- Page 1 T3DMM4-5 / T3DMM5-5 / T3DMM6-5 4½, 5½ and 6½ Digit Digital Multimeters Quick Start Guide Version 1.1 September, 2018 1.800.561.8187 information@itm.com www. .com...
-
Page 2: Table Of Contents
Troubleshooting................24 © 2018 Teledyne LeCroy, Inc. All rights reserved. Teledyne Test Tools is a brand and trademark of Teledyne LeCroy, Inc. Other product or brand names are trademarks or requested trademarks of their respective holders. Specifications, prices, availability and delivery subject to change without notice. -
Page 3: General Safety Summary
Before connecting to the instrument, read the manual to understand the input/output ratings. Do not operate with suspected failures. If you suspect that the instrument is damaged, contact the Teledyne LeCroy service department immediately. Do not operate in wet/damp conditions. - Page 4 Safety Terms and Symbols The following terms may appear on the instrument: DANGER: Direct injury or hazard may occur. WARNING: Potential injury or hazard may occur. CAUTION: Potential damage to instrument/property may occur. CAT I (1): IEC Measurement Category I, applicable for making measurements on ‘other’...
- Page 5 Operating Environment Temperature: 0 °C to 40 °C Humidity: 5% to 90% relative humidity (non-condensing) up to +30 °C. Upper limit derates to 50% relative humidity (non- condensing) at +40 °C. Altitude: ≤ 2000 m Use indoors only. Pollution Degree 2. Use in an operating environment where normally only dry, non-conductive pollution occurs.
- Page 6 Input Terminal Protection Limitation Protection limitation is defined for the input terminal. 1. Main Input (HI and LO) Terminals HI and LO terminals are used for Voltage, Resistance, Capacitance, Continuity, Frequency, Diode and Temperature measurement. Two protection limitations are defined: HI-LO protection limitation: 1000 VDC or 750 VAC.
- Page 7 The multimeter is capable of making measurements with the HI and LO inputs connected to mains in such devices (≤ 300 VAC for T3DMM4-5 and ≤ 600 VAC for T3DMM5-5/T3DMM6-5) or to the branch outlet itself. However, the HI and LO terminals of the multimeter can’t be...
- Page 8 Max. rated input voltage: 1000 Vrms Transient overvoltage: 4000 Vpk WARNING: Voltages above 300 VAC (for T3DMM4-5) or 600 VAC (T3DMM5-5 / T3DMM6-5) can only be measured in circuits that are isolated from mains. However, there may be transient over voltage in circuits that are isolated from mains.
-
Page 9: Daily Maintenance And Cleaning
Daily Maintenance and Cleaning Maintenance Protect the liquid crystal display from direct sunlight when storing or using the instrument. NOTE: To avoid damage to the instrument or test leads, please don’t place them in mist, liquid or solvent. Cleaning Regularly clean the instrument and test leads. ●... -
Page 10: General Inspection
It is always good practice to save the shipping container and packaging for use when returning the power supply to Teledyne LeCroy for service or calibration. The consigner or carrier will be responsible for damage to the instrument resulting from shipping. -
Page 11: Dimensions
Dimensions T3DMM4-5: 293.75mm T3DMM5-5: 293.75mm T3DMM6-5: 345.45mm 260.27mm 1.800.561.8187 information@itm.com www. .com Quick Start 9... -
Page 12: Handle Adjustment
Handle Adjustment To adjust the handle position of the Multimeter, grip the handle by the two sides and pull outward. Then, rotate the handle to the appropriate position. Handle Adjustment Horizontal Position Carrying Position 1.800.561.8187 information@itm.com www. .com 10 Quick Start... -
Page 13: Front Panel
Front Panel Front Panel Overview USB Host Users can store the current state or measurement data into a USB storage device. Users can also read the state files or updated firmware from a USB storage device. Power Key Turn the instrument on or off. LCD Display The instrument provides a 4.3 inch high resolution color TFT-LCD display screen with 480*272 pixels that displays the function... - Page 14 Measurement and Assistant Function Keys DC Voltage / Current Measurement AC Voltage / Current Measurement 2-Wire / 4-Wire Resistance Measurement Frequency / Capacitance Measurement Continuity / Diode Test Temperature Measurement / Enable Multiple Scan Card Function Enable Dual-display Function / Set Up the Utility Acquire Function / Help System Math Function / Display Function Auto Trigger / Stop...
- Page 15 Range and Direction Keys Increase the measurement range Decrease the measurement range Select auto or manual range Set up measurement parameter Move the cursor Page up or down Set up measurement parameter Move the cursor Apply the current setting Signal Input Terminals The measured signal (device) will be connected into the multimeter through these terminals.
-
Page 16: Rear Panel
Rear Panel Rear Panel Overview Power Socket The multimeter accepts two types of AC supplies. Please use the power cord provided in the accessories to connect the multimeter to the AC power through this socket. Note: The correct voltage scale must be first selected (through the Voltage Selector) before power connection. - Page 17 Changing the fuse AC Voltage Selector Select the correct voltage scale (110 V or 220 V) for the AC supply used. Inspection card (option) An optional 16-channel Data Acquisition Module can be installed in the instrument. USB Device Connect the PC through this interface. You can use SCPI commands or PC software to control the Multimeter remotely.
- Page 18 Ext Trigger Trigger the multimeter by connecting a trigger pulse through the [Ext Trig] connector. Note the external trigger source must be selected. Current Input Fuse The multimeter is already installed with a current Input fuse to provide 10 A maximum input protection before leaving factory.
-
Page 19: Starting The Multimeter
2. Ensure that the wall socket has power and is turned on. 3. Try to restart the multimeter, if it fails, check the power fuse and replace with a new one if necessary. 4. If the problem still remains, please contact the Teledyne LeCroy service department for help. 1.800.561.8187 information@itm.com... -
Page 20: User Interface
User Interface LAN Status Icon Control Mode Trigger Mode Measurement Function Measuremet Result Range Operation Menu User Interface Display 1.800.561.8187 information@itm.com www. .com 18 Quick Start... -
Page 21: Measurement Connections
Measurement Connections The Digital Multimeter is designed with many measurement functions. After selecting the desired measurement function, please connect the signal (device) under test to the multimeter according to the method below. Do not switch the measurement function when measuring as it may cause damage to the multimeter. For example, when the test leads are connected to the related current terminals, AC voltage measurement should not be used. - Page 22 Resistance Measurement (2-wire) Resistance Measurement (4-wire) Connect the test leads and tested circuit as in the diagram below. The HI terminal and HI Sense should be connected to one end of the DUT. The LO terminal and LO Sense should be connected to the other end of the DUT.
- Page 23 Temperature Measurement Diode Measurement （ For RTD and thermcouple sensors） 1.800.561.8187 information@itm.com www. .com Quick Start 21...
-
Page 24: Connecting To Usb And Lan Ports
Connecting to USB and LAN Ports The Digital Multimeter has LAN and USB I/O ports. Connect to the ports as in the diagrams below: Connect to USB Device Port Connect to LAN Connect to USB Host Port 1.800.561.8187 information@itm.com www. .com 22 Quick Start... -
Page 25: Using The Built-In Help System
Using the Built-in Help System To access the built-in help system, press [Shift] + [Acquire], then use the direction keys to choose the help item you want. Finally, press [ O K ] to obtain help. The help listings are as follows: 1. -
Page 26: Troubleshooting
When you encounter those problems, please resolve them using the following steps. If the problem remains, please contact the Teledyne LeCroy service centre and provide your device Information including serial number. The screen has no display after pressing the power key. - Page 27 USB storage device is no larger than 8G bytes and FAT formatted. 4. Restart the instrument, then insert the USB storage device. 5. If the problem persists, please contact the Teledyne LeCroy service centre. 1.800.561.8187 information@itm.com www.
- Page 28 The Teledyne Test Tools brand expands on the Teledyne LeCroy product portfolio by adding a comprehensive range of test equipment solutions for its customers. The new range of product solutions deliver engineers with a broad range of quality test solutions that enables speed to market product validation and design.
