Assembly Manual

LED working light (7092.65)

Need help?

Do you have a question about the 7092.65 and is the answer not in the manual?

Page 1 Assembly Manual LED working light (7092.65)
Page 2 In the case in this assembly manual should only be of necessary repair work, please make undertaken by a Hako service centre or sure that only original spare parts are a workshop authorised by Hako. Mem- used.
Page 3 LED working light LED working light Parts list 1 1x LED working light compl. 2 1x corrugated hose holder Before installation 1. Place the machine on a level surface and turn it off. 2. Remove floor mat in footwell. 3. Remove brake button (Fig. 1/3) Fig.
Page 4 LED working light Installing the working light The working light is installed on the left next to the front wheel (Fig. 2/1). 1. Fit working light to holder of chassis (Fig. 2/2). 2. Insert corrugated hose holder into existing hole (Fig. 2/3). 3.
Page 5 LED working light Setting in the configuration menu The LED working light option must be activated via the configuration menu. Option Value LED working light 1. 6. 1. Requirements: • Batteries inserted • 4-digit code or diagnosis plug 97097737 is present. If diagnosis plug is used: Connect diagnosis plug to slot X20 of controller A1 (Fig.
Page 6 Advanced Technology for a Cleaner, Better Environment · · · · Hako GmbH Head Office Hamburger Str. 209-239 23843 Bad Oldesloe Germany · Phone +49 4531 806-0 Fax +49 4531 806-338...
