- Page 1 OVAL GEAR INDICATOR MANUAL Operation Manual...
- Page 2 A. Feature 1. Smart key to lock parameters .And with parameter locking safety feature prevents other people free to modify; 2. Meter with double LED and 6-digital display. multi indicate the operating states; 3. Power supply with 9-36VDC or 90-265VAC; 4.
- Page 3 B. Parameters Supply AC90-250V 50/60Hz(customized for AC/DC24V supply) Power <3W Relays work Mechanical life: 500 million times life Electrical life: 10 million times(Within the rated load) Same Relay capacity 250VAC/3A or 30VDC/5A Para -10 ~ 50 ℃ (no icing);35 ~ 85% RH (humidity) Environment -meters Insulation...
- Page 4 C. Openings Size (Unit : mm) H ×W Body size h×w ×l Panel size Cutting hole a×b 48×96 45.5×90.5×90 46.5×91.5 D. Wiring Note: If this wiring diagram and the actual instrument wiring diagram there is a difference, please press the actual meter wiring diagram.
- Page 6 F. Instructions Code Attributes Explanation Cumulative and Instantaneous value Top Red LED Display Window Alarm Output set Display window Bottom green LED Alarm light.Light when alarm is active OUT （ red） (The timing mode is R , Shiny delay period, the lower the delay time countdown 1.
- Page 7 cursor blink values of increasing upward In normal display, press this key to Reset perform the count or time zero setting Any setting screen, press the key 12+13 Complex composite key to return to the normal display G. Example Item-1: For MD-M2 flow sensor, the sensor K factor is:0.065mL/p To measure instantaneous flow .
- Page 8 Set the instance flow Decimal point ,tap the left key the parameters is flashing ,press the up or down key to set the Decimal point. Item2: MD-M9 test the total flow unit: L Test the Instantaneous flow Unit : L/H The k of M9, K=5.1 ml/p...
- Page 9 6) To press the SET key to set [C-P] the total flow parameters . press the left key the number flashing, press the up or down to set the parameter. If the MD-M9 K=5.1Ml /M, to set the 0.0051 (Unit: L) 7) Press to set the[F-P] To set the instance flow.
- Page 10 Test the Instantaneous flow , UNIT:L/H The K of MD-M12 K=17ml/P 1. Setting Procedure 1) Wiring; (Refer the Wiring) 2) Power on; 3) Press the SET key over 5s ,enter to the setup mode 4) Tap press SET key, rolling down setting the parameters; 5) To set the [C-D-P] Modify the Decimal places.To...
- Page 11 may be 17*60/1000=1.02 (unit: L/M) 8)Press to set the [RAN] Set the instance flow plae of Decimal point ,tap the lefe key the parameters is flashing ,press the up or down key to set the Decimal point.
