- Page 1 Manual LCD video-goggle with 5,8 GHz diversity receiver HIVR 101...
-
Page 2: Table Of Contents
Index Introduction..................3 Service Centre.................3 Intended use...................4 Package content................4 Symbols explication............... 5 Safety notes..................5 Charge the Lithium battery............6 Control panel .................. 7 Commissioning................8 Technical Data.................8 Battery warranty................9 Declaration of conformity..............9 Notes on environmental protection..........10 Care and maintenance..............10 Warranty.................. -
Page 3: Introduction
Introduction Thank you very much for purchasing the Video-goggle. This Vid- eo-goggle is extremely versatile. Read this manual carefully to achieve the best results with your Video-goggle. If you experience any trouble during operation, take the instructions to help or ask your dealer or Graupner Service Centre. -
Page 4: Intended Use
Intended use The Video-goggle is suitable to reproduce images from FPV cameras signal or to playback videos or images from external sources. The integrated 5,8 GHz receiver receives the video signal sent by the FPV transmitters installed in the model. For any improper use no war- ranty or liability is accepted. -
Page 5: Symbols Explication
Symbols explication CAUTION WARN- Always follow the information marked with the WARNING symbol. The signal word indicates the potential for serious injury, the signal word CAUTION indicates possibility of lighter injuries. The signal words NOTE and CAUTION indicate potential damages to objects. -
Page 6: Charge The Lithium Battery
Charge the Lithium battery CAUTION General notes on safety and handling Lithium (Li) batteries • NEVER leave a Lithium battery unattended when in charge. Charge the batteries only in rooms where a smoke detector is installed. • ALWAYS control the battery and the charger during the entire charge process. -
Page 7: Control Panel
Control panel Volume "+" Front camera (optional) 10 Contrast "+" Scan Brightness "-" 11 Brightness "+" CH (channel) Select RF-2D,AV1-2D, 12 Head-tracker (optional) FR (Frequency) AV2-2D, HD-2D Volume "-" Contrast "-" Bottom 1 AV input 2 AV output 3 Earphone socket 4 Shovel for pupils distance 5 Battery connection port 7- 12... -
Page 8: Commissioning
Commissioning Screw the included 5,8GHz antennas on the two connectors placed on the top of the Video-goggle. The power is supplied by the included Lithium battery, pay attention to charge the battery before use. Fix the battery in the elastic band. Connect the battery connection cable. -
Page 9: Battery Warranty
This does not apply to batteries in which the charge and discharge notes were not observed. Declaration of conformity HIVR 101 Video-goggle with 5,8 GHz receiver Graupner/SJ declares that the product is conform to EU norms. EMV 1999/5/EC EN 301 489-1 V1.9.2 (2011-09) -
Page 10: Notes On Environmental Protection
Notes on environmental protection Disposal notes This symbol on the product, user manual or packaging indicates that this product must not be disposed of with other household waste at the end of its life. It must be handed over to the applicable collection point for the recycling of electrical and electronic equipment. -
Page 11: 48352_Jh_V1
11- 12 48352_jh_V1... - Page 12 48352_jh_V1...
