- Page 1 MH202 User guide www.homesystems-legrandgroup.com...
- Page 2 MH202 User guide...
-
Page 3: Table Of Contents
MH202 User guide Index Description of the MH202 Use of the MH202 with Web pages from Personal computer Base functions Scenarios Diagnostics Functions reserved for the “administrator” user Configuration - Device Configuration – Language Troubleshooting The MH202 does not respond to requests via Ethernet (browser, ping, etc.) -
Page 4: Description Of The Mh202
MH202 User guide Description of the MH202 This device can be used to manage up to 300 simple and advanced scenarios. Thanks to the scenario programmer, the system can perform certain actions, not only following a command from the user, but also when external events occur, such as the opening of a door. The execution of an advanced scenario combined with a set time and date, may initiate, for example, the simulation of a presence inside the home by automatically activating the rolling shutters or the lights at certain preset times, when no one is in fact at home. -
Page 5: Use Of The Mh202 With Web Pages From Personal Computer
MH202 User guide Use of the MH202 with Web pages from Personal computer The connection between PC and MH202 is only available for one access at the time. It is therefore not possible to connect several users to the MH202, and therefore to the system, at the same time. Access to the system control pushbuttons is clearly protected by a personal login name and password system. - Page 6 MH202 User guide Example of a Web page: 1. MH202 address 2. MH202 identification name 3. Pushbutton to return to the home page. 4. Icon of the function selected 5. Activation pushbuttons 6. Activation pushbuttons 7. Information and operation area 8.
-
Page 7: Base Functions
MH202 User guide Base functions Scenarios This function can be used to display, activate/deactivate and enable/disable the scenarios configured in the scenario programmer. Note: The confirmation message: Command sent is displayed in the page for each command sent successfully. Diagnostics On clicking on “DIAGNOSTIC”... -
Page 8: Functions Reserved For The "Administrator" User
MH202 User guide Functions reserved for the “administrator” user If accessing the Web page as administrator, the function bar will display the CONFIGURATION box, which includes two pages: • DEVICE • LANGUAGE Configuration - Device In this page the system administrator can configure the login and password for the normal user (Web access), and the Ethernet configuration parameters for access to MH202. -
Page 9: Configuration – Language
MH202 User guide Configuration – Language In this page the administrator user can configure the MH202 Web page display language. The default language is Italian; several other languages are also available. When the language required is selected and confirmed the Web pages will be displayed in the new language. - Page 10 Viale Borri, 231 87045 Limoges Cedex - France 21100 Varese www.legrand.com www.bticino.it Legrand SNC si riserva il diritto di variare in qualsiasi momento i contenuti illustrati nel presente stampato e di comunicare, in qualsiasi forma e modalità, i cambiamenti apportati.
