- Page 1 Installation Instructions AGF Professional 1500 Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166 Email: info@agradefinish.com.au Web: www.agradefinish.com.au...
-
Page 2: Table Of Contents
Index 1. Welcome 2. Safety 3. Item check list 4. Installation 5. Operation _____________________________________________________________13 6. Maintenance___________________________________________________________15 7. Technical support_______________________________________________________19 8. Warranty______________________________________________________________19 Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166 Email: info@agradefinish.com.au Web: www.agradefinish.com.au... -
Page 3: Welcome
1. Welcome Congratulations on you purchase of AGF Professional 1500 Rangehood Please make sure to read through the installation instructions prior to installing the unit as it contains important information. Please make sure you follow these installation instruction as they contain vital safety information. -
Page 4: Safety
2. Safety Please read this section prior to operating this unit. If you find the rangehood is damaged in anyway please do not install and contact A Grade Finish Canopies ASAP on (03) 9355 7100. This appliance is not intended for use by young children or infirm persons without adequate supervision. -
Page 5: Item Check List
3. Item Check list 1. AGF PROFESSIONAL 1500 RANGEHOOD BOX 2. AGF310 ROOF MOUNT FAN 3. 2 x 700mm OF SOILD 305MM DUCTING AGF PROFESSIONAL 1200 RANGEHOOD BOX CONTENTS 1 x rangehood (including filters) 1 x 2 piece telescopic flu... -
Page 6: Installation
4. Installation Step 1: Open box and check there is no damage to the rangehood (if there is any damage please contact a grade finish canopies on (03) 9355 7100) Step 2: Mark out the centre of where you wish to install the rangehood. (see figure 1) Step 3: Mark out the height that you rangehood is to be installed at. - Page 7 Step 4: Hold rangehood up to the marks (step 2 and 3) and mark the mounting points. (See figure 3) Step 5: Screw fixings into marks for mounting Step 6: Hang the rangehood and tighten to fix to the wall. (See figure 4) Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166...
- Page 8 Step 7: cut a hole in the ceiling above the rangehood to enable the flexible ducting and power cables to pass through easily. Be sure not to make the hole bigger than then the flue cover. The hole will need to be big enough to be able to pass the power cables though to the ceiling.
- Page 9 Step 8: Installing the solid ducts For this step you will need to mark out where the ducting is to pass through the roof. Make sure that when marking out the location of the ducting it is next to a beam (for support) With the location of the ducting confirmed cut the hole out in the roof to enable the ducting to pass through the roof leaving 250mm outside the roof.
- Page 10 Step 9: install the flue cover bracket 150mm down from the ceiling (see figure 8) Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166 Email: info@agradefinish.com.au Web: www.agradefinish.com.au...
- Page 11 Step 10: Installing the flexible duct to the solid duct and connecting the 3 way junction. Install the joiner to the bottom of the solid ducts and secure with screws leaving about half of the joiner out the bottom to allow for the flexible ducts to connect to. (See figure 9) Connect one end of the flexible duct to the stating pop on the rangehood.
- Page 12 If you need to install the flexible duct with a bend do not make the bend to sharp as this can restrict airflow see figure 11 as an example for correct instalment of bend Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166 Email: info@agradefinish.com.au...
- Page 13 Step 11 Install the rubber dektite over the solid duct. Do not fix down at this point refer step 13 Step 12: install the motor to the ducting. Slid the flange of the motor to the outside of the ducting and level the unit. Once level screw to the ducting. See figure 11 Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166...
- Page 14 Step 13: with the motor now fixed pass the power lead from fan inside the dektite. See figure 13 Figure 13 Step 14: once cable has been placed inside dektite finish screwing dekite down and silicon all edges Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166 Email: info@agradefinish.com.au...
- Page 15 Step 15: Connect male plug from rangehood to main power supply. See figure 14 Step 16: Connect female plug from rangehood to male plug of double adaptor See figure 14 Step 17: connect both of the fans to the double adaptor Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166...
- Page 16 Step 17: Installing the flue cover With both flue pieces connected to each other (smaller piece to the outside) place on top of rangehood. Slide the inner piece up to ceiling height and screw into the mounting bracket installed in step 9.
- Page 17 With the top half of the flue now secure you will now need to secure the bottom piece Screw the bottom piece to the rangehood and also screw to the top piece for extra support. (See figure 16) Step 18: enjoy your new rangehood Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166...
-
Page 18: Operation
5. Operation Rangehood switch Power on/off (Fan will not operate without power being on) While fan running press power button once to engage the 3 minute timer. Once timer has completed unit will switch off (lights will still remain on after timer has completed). Press the power button second time to switch unit off and bypass the timer function. - Page 19 5. Operation Filter Removal/Installation When removing filters use both the handles and slide the filter to the back of the unit. Once you have the filter at the back of the unit this will enable the filter to release from the rangehood.
-
Page 20: Maintenance
6. Maintenance Please ensure that you unit is turned off prior to conducting any cleaning. Filters should be cleaned every 3 months or more frequently depending on the use. NEVER turn the filters around. Handles are to be facing down at all times. NEVER USE CLOSTIC SODA AS THIS WILL DAMAGE FILTERS Never wipe unit with a wet cloth as water may affect the electrical switches. - Page 21 Globe Removal 1. Rotate the inner globe holder in an anti-clockwise direction Do not exceed 50 Watts 2. Pull the globe holder and globe out and disconnect the globe from the lamp lead Do not exceed 50 Watts Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166 Email: info@agradefinish.com.au...
- Page 22 3. Once disconnected for the lamp lead remove the halogen light from its housing Do not exceed 50 Watts 4. Insert a new globe into the housing making sure the globe fit nice and tight in the housing. Do not exceed 50 Watts Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166...
- Page 23 5. Reconnect the globe and holder to lamp lead Do not exceed 50 Watts 6. Insert back into housing and turn in clockwise direction to lock into place. Do not exceed 50 Watts Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100 Fax: (03) 9355 7166 Email: info@agradefinish.com.au...
-
Page 24: Technical Support
7. Technical Support For all technical support please contact A Grade Finish Canopies on (03) 9355 7100 or via email info@agradefinish.com.au 8. Warranty AGF310 has a standard 12 months warranty from date of purchase. An additional 12 months warranty can be purchased direct from A Grade Finish Canopies Please refer to warranty card included in box for full warranty terms Factory: 9 Norfolk Court, North Coburg VIC 3058 Ph: (03) 9355 7100...
