bearing needs to be filled periodically (Above) Pillow Block Bearing Set Screw... - Page 17 GANG ASSEMBLY (Above) Side view of unit showing the front gang (Above) Non-Greasable Sealed Bearings are used on both assembly set to throw tilled dirt outward and the rear front and rear gang assemblies. These increase longer life gang assembly set for additional tillage and for pulling and dependable use of your unit for years to come.
- Page 18 AVAILABLE PLOW TIPS Right Turning Plow Tips Reversible Tooth Point Tips...
- Page 19 These turning tips also increase the down pressure on your Plotmaster forcing the discs deeper into your soils for increased tillage. Additional Hardware needed to attach these tips to your existing “S” Tines Tip Lock (1) Per “S”...
- Page 20 PLOTMASTER™ HUNTER 600 Recommended use: Tractor 40 HP and up Unit Includes: 3 Point Hitch, I Match compatible, Dual Disc Harrow, Center Plow with (3) 4” • Sweep Plow Tips, Electric Versa Seeder, Cultipacker/Drag with Metal Grating. Dimensions: Length w/Cultipacker Folded: 100 ”...
- Page 21 Hunter 600 Seed Chart Seed lbs per Acre Gate Setting Speed Alfa-Feast Alfalfa Buckbean Bucks and Bosses Chicory Clovers Cow Pea Lablab Lablab Plus Max Attract 50/50 Millet Monster Mix Oats Pea Patch Rye Grass Sorghum Soybean Sunflowers Ultra Forage Upland Gamebird Wheat/Triticale NWGS...
- Page 22 PLOTMASTER™ HUNTER 800 Recommended use: Tractor 60 HP and up Unit Includes: 3 Point Hitch, I Match compatible, Dual Disc Harrow, Center Plow with (5) 4” • Sweep Plow Tips, Electric Versa Seeder, Cultipacker/Drag with Metal Grating. Dimensions: Length w/Cultipacker Folded: 100 ”...
- Page 23 Hunter 800 Seed Chart Seed lbs per Acre Gate Setting Speed Alfa-Feast Alfalfa Buckbean Bucks and Bosses Chicory Clovers Cow Pea Lablab Lablab Plus Max Attract 50/50 Millet Monster Mix Oats Pea Patch Rye Grass Sorghum Soybean Sunflowers Ultra Forage...
- Page 24 TWO SEASONS, TWO NUTRITIONAL NEEDS The whitetail’s nutritional needs can be divided into two parts and two needs: warm-season (spring-summer) protein need and cool-season (fall-winter) energy need. Happily, the needs of both bucks and does are virtually identical during both periods, but for different reasons. Warm-Season “Management”...
- Page 25 How to Calibrate Plotmaster Seeders To determine the seeding rate for any type seed when using the Plotmaster seeder, you need to know two things: a) seed coverage area and b) the amount of seed used to cover this area.
- Page 26 GIVE US YOUR FEED BACK The Plotmaster™ can be found on the web at: www.plotmasters.com e-mail plotmastersystems@gmail.com Drop us a line at: Plotmaster™ Systems, LLC. PO Box 111 Wrightsville, Ga. 31096 PLOTMASTER™ SYSTEMS, LLC. PROVIDES A ONE-YEAR WARRANTY AGAINST ANY MANUFACTURER’S DEFECTS.
