  • Page 1 ASPECT 4/4 COMPACT ASPECT 5/5 COMPACT ASPECT 5 SLIMLINE ASPECT 6 ASPECT 7 ASPECT 8 SLIMLINE ASPECT 8 ASPECT 9 ASPECT 14 WOODBURING STOVE MODELS Instructions for: Installation/Operating/Maintenance/Servicing JINSPADA REV C 06/06/2019...

  • Page 2: Stove Models

    STOVE MODELS ASPECT 4 ASPECT 4 COMPACT CVSPA04WS/CVSPA04WB CVSPA04CWS/CVSPA04CWB ASPECT 5 ASPECT 5 COMPACT CVSPA05WS/CVSPA05WB CVSPA05CWS/CVSPA05CWB...
  • Page 3 ASPECT 5 SLIMLINE ASPECT 6 CVSPA05SWS/CVSPA05SWB CVSPA06WS/CVSPA06WB ASPECT 7 ASPECT 8 SLIMLINE CVSPA07WS/CVSPA07WB CVSPA08SWS/CVSPA08SWB ASPECT 8 ASPECT 9 CVSPA08WS/CVSPA08WB CVSPA09WS/CVSPA09WB ASPECT 14 CVSPA14WS/CVSPA14WB...

  • Page 4: Table Of Contents

    Welcome to the Hunter Stoves family and thank you for purchasing a Parkray Aspect stove. This stove was designed and built to be a high-performance heating appliance, and we hope it will bring you great enjoyment. The natural environment is important to us, so our stoves are manufactured to provide you with a clean and efficient burn that will keep you warm through cold winter nights.
  • Page 5 Technical Specification Aspect Aspect 4 Aspect Aspect 5 Aspect 5 Aspect Compact Compact Slimline Energy Efficiency Class Nominal Heat Output Wood 4.9kW 4.9kW 4.9kW 4.9kW 4.9kW 4.9kW Energy Efficiency Efficiency Wood 85.9% 85.5% 79.0% 81.6% 79.0% 78.3% Mean CO (@13% O₂) Wood 0.33% 0.48%...

  • Page 6: Technical Specification

    TECHNICAL SPECIFICATION Aspect 8 Aspect 7 Aspect 8 Aspect 9 Aspect 14 Slimline Energy Efficiency Class Nominal Heat Output Wood 4.9kW 4.9kW 6.0kW 8.0kW 9.5kW Energy Efficiency Efficiency Wood 78.1% 79.2% 79.2% 73.6% 71.9% Mean CO (@13% O₂) Wood 0.23% 0.24% 0.12% 0.11%...
  • Page 7 PLEASE READ THESE INSTRUCTIONS PRIOR TO INSTALLATION AND OPERATION. KEEP THESE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE AND SERVICING. THIS APPLIANCE WILL BECOME VERY HOT WHEN USED IN ACCORDANCE WITH THESE INSTRUCTIONS, HUNTER STOVES RECOMMEND THAT AN APPROVED GUARD IS USED TO PROTECT THE YOUNG, ELDERLY OR INFIRM FROM HARM.

  • Page 8: Safety

    Metal Parts When installing or servicing this stove, care should be taken to avoid the possibility of personal injury. Modification No unauthorised modification of this appliance should be carried out. Safety WARNING – This appliance will be hot when in operation and due care should be taken. The supplied operating tool or glove may be used to open the door and operate the air controls.

  • Page 9: Remove Internal Components

    Removing Internal Components All internal components must be removed prior to fitting the stove. This will make handling the stove easier; allow access to fixings and the flue outlet; as well as protect the internal components from damage during the installation process Fuel Retainer Open the door and remove the fuel...
  • Page 10 Upper and Lower Rear Bricks Push the upper brick upwards (A). Then pull the bottom edge of the rear brick forward (B) and lift the brick out of the stove. Repeat with the lower brick. Baffle/Throat Plate Push up and (A) drop one edge downward into the bottom of the stove and pull outwards (B).
  • Page 11 Wind the four M6 studs supplied into the fixing holes in the flue collar until finger tight. Place the flue collar onto the stove and tighten using the supplied washers and nuts from inside the stove. Blanking Plate Place the gasket on the outlet and put the blanking plate on top of this.

  • Page 12: Appliance Dimensions

    Appliance Dimensions Aspect Dimensions Aspect 4 Compact/Aspect 4 BOTH COMPACT STANDARD Dimensions Aspect 5 Compact/Aspect 5 BOTH COMPACT STANDARD Dimensions Aspect 5 Slimline...
  • Page 13 Dimensions Aspect 6 Dimensions Aspect 7 Dimensions Aspect 8 Slimline...
  • Page 14 Dimensions Aspect 8 Dimensions Aspect 9 Dimensions Aspect 14...

  • Page 15: Pre Installation Requirements

    Pre-Installation Requirements Please check the following: Any existing chimney/flue system must be confirmed as suitable for this appliance as defined in Building Regulations Document J. It must be swept and inspected, by a competent person (see notes), to confirm that it is structurally sound and free from cracks and obstructions.

  • Page 16: Legal Requirements

    Legal Requirements Hunter Stoves Group requests that before installation and/or use of this appliance that you read these instructions carefully to ensure that all the relevant requirements are fully understood. These instructions cover the basic principles to ensure satisfactory installation of the stove, although details may need slight modification to suit particular local site conditions.
  • Page 17 Hearth/ Material Clearances Hearth constructions must comply with the current building regulations. Your stove must be installed on a floor with adequate load-bearing capacity, otherwise suitable measures should be taken. If the existing construction does not meet this pre-requisite, suitable measures (e.g. load distributing plate) should be put in place.

  • Page 18: Fitting Heat Shield

    Removal Of Rear Heat Shield Flue Heat Shield To remove the heat shield, 4’s – ECIC04047 remove the button-head 5 Slimline and 6 – ECIS05054 screw and pull the shield 5s and 7 – ECIC05031 towards you until the 8/8 Slimline/9/14 – ECIS08054 right-hand edge clears the Rear Heat Shield stove body and pops out.

  • Page 19: Commissioning And Handover

    Non Combustible – Free Standing If the stove is not to stand in a recess, it may stand wholly above a hearth made of non-combustible board / sheet material or tiles, at least 12mm thick. The hearth should extend at least 150 mm from the sides and rear of the stove, and at least 300 mm from the front of the stove (350mm recommended).

  • Page 20: Operating Instructions

    Please advise the customer on the correct use of the appliance with the fuels likely to be used on the stove and warn them to only use the recommended fuels for their specific stove. Advice the user on what to do should smoke or fumes be emitted from the stove. The user should be warned to use a fireguard to BS 8423:2010+A1:2016 in the presence of children, aged and/or infirm persons.
  • Page 21 Please Note Your Building Insurance Company may require you to inform them of this new installation and that the work has been carried out correctly. Please check your policy to ensure that it is still valid when this installation is complete. Using The Appliance For The First Time SAFETY ADVICE During the first operation it is highly likely that fumes and smells maybe produced as part of the...
  • Page 22 C) The air intake needs to be between 25% - 50% open to obtain the best result for burning wood. Warning! – This Appliance will be hot when in operation and due care should be taken. We advise that suitable gloves, or the operating tool is used when operating the air control, and when opening the door Primary Air - The primary air provides a conventional air draught to the bed of the fire.

  • Page 23: Maintenance & Servicing

    Recommended Fuels Hunter Stoves Group recommend that only wood logs with a moisture content of less than 20% should be burnt on this appliance. Burning wet or unseasoned wood will create excess smoke emissions, tar deposits in the stove and chimney and will not produce a satisfactory heat output.
  • Page 24 Gaskets/Tape The glass gasket will have to be replaced when a new piece of glass is fitted as the gaskets become brittle after firing the stove as will the self-adhesive tape. Over time you may also find that the gasket changes colour. This is due to a reduction in the pigment used in the manufacture of the product and no cause for concern.
  • Page 25 Rope Check the rope around the door. If rope is becoming detached, use rope glue to reattach it. If the rope is in a poor condition, a replacement rope kit may be ordered from the Hunter Stoves Group spares range. Chimney and Flue Ways It is important that the chimney, flue ways and any connecting flue pipe are swept regularly.
  • Page 26 TROUBLESHOOTING ISSUE CAUSE RESOLUTION Problem starting the fire and Low flue draught Speak to your installer keeping it burning Wood with moisture content over 20% Ensure use of dry seasoned wood with less than 20% moisture content Unable to control fire High flue draught Speak to your installer Short burn time...

  • Page 27: Troubleshooting/Data Plate

    ISSUE CAUSE RESOLUTION Creosote build-up in chimney Wood with moisture content over 20% Use dry seasoned wood (less than 20% moisture content). Operate at a high temperature for short periods each time the appliance is used to avoid large build-ups of tars and creosotes. Tar coming from flue joints Appliance operated at continuous low Operate at a high temperature for...
  • Page 28 STOVE CARE PRODUCTS All replacement parts and stove care products are available from our website shop www.hunterstoves.co.uk. PRODUCT CODE Glass Cleaner (150mm Aerosol) SCPGC Fire Cement (500gm) SCPFC500 Rope Glue (25ml) SCPGLUE25ML Gauntlet Gloves (Pair) GGLOVE-HSG Touch up Paint with Brush (236ml) SCPPB Spray Paint (400ml) 40.011400HSG...

  • Page 29: Spares

    Spares Information ASPECT 4 COMPACT/ASPECT 4 – DOOR FRONT VIEW ASPECT 4 COMPACT/ASPECT 4 – DOOR REAR VIEW ASPECT 5 COMPACT/ASPECT 5 – DOOR FRONT VIEW ASPECT 5 COMPACT/ASPECT 5 - DOOR REAR VIEW ASPECT 5 SLIMLINE/6 - DOOR FRONT VIEW ASPECT 5 SLIMLINE/6 - DOOR REAR VIEW...
  • Page 30 ASPECT 7 – DOOR FRONT VIEW ASPECT 7 – DOOR REAR VIEW ASPECT 8/8 SLIMLINE/9 AND 14 - DOOR FRONT VIEW ASPECT 8/8 SLIMLINE/9 AND 14 - DOOR REAR VIEW BODY ASSEMBLY SPARES ASPECT COMPACT 4 AND 4...
  • Page 31 BODY ASSEMBLY SPARES ASPECT COMPACT 5 AND 5 BODY ASSEMBLY SPARES ASPECT 5 SLIMLINE...
  • Page 32 BODY ASSEMBLY SPARES ASPECT 6 BODY ASSEMBLY SPARES ASPECT 7...
  • Page 33 BODY ASSEMBLY SPARES ASPECT 8 BODY ASSEMBLY SPARES ASPECT 8 SLIMLINE...
  • Page 34 BODY ASSEMBLY SPARES ASPECT 9 BODY ASSEMBLY SPARES ASPECT 14...
  • Page 35 INSTALLATION & COMMISSIONING CHECKLIST PURCHASE INFORMATION Dealer/Retailer Name Address Telephone Number Email Date Purchased INSTALLER INFORMATION Installer Name Address Telephone Number Email APPLIANCE INFORMATION Date Installed Appliance Stock Code Appliance Description Serial Number COMMISSIONING CHECK (Complete & Sign) Does the chimney/flue system meet the appropriate standard? Has the chimney/flue system been swept and passed the soundness test? Has this appliance passed the flue draught test? Please write down the flue draught reading:...

  • Page 36: Service Records

    SERVICE RECORDS Service Service Date of Service Date of Service Date of next Service Date of next Service Servicing Company/ Servicing Company/ Engineer Engineer Signature Signature Service Service Date of Service Date of Service Date of next Service Date of next Service Servicing Company/ Servicing Company/ Engineer...
  • Page 37 Hunter Stoves Group Ltd Extended 5 and 10 Year Warranty 2 Year Standard Warranty Any appliance bought through the showroom of an authorised Hunter Stoves Group dealership will automatically be covered by our standard 2-year conditional guarantee. However, this standard 2-year warranty can be extended to a 5 year or 10-year conditional warranty dependent on the model type (5 years- Boiler model and Gas models, 10 years- Room heater).
  • Page 38 Paint and Surface Coverings The paint or surface covering of the appliance will be covered (for 2 years after installation) provided the warranty conditions are met. However, damage due to the following events will not be covered: 1. Damage to the paint surface caused by the appliance being stored in a damp and cold environment is not covered under warranty.
