BW TECHNOLOGIES GAS/ALERT/MAX
Four Gas Detector with Internal
Sampling Pump
GasAlertMax provides extraordinary cost of ownership
advantages. Training and maintenance costs are mini-
mized through automated calibration, internal plug-in
sampling pump, long-life VersaPak battery power (avail-
able in local stores) and simple, one-button control.
GasAlertMax is powered by two advanced microcon-
trollers and features plug-in electrochemical and catalytic
sensors. High-output audible/visual alarms provide instant
notification.
The large alphanumeric LCD shows real-time gas concen-
trations and the instrument's status at all times. A full-func-
tion self-test verifies sensor, circuitry and battery integrity
and activates the audible/visual alarms each time the
detector is activated. GasAlertMax clearly advises the
hazard present—Low, High, TWA and STEL multi-gas
alarm. Recorded TWA, STEL and Peak exposures can be
displayed on demand.
GasAlertMax satisfies the OSHA safety regulation
CFR1910.146 (Permit Required - Confined Space Entry).
Features:
• Large LCD shows real-time gas concentrations of H2S,
CO, O2 and %LEL
• Internal plug-in pump for remote sampling
• LOW, HIGH, TWA and STEL alarms with adjustable
setpoints
• Equipped with plug-in, replaceable sensors
• Simple, automatic calibration procedure
• Intrinsically safe to U.S. European and Canadian
standards
• Provides 95 dB tone and bright LED indication on
alarm
Ordering Information:
Part No.
GasAlert/Max for:
GAMAX3-4
4-gas, H2S, CO, O2
GAMAX3-3H
3-gas, H2S, O2, LEL
GAMAX3-2
2-gas, O2, LEL
Add suffix for: -DL1 for black box datalogger
-DL2 for user downloadable datalogger
-A to omit VAC charger and batteries
MULTI-GAS DETECTORS
Measuring Range
H2S 0-100 ppm, CO 0-500 ppm, O2 (% by vol) 0-30%, Combustibles
0-100% LEL
H2S 0-100 ppm, O2 (% by vol) 0-30%, Combustibles 0-100% LEL
O2 (% by vol) 0-30%, Combustibles 0-100% LEL
DOOLEY TACKABERRY
Fire and Safety Equipment - Sales/Systems
–372–
• Compact (1.6 x 3.0 x 5.9 in) and lightweight (15.4 oz)
• Runs an entire shift on one Black & Decker
VersaPak™ rechargeable battery (available worldwide)
• Peak values displayed on command
• Full-function self-test of: sensor/battery/circuitry
integrity: and audible/visual alarms
• One VersaPak rechargeable battery, 2-port charger, 10
ft. sampling hose, calibration hose, carrying holster,
and instructions in local languages included
• Vibrating alarm and remote audible/visual alarm (110
dB) accessories available
