Page 1 User Manual T3DMM6-5 Digital Multimeter T3DMM6-5-SC Digital Multimeter...
Page 2: Copyright And Statement
Trademark Information Teledyne Test Tools is registered trademark of Teledyne Test Tools. Statement Teledyne Test Tools products are protected by patent laws in and outside ● of the United States of America. Teledyne Test Tools reserves the rights to change the specification and ●...
Page 3: General Safety Summary
Before connecting to the instrument, read the manual to understand the input/output ratings. Do not operate with suspected failures. If you suspect that the product is damaged, contact the Teledyne LeCroy service department immediately. Do not operate in wet/damp conditions. Do not operate in an explosive atmosphere.
Page 4: Safety Terms And Symbols
Use only the fuse specified for the instrument. Use proper over-voltage protection. Use anti-static protection. Operate in an anti-static protected area. Ground measurement cable conductors before connecting to the instrument to discharge any static electricity before connecting the cables to the instrument. Observe ventilation requirements.
Page 5 The following symbols may appear on the instrument: CAUTION WARNING Earth Protective Frame Alternating Risk of Risk of Ground Conductor Standby Current injury or electric Terminal Terminal Chassis Power damage; shock or Terminal refer to burn manual Operating Environment Temperature: 0 °C to 40 °C Humidity: 5% to 90% relative humidity (non-condensing) up to +30 °C.
Page 6 Input terminal protection limitation. Protection limitation is defined for the input terminals: 1. Main input (HI and LO) terminal HI and LO terminals are used for Voltage, Resistance, Capacitance, Continuity, Frequency, Diode and Temperature measurements. Two protection limitations are defined: HI-LO protection limit: 1000VDC or 750AVC.
Page 7 Transient overvoltage: 4000 Vpk WARNING: Voltages above 300 VAC (for T3DMM4-5) or 600 VAC (T3DMM5-5 / T3DMM6-5) can only be measured in circuits that are isolated from mains. However, there may be transient over voltage in circuits that are isolated from mains. The multimeter is able to withstand occasional transient overvoltage up to 4000 Vpk.
Page 8: Daily Maintenance And Cleaning
Daily Maintenance and Cleaning Maintenance When storing or using the instrument, please avoid the liquid crystal display from being exposed for long periods of time to direct sunlight. NOTE: To avoid damage to the instrument or probe, please do not place them in mist, liquid or solvent.
Page 9: Introduction Of T3Dmm6-5
It is available with or without a scanner option (-SC). This manual covers both models with the scanner being covered in a chapter at the back of the manual. All references to the T3DMM6-5 also refer to the T3DMM6-5-SC.
Page 10: Abstract
This manual introduces information on operating the T3DMM6-5 Digital Multimeter. It contains 5 chapters: Chapter 1 Quick Start Guide you to using the T3DMM6-5 Digital Multimeter and information about the Front/Back panel and user interface. Chapter 2 Function and Operation Introduce the functions and operations of T3DMM6-5 in details.
Page 11: Table Of Contents
Content Copyright and Statement .................ii General Safety Summary ................iii Safety Terms and Symbols ................vii Daily Maintenance and Cleaning..............viii Introduction of T3DMM6-5 ................ix Abstract ......................x Chapter 1: Quick Start ................14 General Inspection ..................15 To adjust the Handle ................. 16 Appearance and Size ................
Page 12 Auto Zero ....................37 AC Filter ....................38 Short-circuit Resistance ................ 39 Gate Time ................... 40 Basic Measurement Functions ..............41 To Measure DC Voltage ................ 42 To Measure DC Current ................ 45 To Measure AC Voltage ................ 48 To Measure AC Current ................ 50 To Measure Resistance ................
Page 13 System Setup ..................81 Acquire ..................... 83 Auto Trigger ..................84 Single Trigger ..................85 External Trigger..................86 Help System .................... 87 Math Function ................... 89 Statistics....................90 Limits..................... 91 dBm....................... 93 dB......................94 Relative Value ..................95 Display Mode .................... 96 Bar Meter .....................
Page 14 Chapter 5: Appendix ................109 Appendix A: Accessories ................ 109 Appendix B: Warranty summary ............110 Appendix B: Contact Teledyne Test Tools ..........111...
Page 15: Chapter 1: Quick Start
Chapter 1: Quick Start This chapter guides users to quickly get familiar with the front and rear panels, user interface and measurement connections of the multimeter. This chapter contains the following topics: General Inspection • Handle Adjustment • Appearance and Size •...
Page 16: General Inspection
Teledyne Test Tools would not be responsible for free maintenance/rework or replacement of the unit. 2. Inspect the instrument. In case of any damage, or defect, or failure, notify your Teledyne Test Tools sales representative. 3. Check the accessories.
Page 17: To Adjust The Handle
To adjust the Handle. Adjust the handle position of the T3DMM6-5 properly, place the instrument in a stable position so that the user can manipulate and observe the display better. Please grip the handle by the two sides and pull it outward. Then rotate the handle to the appropriate position.
Page 18: Appearance And Size
Appearance and Size Diagram 1- 4 Appearance and Size...
Page 19: Front Panel
Front Panel Diagram 1- 5 Front Panel Overview USB Host • By using this interface, users can store the current state or measurement data into a USB storage device. Users can also read the state files or updated firmware from the USB storage device. Power Key •...
Page 20 • Measurement and Assistant Function Keys DC Voltage / Current Measurement AC Voltage / Current Measurement 2-Wire / 4-Wire Resistance Measurement Frequency / Capacitance Measurement Continuity / Diode Test Temperature Measurement / Enable Multiple Scan Card Functions Enable Dual-display Function / Set Up the Utility Acquire Function / Help System Math Function / Display Function Auto Trigger / Stop...
Page 21 • Range and Direction Keys Increase the measurement range Decrease the measurement range Select auto or manual range Set up measurement parameter to Move the cursor page up or down Set up measurement parameter Move the cursor left or right Apply the current setting •...
Page 22: Back Panel
Back Panel Diagram 1- 6 Back Panel Overview Power Socket Please use the power cord provided in the accessories to connect the multimeter to the AC power through this socket. Important Note: The correct voltage range must be selected first (through the Voltage Selector) before power connection.
Page 23 T3DMM6-5-SC instrument. V. USB Device Connect to a PC through the USB interface. You can use SCPI commands or PC software to control the T3DMM6-5 remotely. VI. LAN The multimeter can be connected to the LAN network for remote control.
Page 24 H. Ext trigger Trigger the multimeter by connecting a trigger pulse through the 【 Ext Trig 】 connector. Note the external trigger source must be selected. Current Input Fuse Before leaving the factory the multimeter is installed with a current measurement fuse to provide 10A maximum input protection.
Page 25: Start The Multimeter
1. Make sure the power cord is in properly connected and that the power cord is good and in working condition. 2. Try to restart the multimeter, if it fails, check the power fuse and replace with a new one if necessary. 3. If the problem still remains, please contact Teledyne Test Tools.
Page 26: User Interface
User Interface Measurement Measurement Diagram 1- 9 User Interface...
Page 27: Measurement Connections
Measurement Connections T3DMM6-5 is designed with many built in measurement functions. After selecting the desired measurement function, please connect the signal (device) under test to multimeter according to the method below. Do not switch the measurement function when measuring as it may cause damage to the multimeter.
Page 28 Resistance Measurement (2-wire) Resistance Measurement (4 wire) Capacitance Measurement Frequency/Period Measurement Continuity Measurement Diode Measurement...
Page 29 Temperature Measurement For RTD and thermcouple sensors...
Page 30: To Use The Built-In Help System
To Use the Built-in Help System To access built-in help information please press 【shift 】 +【Acquire】 to enter the help system; then use the direction keys to choose the help item you want, finally press【OK】to obtain help information. The common help information categories are listed as follows: 1.
Page 31: Chapter 2: Function And Operation
Chapter 2: Function and Operation This chapter introduces how to use the functions of the multimeter from the front panel. The chapter contains the following topics: • To Set the Range To Set the Resolution • • Basic Measurement Functions Sensor Measurements •...
Page 32: Measurement Configuration
Measurement Configuration Most measurement parameters are user-defined. Changing a measurement parameter will change the measurement precision and speed, as well as the input impedance. An appropriate measurement parameter based on the actual application will ensure faster measurement or higher measurement precision. The default measurement configurations of the multimeter can ensure the accuracy of the measurement results in most cases.
Page 33: Range
Range T3DMM6-5 provides auto and manual range selecting modes. In auto mode, the multimeter selects a proper range automatically according to the input signal. In manual mode, you can use the front panel key or menu key to set the range.
Page 34 Note: 1. “overload” will be displayed when the input signal exceeds the currently set range. 2. By default, the range is set to Auto at power-on or after a reset. 3. Auto mode is recommended if you are not sure about the measurement range in order to protect the instrument and obtain accurate data.
Page 35: Integration Time And Resolution
The integration time applies to DCV, DCI, 2WR and 4WR measurements. T3DMM6-5 expresses the integration time by the number of power line cycles, the unit is PLC. The multimeter automatically detects the input power line frequency at power-on.
Page 36 Table 2-2 Relationship between reading resolution and integration time Resolution Integration time 4½ 0.005PLC/0.006PLC 0.05PLC/0.06PLC 5½ 0.5PLC/0.6PLC 6½ 1PLC 10PLC 100PLC 2. In ACV, ACI ,FREQ/PERIOD measurements, the resolution is fixed at 6½ digits. 3. In CAP measurements, the resolution is fixed at 4½. 4.
Page 37: Dc Impedance
DC Impedance DC impedance applies to DCV measurements. The default is “10MΩ”. In the range of 200mV, 2V or 20V, you can choose “>10GΩ” to reduce the loading error on the measured object, caused by the multimeter load. In the range of 200 mV, 2 V or 20 V under DCV measurement, press 【...
Page 38: Auto Zero
Auto Zero Auto zero (Auto Zero) applies to DCV, DCI, 2WR and 4WR measurements. Enter the specific measurement function and press 【Auto Zero】 in the menu to perform the setting, as shown in Diagram 2-5 (take DCV measurement for instance). Diagram 2-5 Turn on or off Auto Zero ON: the multimeter internally disconnects the input signal and measured •...
Page 39: Ac Filter
AC Filter AC filter applies to ACV and ACI measurements. It can optimize the low- frequency accuracy and minimize the AC settling time. T3DMM6-5 provides three types of AC filters (>3Hz, >20Hz, >200Hz). The AC filter to be used is determined by the input signal frequency. You...
Page 40: Short-Circuit Resistance
Short-circuit Resistance This function only applies to a continuity test. When the measured circuit has a resistance lower than the short-circuit resistance, the circuit is considered as connected and the beeper sounds (if sound is on). The default short-circuit resistance is 50Ω and the setting is stored in non-volatile memory. When continuity test is enabled, set the【Threshold】(equal to short-circuit resistance) using the direction keys.
Page 41: Gate Time
Gate Time Gate time (also called Aperture Time) applies to the FREQ / PERIOD function. It decides the resolution of a low-frequency measurement. The longer the gate time, the higher the resolution of the low-frequency measurement and the slower the measurement, and vice versa. In FREQ / PERIOD measurement, press 【Gate Time】...
Page 42: Basic Measurement Functions
Basic Measurement Functions T3DMM6-5 Digital Multimeter has the following basic functions: Measure DC Voltage • Measure AC Voltage • Measure DC Current • • Measure AC Current • Measure 2/4-Wire Resistance Measure Capacitance • Test Continuity • Test Diode •...
Page 43: To Measure Dc Voltage
To Measure DC Voltage Range: 200mV, 2V, 20V, 200V, 1000V Max Resolution: 100nV (in the range of 200mV) Input Protection: 1000 V protection is available on all ranges and a 10% over-range for all ranges except 1000 V range. If the reading exceeds the range, “overload”...
Page 44 3. Set the range Press【Range】to select a range for the measurement. You can also use , and keys on the front panel to select the range. Auto (autorange) automatically selects the range for the measurement based on the input. Autoranging is convenient, but it results in slower measurements than using a manual range.
Page 45 7. Set the relative value (Optional operation) Press【Rel】to start or stop the Relative math function. When it is started, the reading displayed is a value which comes from the result of actual measurement value minus the relative value that has been set. The default relative value is the measurement value when the function is started.
Page 46: To Measure Dc Current
To Measure DC Current Range: 200μA, 2mA, 20mA, 200mA, 2A, 10A Max Resolution: 0.1nA (in the range of 200μA) Input Protection: a 10A protection fuse is available in all ranges and a 10% over-range for all ranges except 10A range. If the reading exceeds the range, “overload”...
Page 47 3. Set the range Press【Range】to select a range for the measurement. You can also use , and keys on the front panel to select the range. Auto (autorange) automatically selects the range for the measurement based on the input. Autoranging is convenient, but it results in slower measurements than using a manual range.
Page 48 7. Read the measurement value The multimeter measures the input signal according to the current measurement settings and displays the measurement result on the screen. 8. Perform math operations (advanced) You can perform math operations (Statistics, Limit and REL) on every DCI measurement reading.
Page 49: To Measure Ac Voltage
To Measure AC Voltage Range: 200mV, 2V, 20V, 200V, 750V Max Resolution: 100nV (in the range of 200mV) Input Protection: 750V protection is available in all ranges and a 10% over- range for all ranges except 750V range. If the reading exceeds the range, “overload”...
Page 50 4. Set the filter Press【Filter】and choose the filter for the measurement. The instrument provides three different AC filters, “>3Hz”, “>20Hz” and “>200Hz”. You should generally select the highest frequency filter whose frequency is less than that of the signal you are measuring. 5.
Page 51: To Measure Ac Current
To Measure AC Current Range: 200μA, 2 mA, 20 mA, 200 mA, 2A, 10A Max Resolution: 0.1nA (in the range of 200μA) Input Protection: 10A protection is available in all ranges and a 10% over-range for all ranges except the 10A range. If the reading exceeds the range, “overload”...
Page 52 4. Set the filter Press【Filter】and choose the filter for the measurement. The instrument provides three different AC filters, “>3Hz”, “>20Hz” and “>200Hz”. You should generally select the highest frequency filter whose frequency is less than that of the signal you are measuring. 5.
Page 53: To Measure Resistance
Over-range for all ranges. If the reading exceeds the range, “overload” will be displayed. T3DMM6-5 provides 2-wire and 4-wire resistance measurements. When the measured resistance is lower than 100kΩ, the 4-wire resistance measurement is recommended to reduce the measurement error caused by the test lead resistance and contact resistance between the probe and the testing point.
Page 54 Press on the front panel to enter the 4-wire resistance measurement interface, as shown in Diagram 2- 14. Diagram 2- 14 4 Wire Resistance Measurement Interface 2. Make the connection Connect the test leads with the measured signal by referring to “Measurement Connections”.
Page 55 5. Autozero setting Press 【Auto Zero】to enable or disable this function. Autozero provides the most accurate measurements, but requires additional time to perform the zero measurement. With autozero enabled (On), the DMM internally measures the offset following each measurement. It then subtracts that measurement from the preceding reading.
Page 56: To Measure Capacitance
To Measure Capacitance Range: 2nF, 20nF, 200nF, 2μF, 20μF, 200μF, 2mF, 20mF, 100mF Max Resolution: 1pF (in the range of 2nF) Input Protection: 1000V protection is available in all ranges. If the reading exceeds the range, “overload” will be displayed. Operating Steps: 1.
Page 57 4. Set the relative value (Optional operation) Press 【Rel】 to start or stop the Relative math function. When it is started, the reading displayed is a value which comes from the result of actual measurement value minus the relative value that has been set. The default relative value is the measurement value when the function is started.
Page 58: To Measure Frequency Or Period
To Measure Frequency or Period Frequency (Period) Range: From 3Hz to 1MHz (from 0.33s to 1μs). Input Signal Range: 200mV, 2V, 20V, 200V, 750V. Input Protection: 750V protection is available in all ranges. Operating Steps: 1. Enable the Freq/Period measurement on the front panel, then select 【Freq】...
Page 59 3. Set the range Press 【Range】to select a range for the measurement. You can also use the , and keys on the front panel to select the range. Auto (autorange) automatically selects the range for the measurement based on the input. Autoranging is convenient, but it results in slower measurements than using a manual range.
Page 60: To Test Continuity
To Test Continuity Test Current Source: 1mA Max Resolution: 0.01Ω Input Protection: 1000V Input Protection Open-circuit Voltage: <8V Beep Threshold (short-circuit resistance): from 0Ω to 2000Ω This function measures the resistance of the circuit with about 1mA current source. When the measured resistance is lower than the short-circuit resistance (Threshold), the beeper sounds (if the Beeper is on).
Page 61 3. Set the short-circuit resistance (Threshold) Enter a desired value using the direction keys. The range is from 0Ω to 2000Ω and the default is 50Ω. 4. Read the measurement value The multimeter measures the input signal according to the current measurement settings and displays the measurement result on the screen.
Page 62: To Test Diode
To Test Diode Test Current Source: 1mA Voltage Measurement Range: 0V~4V Max Resolution: 10μV Input Protection: 1000V Input Protection Open-circuit Voltage: <8V This function measures the forward voltage drop on the diode. When the voltage is lower than the Threshold, the beeper sounds (if the beeper is on). Operating Steps: 1.
Page 63 4. Read the measurement value The multimeter measures the input signal according to the current measurement settings and displays the measurement result on the screen. If the reading exceeds the threshold, “open” will be displayed. 5. Evaluate the results of a measurement Reverse the probes and measure the forward voltage drop on the diode again.
Page 64: To Measure Temperature
To Measure Temperature T3DMM6-5 can directly measure the temperature using TC (Thermocouple) and THERM (Thermistor) sensors. Operating Steps: 1. Enable the Diode measurement Press on the front panel to enter the Temperature measurement interface, as shown in Diagram 2- 20.
Page 65 3. Set the type of sensor Press 【 Load 】 and use the direction keys to choose a desired temperature sensor. Press 【Define】to view the configurations. Then press 【Read】 to apply the current temperature sensor configurations. Diagram 2- 21 Load a Configuration File 4.
Page 66 5. Set the unit of temperature Press 【 Units 】 to choose the unit of temperature. The Multimeter supports three units: °C ,°F , °K. Diagram 2- 23 Unit Selection Interface 6. Set the relative value (Optional operation) Press 【Rel】 to start or stop the Relative math function. When it is started, the reading displayed is a value which comes from the result of actual measurement value minus the relative value that has been set.
Page 67: Dual-Display Function
Dual-display Function Dual-display function is used to improve the test and measurement functions. Press to open the Dual-display function and the upper right corner will show “Dual”. Now press a function key if this function can be used as the second display, it will be displayed in the second Display area.
Page 68 Instruction: 1. If the same measurement function is used in both Main and second Display. The readings in both displays will update at the same time. • • If math function (dBm, dB) is used in Main Display, when opening the second Display, the math operation will be stopped automatically.
Page 69: Utility Function
Utility Function The Utility function enables users to set up system parameters and interface parameters of the multimeters. Press to enter the operating menu of Utility function, as the following diagram shows. Diagram 2- 24 Utility Function Configuration Interface Table 2- 1 Utility Function Menu Description Function Menu Description Store/Recall...
Page 70: Store And Recall
Store and Recall The Store/Recall function enables users to store and recall the instrument state and data files in the local storage as well as in the USB storage. After 【 Store/Recall 】 to enter the entering the function menu of Utility, press interface as shown in diagram 2-25.
Page 71: Store Settings
Store Settings Store settings allows you to save the system configuration (as .xml) or measurement data (as .csv) into the internal memory or an external USB storage device. After entering into the function menu of Store/Recall, press【Store Settings】to enter the following interface. Diagram 2- 26 Store Settings Interface Table 2- 3 Storage Function Menu Description Function Menu...
Page 72 Operating Steps: 1. Set the storage directory Press 【Browse】to enter the following interface, then use the direction keys or menu operation keys to choose the storage directory. Press 【Select】 to set the current directory as storage location and Return to the higher level menu.
Page 73 The method of inputting a file name: Press direction keys to select a desired character in the input area. • Press “OK” key on the front panel to input selected char in the • input area. Press【Clear All】to clear all input chars. •...
Page 74 Recall Settings Recall settings allows you to read the system configuration from the internal memory or an external USB storage device. After entering the function menu of Store/Recall, press【Recall Settings】to enter the following interface. Diagram 2- 29 Recall Settings Interface Use direction keys or menu operation keys to choose the state file with the suffix “.xml”.
Page 75 Manage File The Manage Files function allows you to create, copy, delete, and rename files and folders in the instrument's internal flash memory or on a USB drive attached to the front panel. It also allows you to capture the current screen to a bitmap (*.bmp) file.
Page 76: I/O Configuration
I/O Configuration Press【I/O Config】to enter the following interface and set up the parameters. Diagram 2- 31 I/O Configuration Interface LAN Settings The Multimeter enables users to operate the instrument remotely by LAN interface and store or recall internet settings. You can look over current LAN settings and set up an IP address and subnet mask.
Page 77 Table 2- 4 LAN Settings Function Description Menu IP Address Set up IP address. Subnet Mask Set up subnet mask. Gateway Set up gateway Cancel Cancel current operation and return to the higher level menu. Done Save all changes and return to the higher level menu.
Page 78: Board Test
Board Test T3DMM6-5 provides self-test functions, including Key Test, LCDTest, Beeper Test and Chip Test. Operating Steps: 1. Press , then choose【Test/Admin】→【Board Test】to enter the following interface. Diagram 2- 34 Board Test Interface Table 2- 5 Board Test Function Description...
Page 79 Diagram 2- 35 Key Test Interface Before testing the keys the key shapes on the screen will be displayed in a blue colour. The on screen keys and knobs will change to a green colour when tested. Press [Done] to exit the test. 3.
Page 80 4 . Test the beeper. Press【Beeper】to test the beeper. Under regular circumstances, press 【 Beeper】 one time and the instrument will beep one time. 5 . Test the chips. Press【Chip】→【Start】to enter chip test interface, as Diagram 2- 37 shows. Diagram 2- 37 Chip Test Interface NOTE: If the test is passed, the corresponding result shows “pass”.
Page 81: Firmware Update
Firmware Update The software of the Multimeter can be updated directly via a USB flash drive, updating the current software version to the desired software version. Operating Steps: 1. Copy the update file to the USB flash drive. 2. Insert the USB flash drive to the USB host interface on the front panel of the Multimeter.
Page 82: System Setup
System Setup Press , then select【System Setup】to enter the following interface. Diagram 2- 38 System Setup Interface Table 2- 6 System Settings Menu Description Function Menu Description Language Select the display interface language. Firmware Update Update software version. Screen Set up the screen protection function. System Info View system information.
Page 83 3. View system information. Press 【 System Info 】 to view system information, including start-up times, software version, hardware version, production ID and serial number, as shown in the following diagram. T3DMM6-5 012345C6789 Diagram 2- 39 System Information...
Page 84: Acquire
Acquire Sampling is a process of acquiring and digitising a signal. The optional Trigger methods of the Multimeter include Auto Trigger, Single Trigger and External Trigger. Press to enter the interface shown as the following diagram: Diagram 2- 40 Acquire Interface Table 2- 7 Function Menu of triggering parameter Function Menu Description...
Page 85: Auto Trigger
Auto Trigger Auto Trigger parameters that need to be set up include delay, samples/trigger and VMC out. Operating Steps: 1. Press , then select【Trg Src】→【Auto】or press on the front panel directly to enable Auto Trigger. 2. Set the delay. Delay is the waiting time after the trigger signal is sent out and before the acquiring starts.
Page 86: Single Trigger
Single Trigger Single Trigger parameters that need to be set up include delay, samples/trigger and VMC out. Operating Steps: , then select 【Trg Src】→【Single】or press 1. Press on the front panel directly to enable Single Trigger. 2. Set the delay. Press【Delay】to select Auto or Manual mode.
Page 87: External Trigger
External Trigger The external trigger signal will be input via EXT TRIG interface on the rear panel. External trigger parameters that need to be set up include delay, samples /trigger, slope and VMC out. Operating Steps: , then select 【 Trg Src 】 → 【 Ext 】 to enable the External 1.
Page 88: Help System
Help System T3DMM6-5 provides a powerful built-in help system. You can recall help information at any time whilst using the instrument. You also can get a functionality help for every button on the front panel or menu soft key by using the built-in help system.
Page 89 6. Saving and Recalling Information. Introduction of how to store and recall the data/parameter/sensor files. 7. Optional Scanner Card. Get help about operating the optional scanner card (T3DMM6-5-SC only). 8. The convention and Tips of Soft Key usage. Get help and tips about using the soft keys.
Page 90: Math Function
Math Function The Multimeter provides five math functions: Statistics, Limits, dBm, dB and Relative. Choose different math functions to meet different measurement needs. Math functions can only be used in DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Period and Temperature measurement.
Page 91: Statistics
Statistics There are many kinds of reading statistic functions, including: Max, Min, Average and Standard deviation. Press →【Statistics】→【Show】to enter the interface shown in the following diagram. Diagram 2- 43 Statistics Table 2- 10 Statistic Measurement Menu Function Description Function Settings Description Menu Show the minimum statistics value of current...
Page 92: Limits
Limits Limits function is available to indicate signals beyond ranges according to the upper and lower parameters. The following are some measurement functions which are able to do a limit operation: DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Period, Capacitance and Temperature. →...
Page 93 1. How to Set Limits Select【High】,【Low】,【Center】or【Span】 and then switch to the needed digit using the Left or Right Direction keys and input the numerical value by selecting the Up and Down Direction keys. 2. Unit The unit of Limits is decided by the current measurement function. 3.
Page 94: Dbm
The dBm function is logarithmic and based on a calculation of power delivered to a reference resistance, relative to 1 milliwatts. This function only applies to an AC voltage and DC voltage measurements. Press →【dB/dBm】→【On】and select【Function dBm】to enter the interface shown in the following diagram. Diagram 2- 45 dBm Function Interface Table 2- 12 dB Measurement Function Menu Function Description Function...
Page 95 Each dB measurement is different between the input signal and a stored relative value, with both values converted to dBm. The dB function applies to AC voltage and DC voltage measurements only. → 【 dB/dBm On 】 and select 【 Function dB 】 to enter the interface Press shown in the following diagram.
Page 96: Relative Value
Relative Value Relative value is used for relative measurements. Actual measurement reading is the difference between measurement value and preset value. The Multimeter Relative Value is available for the following measurement parameters: DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Period, Capacitance and Temperature.
Page 97: Display Mode
Display Mode The Multimeter supports four types of views for measured data: “Number”, “Bar Meter” ”Trend Chart” and “Histogram”. Number Press to open the menu of display mode and press 【Display】to enter the following interface. “Number” is always the selected mode when the Multimeter is turned on.
Page 98: Bar Meter
Bar Meter Operating Steps: 1. Press【Bar Meter】to enter Bar Meter display mode. Diagram 2- 48 Bar Meter Display Mode 2. Press 【 Horizontal Scale 】 to set the vertical scale as Defaultor Manual mode. Table 2- 15 To Set the Vertical Scale of Bar Meter manually Function Menu Description Set the low value of horizontal scale.
Page 99: Trend Chart
Trend Chart Operating Steps: 1. Press【Trend Chart】to enter the Trend Chart display mode. Diagram 2- 49 Trend Chart Display Mode Table 2- 16 Trend Chart Display Mode Function Menu Description Display Trend The current select display mode is Trend Chart. Recent All Show recent or all readings.
Page 100 Press【Manual】and you can set the vertical scale manually, as displayed in diagram 2- 51. Diagram 2- 51 Manual Vertical Scale...
Page 101: Histogram
Histogram Operating Steps: 1. Press【Histogram】to enter the Histogram display mode. Diagram 2- 52 Histogram Display Mode Table 2- 17 Histogram Display Mode Function Menu Settings Description Display Currently selected display mode is Histogram Histogram. Binning Set Binning as Auto or Manual mode. Bin Set Set the Bin parameters.
Page 102 Table 2- 18 Bin Set Function Settings Description Menu Num. Bins Set the number of Bins, 10, 20, 40, 100, 200 or 400 selected. Set the low value of the horizontal scale. High Set the high value of the horizontal scale. Center Set the center value of the horizontal scale.
Page 103: Trigger
Trigger The Multimeter supports the Trigger function. Press on the front panel to trigger the Multimeter by Auto or Single mode. Auto trigger is considered as a default when the power is initially turned on. Auto Trigger Press on the front panel one time and the Auto Trigger will be started to capture continuous readings automatically.
Page 104: Hold Measurement Function
Hold Measurement Function Hold Measurement function provides users with a stable reading on the screen of the front panel. When the test leads are disconnected, the reading is still held on the screen, which enables users to view the measured history data. Press to open Hold measurement function interface, the black field just above the screen will show “·Probe Hold”, as shown in the following...
Page 105: Chapter 3: Measurement Tutorial
Chapter 3: T3DMM6-5-SC Scanner Card Product Overview The T3DMM6-5-SC scanner is a multiplexer that provides multi-point measurement capabilities to the T3DMM6-5-SC multimeter digital multimeter. The scanner features 12 multi-purpose + 4 current channels and supports the following measurement functions: DCV, ACV, DCI, ACI, 2WR, 4WR, CAP, FREQ, DIODE, CONT and TEMP (RTD and Thermocouple).It provides a convenient and versatile solution...
Page 106 It provides a convenient and versatile solution for test applications that require multiple measurement points or signals and is an ideal tool for R&D burn-in and production testing. The scanner option is not available separately for the T3DMM6-5 or as an upgrade for the T3DMM6-5.
Page 107 1.Operations WARNING The T3DMM6-5-SC scanner is not designed to be “hot swappable”. Remove power from all inputs and turn the instrument power off before installation or removal of the scanner card. Hot swapping the card could cause damage and is not covered under the warranty.
Page 108 5.Insert the Scanner 6.Power On Insert the scanner bottom-side-up. Close the cover by tightening the screws. Connect the power cord and turn On the power ① ② 2.Application of 16 Channels (1) 2-Wired Application (DCV/ DCI/ ACV/ ACI 2WR/ 4WR/ CAP/ FREQ/ DIODE/ CONT / TEMP) Remarks：[1] CH1 to CH12 can be used to measure DCV /ACV/ 2WR/ 4WR/ CAP/ FREQ/ DIODE/ CONT / TEMP.
Page 109 Scanner Function Menu Function Menu Settings Description Mode Scan/Step Set the operation mode Time 0ms~999.999s Sets the duration between each scan loop (Scan mode) or between each scanned channel (Step mode) Cycles Auto/Man Sets the number of scan operations Channel Setup Sets the scanned channel range, measurement function, and measurement parameters Start On/Off...
Page 110 The scanner function provides two measurement speeds: Fast (50 reading/s = 20ms / reading) and Slow (5 reading/s = 200ms / reading). (Fast: 1PLC, Slow: 10 PLC for T3DMM6-5-SC) The speed setting is applicable for the following functions: DC/AC Voltage (DCV/ACV), 2/4...
Page 111 6.Start scan operation Set the [Start] to on to start the scan operation The upper part of the interface displays the function, range, and result of the current channel. The table below records the measurement result of each channel. 7.Enter trend chart and statistics mode (optional operation) Press to open trend chart and statistics function.
Page 112 Remote operations The T3DMM6-5-SC series can be controlled remotely by using the EasyDMM software. It allows users to easily select the measurement function and range for each channel and start acquiring measurement data. With a rich online help system, the user is able to create a virtual instrument on the PC for data collection and instrument control.
Page 113: True Rms Ac Measurement
Chapter 4: Measurement Tutorial True RMS AC Measurement The AC measurement of the Multimeter has a true RMS response. The power dissipated in a resistor within a time is proportional to the square of the measured true RMS voltage, independent of waveform shape. The instrument can accurately measure true RMS voltage or current, as long as the waveform shape contains negligible energy above the effective bandwidth.
Page 114: Crest Factor Errors (Non-Sinusoidal Inputs)
Crest Factor Errors (non-sinusoidal inputs) A common misconception is that "since an AC Multimeter is a true RMS, its sine wave accuracy specifications apply to all waveforms." The shape of the input signal can dramatically affect measurement accuracy. A common way to describe signal wave shapes is “crest factor”.
Page 115: Loading Errors (Ac Voltage)
Loading Errors (AC Voltage) In the AC Voltage function, the input of T3DMM6-5 appears as a 1MΩ resistance in parallel with 100pF of capacitance. The test lead that you use to connect signals to the Multimeter will also add additional capacitance and loading.
Page 116: Chapter 4: General Troubleshooting
The following is a list of issues that may arise while using the Multimeter and its solutions. Please use the corresponding steps when troubleshooting. If you are still unable to resolve, please contact Teledyne Test Tools. ➢ If the screen of the Multimeter is still dark with nothing displayed after pressing the power key: 1.
Page 117 3. Check if the capacity of the used USB disk is too large. The Multimeter is recommended not to use USB disks which exceed 8GB. 4. After restarting the instrument, insert the USB disk again to inspect. 5. If you still cannot use the USB disk properly, please contact Teledyne Test Tools.
Page 118 We suggest that the length of the USB data wire and LAN cable • connected to the instrument should be less than 3m to avoid affecting the product performance. All the accessories are available by contacting your local Teledyne • Test Tools office.
Page 119 Teledyne Test Tools makes no warranty of any kind, express or implied, including without limitation the implied warranties of merchantability and fitness for a particular purpose. In no event shall Teledyne Test Tools be liable for indirect, special or consequential damages.
Page 120 Appendix B: Contact Teledyne LeCroy Teledyne LeCroy (US Headquarters) 700 Chestnut Ridge Road Chestnut Ridge, NY. USA 10977-6499 Phone: 800-553-2769 or 845-425-2000 Fax Sales: 845-578-5985 Email Sales: contact.corp@teledynelecroy.com Email Support: support@teledynelecroy.com (Oscilloscopes, Waveform Generators, Signal Integrity) Web Site: http://teledynelecroy.com/ Phone Support: 1-800-553-2769...
Page 121 © 2018 Teledyne Test Tools is a brand and trademark of Teledyne LeCroy Inc. All rights reserved. Specifications,prices,availability and delivery subject to change without notice. Product brand or brand names are trademarks or requested trademarks of their respective holders.
