- Page 1 AGF Professional 1500 INSTALLATION INSTRUCTIONS 450mm 850mm 600mm 595mm – 1000mm 300mm 1500mm Tel: (03) 9355 7100 Fax: (03) 9355 7166 Email: sales@agradefinish.com.au Web: www.agradefinish.com.au 9 Norfolk Court, Coburg North Victoria 3058...
-
Page 2: Table Of Contents
7. Technical support ......... 10 8. Warranty ..........10 1. Welcome Congratulations on you purchase of AGF Professional 1500 Rangehood Please make sure to read through the installation instructions prior to installing the unit as it contains important information. Please make sure you follow these installation instruction as they contain vital safety information. -
Page 3: Safety
Always switch power off prior to installing, servicing or cleaning the appliance. 3. Item Check list 1. AGF PROFESSIONAL 1500 RANGEHOOD BOX 2. 2 x AGF310 ROOF MOUNT FAN 3. 2 x 1000mm OF SOLID 305MM DUCTING AGF PROFESSIONAL 1500 RANGEHOOD BOX CONTENTS •... -
Page 4: Installation
Hold rangehood up to the marks (step 2 and 3) and mark the mounting points. (Refer figure 3) Step 5: Screw fixings into marks for mounting Step 6: Figure 4 Hang the rangehood and tighten to fix to the wall. (Refer figure 4) PAGE 3 AGF Professional 1500... - Page 5 Install the flue support bracket to the beam and screw to the duct. (Refer figure 5 / 6) Repeat for the second duct. Please leave a minimum gap of 500mm between the solid ducts. (Refer figure 7) Figure 7 AGF Professional 1500 PAGE 4...
-
Page 6: Step
Step 11: Install the rubber dektite over the solid duct. Do not fix down at this point refer step 13. (This can be purchased at additional cost via our online store: www.agradefinish.com.au) PAGE 5 AGF Professional 1500... - Page 7 Screw the bottom piece to the rangehood and also screw to the top piece for extra support. (Refer figure 17) Step 19: Thank you for purchasing an A Grade rangehood. Enjoy! Figure 15 Figure 16 Figure 17 AGF Professional 1500 PAGE 6...
-
Page 8: Operation
1. Slide filter to back of rangehood 2. Pull filter down and slide filter towards the front of the rangehood to release from body 3. To reinsert the filter do steps I and 2 in reverse PAGE 7 AGF Professional 1500... -
Page 9: Maintenance
2. Pull the globe holder and globe out and disconnect the globe from the lamp lead Do not exceed 50 Watts 3. Once disconnected from the lamp lead, remove the halogen light from its housing Do not exceed 50 Watts AGF Professional 1500 PAGE 8... -
Page 10: Technical Support
6. Insert back into housing and turn in clockwise direction to lock into place. Do not exceed 50 Watts 7. Technical Support For all technical support please contact: A Grade Finish Canopies on (03) 9355 7100 or via email info@agradefinish.com.au PAGE 9 AGF Professional 1500... -
Page 11: Warranty
8. Warranty AGF 1500 PRO-2 has a standard 24 months warranty from date of purchase. An additional 12 months warranty can be purchased direct from A Grade Finish Canopies for $250 Including GST. This document sets out the terms and conditions of the product (d) damage to the Appliance caused by: warranties for A Grade Finish Rangehoods.
