- Page 1 Wireless remote control for profi-air 180 / 300 sensor ® Operating instructions DRAINAGE SYSTEMS ELECTRICAL SYSTEMS BUILDING TECHNOLOGY INDUSTRIAL PRODUCTS...
-
Page 2: Table Of Contents
Table of contents 1 General 1.1 Introduction 1.2 Safety 1.3 Symbols used 1.4 Intended use 1.5 Transport and unpacking 1.6 Checking the scope of delivery 1.7 Overview of functions 2 Layout of the wireless remote control 2.1 Front 2.2 Back 3 Putting the wireless remote control into operation 3.1 Synchronisation 3.2 Multiple wireless remote controls... - Page 3 1 General The wireless remote control has The remote control has a wireless connection to the control board of been developed specifically for demanding operators of profi-air the ventilation unit. The range of 180 / 300 sensor ventilation units this control unit inside a building who emphasise innovative opera- (through walls and light ceiling structures) is up to 30 m.
- Page 4 1 General 1.4 Intended use The wireless remote control must units and is only suited for domestic only be used to operate use inside closed and frost-protected profi-air 180 / 300 sensor ventilation rooms. 1.5 Transport and unpacking Please handle the profi-air wireless remote control with utmost care during transport and unpacking.
- Page 5 2 Layout of the wireless remote control 2.1 Front Display Navigation button 2.2 Back Fastening points Open battery compartment Optional USB connection FRÄNKISCHE OI profi-air FB 180 / 300 sensor...
- Page 6 3 Putting the wireless remote control into operation 3.1 Synchronisation The remote control and the ventilation unit must be synchronised in order to be able to communicate. This requires the following steps: Step Procedure Interrupt power supply of the ventilation unit. Open the battery compartment on the back of the remote control and insert the included batteries 2 x 1.5 V AAA).
- Page 7 4 Display overview Operating modes Operating data Info line Time/day Ventilation mode Navigation button The following table provides a short description of the different symbols and buttons of the wireless remote control. The wireless remote control features a power saving function which switches the display off between 11:00 pm and 07:00 am.
- Page 8 5 Navigation button and keystroke combinations The following table provides an overview of the functions of the navigation button and the keystroke combinations. 5.1 Navigation button Button Function Push the “CENTER” button to start the user menu, select a menu item or confirm a setting. Push the “LEFT”...
- Page 9 6 User menu The user menu is used to control the profi-air 180 / 300 sensor ventilation unit. It provides possibilities to set, e.g. operating modes and visualise operating data, filter replacement and error codes. The user menu is set up as follows: Remaining AUTO weekly...
- Page 10 6 User menu Holiday mode The holiday mode can be activated for times when the building is not inhabited. The ventilation unit runs with minimum air exchange in holiday mode (i.e. 2/3 of the time in ventilation mode 1 and 1/3 of the time in ventilation mode 0).
- Page 11 6 User menu 6.2 “Operating data” display field The “operating data” display field displays different operating data depending on the system's current operating mode. The following table shows and explains the individual items. (T3) (T5) Symbol for the ventilation unit (T5) Heat recovery active Summer bypass active (only with profi-air 300 sensor)
- Page 12 6 User menu Filter The triangles of the filter symbol show the remaining life of the filter. If all three triangles are displayed in black, the filter symbol flashes and the filter should be replaced. The filter alarm can be intermitted for 14 days by pushing any button on the wireless remote control. The factory setting for the filter replacement is 180 days.
- Page 13 6 User menu 6.4 “Ventilation mode” display field This display field displays the current ventilation mode. Mode 0 The device is switched off. This function may only be used in exceptional cases, e.g unpleasant odour from outside. After activating speed 0, this will be enabled for 4 hours and switched to speed 3 afterwards. If the system has been switched off over a longer period of time, this causes an increased risk of conden- sation in the pipes, and/or might lead to moisture damage in the building.
- Page 14 7 Fitter menu The fitter menu is used to commission the profi-air 180 / 300 sensor ventilation unit. Push and hold the “RIGHT” button for 10 seconds to activate the fitter menu, the unit symbol starts flashing slowly and the control switches to ventilation mode 3. You can also access the fitter menu by pushing and holding the MANUAL and AUTO buttons at the control unit for 5 seconds.
- Page 15 7 Fitter menu 7.1 SW menu item The menu item displays the software versions of the different components in the info line. Display Description H… Software version of the mainboard in the ventilation unit C… Software version of the integrated control unit F…...
- Page 16 7 Fitter menu 7.3 Fan menu item The following is displayed and can be set under this menu item: display of the current potentiometer setting of the fans in mode 3 (setting on the back of the integrated control unit) display of the current fan speed difference between ventilation modes 1 / 2 / 3 (OFSE) highest gear for the fan in mode 4...
- Page 17 7 Fitter menu 7.4 Summer bypass menu item (only with profi-air 300 sensor) You can set the desired target temperatures for the summer bypass under this menu item: (T3 / set bypass T Symbol for the ventilation unit (T1 / set bypass T Summer bypass active (only with profi-air 300 sensor) Step Description...
- Page 18 7 Fitter menu 7.5 Target values and setting ranges The following table shows the target values and setting ranges which can be adapted using the wireless remote control. Designation Factory setting min. max. Humidity 45 % 35 % 65 % automatic mode (RH %) Summer bypass T 15 °C...
- Page 19 8 Error codes Code Description Extract air fan Supply air fan Summer bypass flap Fresh air temperature sensor (T1) Supply air temperature sensor (T2) Extract air temperature sensor (T3) Exhaust air temperature sensor (T4) Room air temperature sensor (T5) Humidity sensor Fresh air temperature <...
-
Page 20: Weekly Program P1
9 Weekly programs Weekly program P1 Monday – Friday Time / mode Weekend Time / mode Weekly program P2 Monday – Friday Time / mode Weekend Time / mode Weekly program P3 Monday – Friday Time / mode Weekend Time / mode FRÄNKISCHE OI profi-air FB 180 / 300 sensor... -
Page 21: Weekly Program P4
9 Weekly programs Weekly program P4 Monday – Friday Time / mode Weekend Time / mode Weekly program P5 Monday – Friday Time / mode Weekend Time / mode Weekly program P6 Monday – Friday Time / mode Weekend Time / mode FRÄNKISCHE OI profi-air FB 180 / 300 sensor... -
Page 22: Weekly Program P7
9 Weekly programs Weekly program P7 Monday – Friday Time / mode Weekend Time / mode Weekly program P8 Monday – Friday Time / mode Weekend Time / mode Weekly program P9 Monday – Friday Time / mode Weekend Time / mode FRÄNKISCHE OI profi-air FB 180 / 300 sensor... -
Page 23: Weekly Program P10
9 Weekly programs Weekly program P10 Monday – Friday Time / mode Weekend Time / mode Weekly program P11 Monday – Friday Time / mode Weekend Time / mode Weekly program P12 Monday – Friday Time / mode Weekend Time / mode FRÄNKISCHE OI profi-air FB 180 / 300 sensor... - Page 24 Rooted in Königsberg – globally successful! Our facilities in Europe: Königsberg, Germany (headquarters) Bückeburg, Germany Schwarzheide, Germany Okříšky, Czech Republic St.-Leonards-on-Sea, Great Britain Moscow, Russia Yeles/Toledo, Spain Torcy-le-Grand, France Our facilities in Africa: Ebersbach/Fils, Germany Ben Arous, Tunisia Hermsdorf, Germany Casablanca, Morocco Mönchaltorf, Switzerland Milan, Italy...
