- Page 1 Lamellar Grinding Machines T-20/T-25 11/2012 Instruction Manual T 20 GS-Schleiftechnik Am Kiebitzengraben 4 91315 Höchstadt DE Tel.0700-24681234- e-mail: info@gs-de.eu - Internet: www.gs-de.de...
-
Page 2: Table Of Contents
Contents as of 12/01/12 1. General 1.1 Warranty Information 1.2 Description and Features 1.3 Overview 1.4 Technical Data and Dimension 2. Start-up 2.1 Package Contents 2.2 Installation 2.3 Electrical Connection 2.4 Rotation check-up 3. Cleaning 3.1 Preparation for cleaning 3.2 Cleaning instructions 3.3 Grinding machine made ready for work 4. -
Page 3: Warranty Information
This however is of no influence to our manual. 1.2 Description and Features The T-20/25 Lamellar Grinding Machines serve to sharpen cutting tools such as: - Cutting knife - Cutter knife... - Page 4 1.3 Technical manual Table-top devices of the latest state-of-the art developments for modern and economic tool grinding -Space-saving and closed construction Design according to the requirements of international safety regulations -Impact-resistant aluminum housing -High performance drive with optimum disc speed -Lamellar grinding disc Polishing disc for honing Features...
-
Page 5: Start-Up
- Polishing paste - Manual 2.2 Installation The Lamellar Grinding Machines T-20/25 must be installed in a dry working area only. You have to provide: - a sufficient work space for operation and cleaning - a foot-sure floor for the operator - a smooth, even working surface 2.3 Electrical connection... -
Page 6: Cleaning
3. Cleaning 3.1 Preparation for cleaning For cleaning the Lamellar Grinding Machines T-20/25 must be unplugged from the electrical power supply (unplug from power plug). 3.2 Cleaning instructions The Lamellar Grinding Machines T-20/25 must not be cleaned with a high-pressure cleaner or be put into water! The polishing honing disc must not come into contact with water. -
Page 7: Honing Of Tools
4.2 Sharpening of tools with the lamellar grinding disc Pre-grinding (changes in shape of the cutting edge) and finest regrinding are achieved if the tool is moved in a simple alternating motion in a longitudinal direction (somewhat parallel to the motor axis) and by varying the grinding pressure. The lamellar disc adapts itself automatically to the cutting edge of the tool, in way, that if required, the existing blade shape is fully maintained. - Page 8 , without consulting us this declaration loses validity. GS-Schleiftechnik stocks a complete technical documentation ready for examination. The manual belonging to this machine is available in its original version. The conformity for the knife grinder T - 20 is ensured D-90431 Nürnberg, 01.11.2012...
- Page 9 , without consulting us this declaration loses validity. GS-Schleiftechnik stocks a complete technical documentation ready for examination. The manual belonging to this machine is available in its original version. The Conformity for the knife grinder T - 25 is ensured D-90431 Nürnberg, 01.11.2012...
- Page 10 Part list Specification T-20 Serial no.: Item Side Part left GS200-2-2 Bottom GS200-2-2 Cover GS200-6-2 Protection inside Protection outside Dirt Trap Welding Work Cover/Lid Safety Washer for polishing disc 12 691 007 001 Nut M 12 for Polishing Disc T 20...
- Page 11 Part List Specification T-25 Serial No.: Item Basic Housing 11 400 250 502 Engine Console 11 225 300 300 Cover Grinding Motor 11 225 300 310 Bottom Cover Metal Plate 11 225 332 001 Rubber Buffer 12 20 25 6 18 Safety Washer for Polishing Disc 12 691 007 001 Nut M 14 for Poliishing Disc...
- Page 12 Datum Name Benennung Z-Nr. T 20 GS-Schleiftechnik 10.10.12 90431 Nürnberg Ansicht: Material:...
