- Page 1 Manual 7" LCD HD video-goggle with 5,8 GHz diversity receiver HIVR 702...
-
Page 2: Table Of Contents
Index Introduction ................3 Service Centre ................3 Intended use ................4 Package content ................4 Symbols explication ..............5 Safety notes ................5 Charge the Lithium battery ............6 Control panel................7 Bottom ..................8 Commissioning ................8 Screen symbols / Setting menu ..........9 Technical Data ................. 10 Battery warranty ..............10 Declaration of conformity ............ -
Page 3: Introduction
Introduction Thank you very much for purchasing the 7” (inch) Monitor Goggle. This 7” Monitor Goggle is extremely versatile. Read this manual carefully to achieve the best results with your 7” Monitor Goggle and first of all to safely control your models. If you experience any trouble during operation, take the instructions to help or ask your dealer or Graupner Service Centre. -
Page 4: Intended Use
Intended use The 7“ Monitor Goggle is suitable to reproduce images from FPV cameras signal or to playback videos or images from external sour- ces. The integrated 5,8 GHz receiver receives the video signal sent by the FPV transmitters installed in the model. For any improper use no warranty or liability is accepted. -
Page 5: Symbols Explication
Symbols explication CAUTION WAR- Always follow the information marked with the NING WARNING symbol. The signal word indicates the potential for serious injury, the signal word CAUTION indicates possibility of ligh- ter injuries. The signal words NOTE and CAUTION indicate potential damages to objects. -
Page 6: Charge The Lithium Battery
Charge the Lithium battery CAUTION General notes on safety and handling Lithium (Li) batteries • NEVER leave a Lithium battery unattended when in charge. Charge the batteries only in rooms where a smoke detector is installed. • ALWAYS control the battery and the charger during the entire charge process. -
Page 7: Control Panel
Control panel Right side Left side "-" button On-screen menu Scroll down Scan button V 1/2 - Video input Channel switch no function "+" button Buttons Description Video source Selection of the video input Band select Manual select one of the three signal band A/B/F Channel select Manual select one of the eight channels 1-8 SCAN function... -
Page 8: Bottom
Bottom 1 HD IN (not available) 5 AV IN - Video input 2 Mini USB input 6 AV OUT - Video output 3 TF (not available) 7 3,5 mm earphone socket 4 Tripod thread Commissioning Screw the included 5,8GHz antennas on the two connectors placed on the top of the monitor goggle. -
Page 9: Screen Symbols / Setting Menu
Earphone socket Here you can connect your earphone Screen symbols / Setting menu Changes of the frequency band or of the channel will be shown in the upper part of the screen. Charge the battery if the battery indi- cator indicates empty battery. 1. -
Page 10: Technical Data
Technical Data Screen dimensions: 7“ (inches) / 178 mm TFT LCD Monitor, LED backlight, 800 x 480 Pixel Contrast: 500:1 Holder: tripod thread / sliding insert ISM 5.8 GHz, 40 channel diversity head set Battery: 2600 mAh Lithium battery ... -
Page 11: Notes On Environmental Protection
Notes on environmental protection Disposal notes This symbol on the product, user manual or packaging indicates that this product must not be disposed of with other household waste at the end of its life. It must be handed over to the applicable collection point for the recycling of electrical and electronic equipment. - Page 12 48352_jh_V1...
