ProCast Mio Layout

1
2
3
4
by
1 19mm CAPSULE – 19mm Fixed charge
capsule provides smooth and linear frequency
response.
2 STEEL GRILLE – Steel mesh grille screen
protects the capsule and the minimally
5 intrusive design ensures a linear frequency
response.
6
3 POWER LED – When illuminated the blue LED
Indicates the ProCast Mio is receiving USB bus
power.
4 DIECAST BODY – Heavy duty Zinc die-cast
body provide the microphone with integral
strength that
5 PHONES - 1/8-inch (.35mm) stereo jack for
connecting stereo headphones to monitor the
7
computer output when using in USB mode.
6 USB – Micro USB connector for interfacing with
your PC or Mac.
7 XLR OUT – XLR low impedance balanced
microphone output for connecting to standard
mixer or audio interface.
