INSTRUCTION AND SAFETY MANUAL
Expandable davit arm system 762 mm - 1219 mm (30" - 48")
Xtirpa removable adaptor for PPE
IN-8015 UNIVERSAL RESCUE SYSTEM
™
MUST BE READ AND UNDERSTOOD BY THE USER BEFORE EACH USE
INNOVA Public Utility Products, Inc., 1040 BOUL. INDUSTRIEL, GRANBY, QUEBEC, CANADA
Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.ca
P. 1
Number:
MU8015-002ANG 2017
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Innova XTIRPA IN-8015
Summary of Contents for Innova XTIRPA IN-8015
- Page 1 Xtirpa removable adaptor for PPE IN-8015 UNIVERSAL RESCUE SYSTEM ™ MUST BE READ AND UNDERSTOOD BY THE USER BEFORE EACH USE INNOVA Public Utility Products, Inc., 1040 BOUL. INDUSTRIEL, GRANBY, QUEBEC, CANADA Tel (450) 777-1240 Fax (450) 372-9936 www.xtirpa.ca P. 1 Number:...
- Page 2 CAUTION The XTIRPA System is part of a personal protection equipment system, a protection system against falls, a work and safety positioning system to be used in isolation. The user must read, understand and respect the manual’s instructions for each of the entire XTIRPA system’s components and parts.
- Page 3 DESCRIPTION AND INTERPRETATION OF THE MARKING SYMBOLS This symbol is used to attract the user’s attention on a potential danger. The latter’s safety is at risk. It is essential to follow the manufacturer’s recommendations. This symbol asks the user to read and understand this product’s operation manual before us- ing it.
- Page 4 APPLICATION The XTIRPA System as well as its numerous components and parts (including the davit arm, safety guard, removable adapter, permanent adapter, integrated mast and side entrance trolley) were engineered to be used as part of a personal protection equipment system, a protection system against falls, a work and safety positioning system, a staff management system, an equipment management system and a safeguard system to be used in isolation.
- Page 5 f) Wear any appropriate, certified and recommended safety equipment, including, without limitation, safety helmet, protective glasses, leather gloves, protective clothing, safety boots, harness compliant with EN 361, flashlight and respiratory system if necessary. CAUTION: The equipment must not be used beyond its limits or for purposes other than those for which it was originally intended.
- Page 6 XTIRPA System for your application, please contact the PSP INNOVA INC. Manufacturer. CAUTION: To ensure security during the use of the fall arrest system, it is essential to make sure that there is enough clearance below the user, so as to avoid any injury.
- Page 7 IMPORTANT : If you have questions related to the use, maintenance or adequacy of the XTIRPA System for your application, please contact the PSP INNOVA INC. Manufacturer. IMPORTANT : Enter the product’s ID number indicated on the ID label on the maintenance and inspection sheet contained in this Instruction and Safety Manual.
- Page 8 g) A person who hasn’t read the Instruction and Safety Manual, who hasn’t been trained to use the XTIRPA System and who doesn’t understand all the operation and safety instructions, is not qualified to use the XTIRPA System. A user who wasn’t trained exposes others and himself/ herself to serious injuries or death, for which the manufacturer refuses any warranty or responsibility, the user, owner and buyer of the XTIRPA System waiving any arising claim,...
- Page 9 MAINTENANCE/REPAIRS/STORAGE a) Before each use, the user must read, understand and follow the manufacturer’s Instruction and Safety Manual. Ensure that markings are visible at all times. b) Before each use, inspect carefully the XTIRPA System as well as all its components and parts. Any faulty part or component could lead to serious injury or even death.
-
Page 10: Warranty
WARRANTY The XTIRPA System, offered by the PSP INNOVA INC. Manufacturer, is warranted against all defects in material and labor for a (2) two-year period from the date of purchase, this warranty does not protect the XTIRPA System’s initial buyer. The Manufacturer will promptly repair or replace all the components or parts that he deemed faulty, the Manufacturer reserves the right to ask for the allegedly faulty part to be return to his factory, before performing any repair or replacement. - Page 11 DESCRIPTION OF THE XTIRPA SYSTEM CAUTION The XTIRPA System is part of a personal protection equipment system, a protection system against falls, a work and safety positioning system, a staff management system, an equipment management system and a safeguard system to be used in isolation. The XTIRPA System was engineered to act as a supporting or anchoring structure for these uses.
- Page 12 Illustration 2: IN-2426 Illustration 3: IN-2240 Illustration 1: IN-2237 Illustration 4: IN-2313 Illustration 5: IN-2380 Illustration 6: A2237-06 Illustration 7: IN-8015 P. 11 MU8015-002ANG 2017...
- Page 13 IMPORTANT : If you have questions related to the use, maintenance or adequacy of the XTIRPA System for your application, please contact the PSP INNOVA INC. Manufacturer. IMPORTANT : Enter the product’s ID number indicated on the ID label on the maintenance of the XTIRPA System and inspection sheet contained in this Instruction and Safety Manual.
- Page 14 SYSTEM’S OPERATION AND USE Davit arm with mast and barrel adaptor Ensure that all components and parts are in perfect operating condition and that everything works properly. IN-2237 IN-2380 IN-2240 A. Remove the retention pins. Adjust both parts of the adaptor to get a distance that is barely greater than the low wall on which it is installed.
- Page 15 If you have questions related to the use, maintenance or adequacy of the XTIRPA System for your application, please contact the PSP INNOVA INC. Manufacturer. To install a second handling winch or lifeline, follow the following steps using the removable bracket for the A2237-06 handling winch P.
- Page 16 XTIRPA System for your application, please contact the PSP INNOVA INC. Manufacturer CAUTION: Any system must immediately be removed from circulation: if the security is questioned or if it was used to stop a fall. It is imperative to immediately stop using the system until a competent person authorizes in writing the product’s integrity before it can be used again.
- Page 17 THE FOLLOWING INFORMATIVE AND SAFETY LABELS MUST BE CLEAN AND READABLE AT ALL TIMES INSTRUCTION LABEL IN-2237 INSTRUCTION LABEL IN-2240 INSTRUCTION LABEL IN-2313 P. 16 MU8015-002ANG 2017...
- Page 18 INSTRUCTION LABEL IN-2426 INSTRUCTION LABEL IN-2380 INSTRUCTION LABEL IN-2237 P. 17 MU8015-002ANG 2017...
- Page 19 Calculation diagram P. 18 MU8015-002ANG 2017...
- Page 20 P. 19 MU8015-002ANG 2017...
- Page 21 P. 20 MU8015-002ANG 2017...
