ACCESSORY (801903/801906) FOR
Thank you for purchasing an Environmental DustTrak™
Aerosol Monitor Wireless Router Accessories
(PN 801903 & 801906). These instructions will help you
quickly install your Wireless Router into the
Environmental Enclosure (PN 8535).
Unpacking the Wireless Router
Accessories
1. Carefully unpack the Wireless Router and Mounting
Kit from the shipping container and verify that all the
items listed in the following table are present.
Qty.
Item Description
1
GL-AR150
Wireless Router
with USB Cable
4" Wireless 1dB
1
Hinged Antenna
12" RJ45 Cable
1
Cat 6
_______________
TSI and TSI logo are registered trademarks of TSI Incorporated.
DustTrak is a trademark of TSI Incorporated.
3M, the 3M logo and Command are trademarks of 3M.
ENVIRONMENTAL ENCLOSURE
Reference Picture
WIRELESS ROUTER
2. Contact
TSI
immediately if items are missing or
broken.
3. The DustTrak model numbers 8530(EP) and
8533(EP), should be installed into the enclosure
prior to starting this installation procedure.
4. Configuration of the wireless router and DustTrak
Ethernet IP address should be completed prior to
starting this installation procedure.
Qty.
Item Description
18" RP-SMA
1
Extension Cable
(Male to Female)
with antenna post
and sealing gland
1
O-ring
3M™
1
Command™
brand Strips 6 PK
8535
INSTALLATION GUIDE
Reference Picture
Advertisement
Related Manuals for TSI Instruments 801903
Summary of Contents for TSI Instruments 801903
-
Page 1: Wireless Router
Thank you for purchasing an Environmental DustTrak™ broken. Aerosol Monitor Wireless Router Accessories (PN 801903 & 801906). These instructions will help you 3. The DustTrak model numbers 8530(EP) and quickly install your Wireless Router into the 8533(EP), should be installed into the enclosure Environmental Enclosure (PN 8535). - Page 2 3. Install the O-ring Tools Needed for Installation into the groove on Adjustable Wrench capable of opening to 1.188” the antenna assembly. Phillips Screwdriver Installing Wireless Router into the Environmental Enclosure 1. DustTrak monitor’s power should be off prior to starting this procedure.
- Page 3 6. Using the nut that was removed in Step 4, attach the 9. Remove the black liner and attach the router to the gland seal to the side of the enclosure. If needed, metal plate inside the enclosure. use an adjustable wrench to apply a small amount 10.
- Page 4 13. Screw the hinged antenna to 15. Power on the the top of the antenna DustTrak Aerosol assembly. Monitor. After two (2) minutes, the red and green LEDs on the wireless router will also be on. 14. Using the adjustable wrench, tighten the compression nut on the outside of the gland to create a water-tight seal between the gland and antenna cable as shown in the picture.
