Prior Scientific PL220 Manual

Automatic slide oiler

Advertisement

Quick Links

PL220
© Prior Scientific Instruments Ltd., UK
Worldwide distribution
Prior Scientific, Ltd
Prior Scientific, Inc
Cambridge, UK
Rockland, MA. USA
T. +44 (0) 1223 881711
T. +1 781-878-8442
E. uksales@prior.com
E. info@prior.com
Version 2.1 Nov 2014
Automatic Slide Oiler
Manual Version 2.2
Prior Scientific, GmbH
Prior Scientific KK
Jena, Germany
Tokyo, Japan
T. +49 (0) 3641 675 650
T. +81-3-5652-883
E. jena@prior.com
E. info-japan@prior.com
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL220 and is the answer not in the manual?

Questions and answers

Summary of Contents for Prior Scientific PL220

  • Page 1 Jena, Germany Tokyo, Japan T. +44 (0) 1223 881711 T. +1 781-878-8442 T. +49 (0) 3641 675 650 T. +81-3-5652-883 E. uksales@prior.com E. info@prior.com E. jena@prior.com E. info-japan@prior.com © Prior Scientific Instruments Ltd., UK Version 2.1 Nov 2014 Page 1...
  • Page 2: Table Of Contents

    Table of Contents SECTION 1 IMPORTANT SAFETY INFORMATION SECTION 2 UNPACKING & INSPECTION SECTION 3 INSTALLATION IDENTIFYING THE PARTS OF THE PL220 CONTROLLER IDENTIFYING THE PARTS OF THE DISPENSING TIP ASSEMBL. SET UP OF PL220 POSITIONING OF OIL DISPESNSER INSTALLATION OF COM PORT...
  • Page 3 Thank you very much for purchasing this product from Prior Scientific. We are confident it will prove to be a reliable, precise and valuable addition to your microscopy system. Please do take the time to read these instructions before attempting to install and use this product.
  • Page 4: Section 1 Important Safety Information

    Make sure the system in installed so that the front panel power switch is easily accessible. Do not position equipment so that it is difficult to disconnect from power supply. © Prior Scientific Instruments Ltd., UK Version 2.2 November 2015...
  • Page 5 This symbol used on the pump means - Caution refer to accompanying documents. This symbol used on the pump means. DO NOT allow fingers to contact moving parts. © Prior Scientific Instruments Ltd., UK Version 2.2 November 2015 Page 5...
  • Page 6: Section 2 Unpacking & Inspection

    - PL220 Control Box - Oil Reservoir Bottle - Tubing (1m x 1.6mm bore x 1.6mm wall) - USB Cable - RS232 comms cable - Oil Dispenser Assembly © Prior Scientific Instruments Ltd., UK Version 2.2 November 2015 Page 6...
  • Page 7: Section 3 Installation

    INSTALLATION SECTION 3 3.1 Identifying the parts of PL220 Controller. Front Direction of pump travel Pump Prime button Power connector RS232 Power switch © Prior Scientific Instruments Ltd., UK Version 2.2 November 2015 Page 7...
  • Page 8: Identifying The Parts Of The Dispensing Tip Assembl

    3.2 Identifying the parts of Dispensing Tip Assembly. Needle support Top clamp Dispensing tip Vertical support pillar Luer fitting Ankle adjustment locking screw Dispenser locking screw Dispensing tip © Prior Scientific Instruments Ltd., UK Version 2.2 November 2015 Page 8...
  • Page 9: Set Up Of Pl220

    3.3 Set up of PL220 Place the bottle into the location as shown below. Fill the bottle with an appropriate amount of immersion oil. Only use recommended microscope immersion oil. (eg. Cargille Microscope Immersion Oil - Type A) Place the open end of the tubing into the bottle and ensure it is situated close to the bottom of the bottle and immersed in the oil.
  • Page 10: Positioning Of Oil Dispesnser

    It is important to position the Oil Dispensing assembly in a location that allows for the dispensing tips to be positioned over the slide at the load position of the stage. © Prior Scientific Instruments Ltd., UK Version 2.1 Nov 2014...
  • Page 11 The Dispensing tip should be positioned over the slide. To adjust position loosen the appropriate locking screws, and move tip into desired position. See for directions of movement. Adjustment screws © Prior Scientific Instruments Ltd., UK Version 2.1 Nov 2014 Page...
  • Page 12: Installation Of Com Port

    PL220 is identified on the download page. http://www.prioruk.com/downloadcentre/dc_software.html The software should automatically install. Plug in the USB cable to the PL220 and computer, power on the PL220. The COM PORT should automatically be installed and the PL220 should be controllable via the computer.
  • Page 13: Section 4 Software Commands

    = number of microsteps per second when pumping with the PRIME button pushed. A full revolution of the motor is 50,000 microsteps, it is advised to do at least 1 revolution per dispense © Prior Scientific Instruments Ltd., UK Version 2.1 Nov 2014 Page...
  • Page 14 Delivers a specified “a” number of DROPs. Each DROP entails a forward and backwards motion of the pump. (The back movement is to stop oil dripping from the dispensing tip). © Prior Scientific Instruments Ltd., UK Version 2.1 Nov 2014 Page...
  • Page 15: Section 5 Replacement Parts

    REPLACEMENT PARTS SECTION 5 Part No. Description. H407 24v Desk top power supply W4013 Flexible Dispensing Tip W4014 Luer Fitting Screw W4040 Tubing (1m x 1.6 bore x1.6 wall) © Prior Scientific Instruments Ltd., UK Version 2.1 Nov 2014 Page...
  • Page 16: Returns And Repairs

    Prior Scientific PRIOR to returning the product in order to both obtain the best advice and to get an RMA number which is needed for tracking repairs. If you are in North America (USA or Canada) return the product to Prior Scientific Inc (USA); otherwise return to Prior Scientific Ltd (UK).
  • Page 17: Section 7 Technical Specifications

    • Dry weight 6.1Kg • Dimensions (Not including tip support bracket) : 174mm (W) x 130mm (H) x 250mm (D). • Supply voltage 100v to 240v, 50Hz to 60Hz © Prior Scientific Instruments Ltd., UK Version 2.1 Nov 2014 Page...
  • Page 18 DECLCARATION OF CONFORMITY SECTION 8 Declaration of Conformity Prior Scientific Instruments Limited declares that the following product: PL220 Automated Oiler Conforms to the following Directives and Standards Machinery Directive 2006/42/EC EN809:1998 + A1:2009 EN 61010-1:2010 Based upon test report no: PD-00159-02...
  • Page 19 Please feel free to contact us regarding any questions, comments or suggestions. Prior Scientific manufactures a wide range of products designed for a huge range of microscopy applications, from automated systems to illuminators, sample holders, filter wheels, and robotic slide loaders.
