Page 2
Thank you to have chosen our SMARTPHONE, we hope that it will bring satisfaction to you. Nevertheless, for a good use of your Smartphone telephone, we invite you to read the instructions attentively. Please keep this operation instruction with care for future use. SAFETY TIPS Use of wireless hands‐free system (headphone, headset) with a low power DFMake sure the cell phone has a low SAR. Keep your calls short or send a text message (SMS) (instead. This advice applies especially to children, adolescents and pregnant women. Use cell phone when the signal quality is good. ...
Page 3
2. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. 3. Do not use this unit near water such as bathtub, shower or pool. Immersion of this unit in water could cause an electrical shock. 4. Place the unit securely on a stable surface. Serious damage and/or injury may result if the unit falls. 5. Do not cover slots and openings on the unit. They are provided for ventilation and protection against overheating. 6. Install the unit in a place where nobody can walk on. 7. Never push any objects through slots in this unit. This may result in the risk of fire or electric shock. Never spill any liquid on the unit. 8. To reduce the risk of electric shock, do not disassemble ...
Page 4
10. Do not place lighted objects such as candles, cigarettes on the unit. 11. This product contains a rechargeable battery. Note: There is a risk of explosion if battery is incorrectly replaced: the battery must be replaced by an equivalent type. 12. Do not expose the battery to excessive heat such as sunshine, fire, a radiator or similar sources. 13. When this device is used in USB mode, operating ...
Page 5
ADVICES TO REDUCE THE USER'S RADIATION EXPOSURE LEVEL • Hands‐free kits are very popular thanks to the comfort of use they offer. For the sake of prudence, the user is advised to use them as often as possible, especially when the phone is used for frequent and/or lengthy communications. ...
Page 6
to each situation, and to power off your phone when demanded. • Moreover, to avoid any risk of interference, persons wearing electronic implants (pacemakers, insulin pumps, neuro‐stimulators, etc) must permanently maintain a distance of 15 cm between their mobile phone and the implant; the phone must be used on the body side which does not contain the implant. • It is dangerous to use the phone while driving, even with equipment not prohibited by regulations, as accidents may be caused by the ...
CONTENTS KNOWING ABOUT THE PHONE & GETTING STARTED Key description Appearance SIM card Storage card Battery & Charging 1. POWER ON & OFF 2. PHONE 3. INTERNET CONNECTIONS 4. CONTACTS 5. MESSAGES 6. BROWSER 7. CAMERA 8. MUSIC & VIDEO PLAYER 10. GALLERY 11. CLOCK 12. GMAIL 13. FM RADIO 14. FILE MANAGER 15. CONNECTING TO PC TO SAVE FILES 16. BLUETOOTH 17. 1MOBILE MARKET 18. SETTINGS 19. SPECIFICATIONS 7 ...
5) BROWSER 6) USB CONNECTED SYMBOL 7) BLUETOOTH 8) WIFI CONNECTION STATUS 9) BATTERY STATUS 10) CURRENT TIME SIM card The SIM card contains your phone number, service details, and memory for storing phonebook contacts and/or text messages. Inserting the SIM card 1) Take the back cover off. 2) Insert the SIM Card into the SIM Card slot lightly with the corner cutting of the card aligning to the notch of the slot and the gold plate of the card facing download, till the SIM Card cannot be further pushed in. Removing the SIM card Make sure to switch off GSM55 before removing your SIM card. 11 ...
Storage card Use a storage card to store your photos, videos, and music. IMPORTANTE NOTE : If you want to put photos, videos, music, you have to insert TFT card. Inserting the storage card 1) Take the back cover off. 2) Insert the micro SD card into the storage card slot with its gold contacts facing down and push it until it clicks into place. 12 ...
Battery & Charging Charging the battery Before you turn on and start using GSM55, it is recommended that you charge the battery. Only the power adapter and USB cable provided in the box must be used to charge the battery. Do not remove the battery while you are charging it using the power or car adapter. As a safety precaution, the battery stops charging if it overheats. 1. POWER ON & OFF Switching the POWER Button on Press the POWER button off. Switching the power off 1) If the display is off, press the POWER button to turn it back on, then unlock the screen. 2) Press and hold the POWER button for a few seconds. ...
2. PHONE Key Descriptions Power Key In the power‐on state, press this key shortly to allow the mobile phone to enter the sleep state and long to activate the power‐off menu. In the power‐off state, press this key shortly to get no reaction and long to power on. Back Key Return to previous menu Home Key Return to the standby interface. Menu Key Enter the main menu. Volume Key Adjust the volume. Making a phone call Calling using the Dialer Tap at the bottom of the Home Screen to enter the dialer screen. In Dial, when you input ...
Page 15
1) Directly press on the keyboard, and then choose which SIM card you want to use. 2) You can choose to have a call by click the contacts. 3G Call ‐ Both SIM1, SIM2 card slot could support the WCDMA or GSM. ‐ SIM 1 default, when both SIM card inserted, enter the interface of Settings》 More》 Cellular networks 》 Preferred network type 》 Click Enable, 3G service can be freely shift from SIM ...
3. INTERNET CONNECTIONS Data connection When you turn on GSM55 for the first time, it will be automatically set up to use your mobile operator's data connection (if double SIM1 and SIM2 card are inserted).. Enabling data roaming Using data services while roaming may be costly. Check with your mobile operator for data roaming rates before you use data roaming Tap Setting >more >Cellular networks >Data Roaming Wi‐Fi 1) Tap Setting >Wi‐Fi >Turn on Wi‐Fi ...
Page 17
5) Tap Connect. When GSM55 is connected to the wireless network, the Wi‐Fi icon Appears in the status bar and tells you the approximate signal strength. The next time GSM55 connects to a previously accessed secured wireless network, you won’t be asked to enter the key or other security information ...
Network notification in Wi‐Fi settings is enabled, this icon appears in the status bar whenever the phone detects an available wireless network within range. Airplane mode The place where you cannot use the wireless signal, such as aircraft, you have to turn off or turn on fly Mode. Turn flight mode, the title bar would have the icon and have notifications. 4. CONTACTS With the Contacts app, easily manage your communications with your contacts via phone, messaging, email, and social networks. Add a new contact ...
Page 19
Save more number if you want to save more numbers for one contact, please set the number into the phone memory; the SIM card only can save 1 number for one contact To search for a contact Press to search for a contact. There have a search bar on the top of contacts list screen, enter the first few letters of the first or last name of the contact you are searching, matching contacts are displayed. You can also press menu, and then tap Search to open the search bar. Delete contact 19 ...
If you want to delete single contacts, On the single contacts screen,Press to press Delete contact ,and choose the contact at the front & press ok. 5. MESSAGES Create and send a text message You can use Messaging to exchange text messages (SMS) and multimedia messages (MMS) with your friends on their mobile phones. Sending a message 1. ...
the To field. As the information is entered, all matching contacts appear. Touch a suggested contact or multiple contacts as message recipient(s). 3. Touch Enter message to compose your message. Touch menu icon to insert a common phrase. 4. After completing the message, touch Send icon to send your message. Common phrase Common phrases can save your time in editing ...
Page 22
:add page and add page as bookmark, : add page : bookmarks Home Page Tap to choose "Home", or choose what you want. 22 ...
7. CAMERA Please insert micro SD card before using the camera before taking a photo or video, slide your finger on the zoom bar to zoom in or out. Taking photo 1. Tap to taking a photo, before you taking a photo you can do some settings to adjust the camera; tap in the screen, it will appears. You can choose the config setting . 23 ...
Page 24
to shift between the front & rear camera. Slid left the screen, to view all of the photo or video taken 24 ...
Shooting videos 1.Tap d to start shooting video.Press the struction of photo taking to do config setiing. to shift between the front & rear camera. 8. MUSIC & VIDEO PLAYER All songs & Video that you capture on your phone are stored on the storage card 1) Select desired music/video to play from the music/album/artist/playing list. 2) Tap Previous→ Pause → Next icon for operation.
10. GALLERY You can browse all the pictures and videos stored in the phone. 11. CLOCK Alarm Setting You can use Clock to check the time anywhere in the world, set an alarm, tap “clock” and tap 26 ...
Page 28
Clock settings 12. E‐MAIL Mail application provides E‐mail elves, by which you can add new external POP3 or IMAP email account, can use the account of the common web‐based E‐mail service providers such as ® Yahoo! ® Mail Plus, AOL and Microsoft Exchange ActiveSync and etc. Create new POP3 / IMAP E‐mail account 1. Press Home key, then click the label of the application and click E‐mail.。 2. In mail provider selection interface, click Other (POP3 / IMAP). 28 ...
Page 29
Note: If the account type you want is not stored in the mobile phone’s database, the mobile phone will ask you to enter more detailed information. You are suggested to get first all the information related to E‐mail account including send in/send out server settings and etc, and then continue your setting. 3. Input the E‐mail address and password of the E‐mail account, and then click the Next. 4. Input account name and your name, then click Finish. Create other E‐mail account Please carry out any of the following steps: • If you are on the interface of account list, please press Select, then click More > New Account. • If you are in the E‐mail Inbox, please press Select, then click More > New Account. Tip: If you are in the Inbox of a E‐mail account, and you want to return to the menu of account list, please press Select, then click More > Account List. 29 ...
13. FM RADIO When you tap to open FM, please insert earphone first. : Previous saved channel : Next saved channel : Manual search the channel in the front frequency : Manual search the channel in the next 30 ...
frequency : saved as favorites Press to pause or play the radio. 14. FILE MANAGER File manager will copy, cut, delete, rename the documents or the folder in the TF card, it also will share the files, install apk etc. In the main menu or desktop, click the document manager icon to enter into documents manager. 31 ...
15. CONNECTING TO PC TO SAVE FILES Connect the tablet PC to PC and the tablet PC can be used as mobile storage device 1) Connect your mobile phone to the computer with the USB cable. Then the screen will show like this, at the same time the mobile phone is in the state of charging. 2) Slide from the top to the bottom on the screen, then screen will show like this, please always choose the option “Media device (MTP)” Connected as a media device 32 ...
3) Then you may realize the direct copy of the data in the computer. 16. BLUETOOTH With Bluetooth, you can send or receive information from other devices; 1) Tap Setting >Wireless &Networks >Bluetooth on/off 2) Tap Bluetooth. The Bluetooth screen opens. 3) Tap ,it will show Rename, Visibility timeout, Show received files & Advance setting, 3.1. Tap Rename phone. Enter the new name in the dialog box, and then tap 33 ...
Page 34
Rename 3.2. Tap Visibility timeout to choose how long the phone Visibility timeout to other Bluetooth devices 4) When Bluetooth is turned on. The Bluetooth icon appears in the status bar. Your phone can detect other Bluetooth‐enabled devices. 5) Select the desired device & touch to pair. 6)GSM45/2 automatically tries to pair with the Device. 7) If automatic pairing fails, enter the passcode supplied with the desired device If prompted to enter a passcode, try 0000 or 1234, or consult the device documentation to find the passcode. 34 ...
Disconnecting a Bluetooth device 1) Tap Bluetooth. The Bluetooth screen opens. 2) In the Paired devices section, tap the name of the device to disconnect. 3) Tap OK. 17. 1 Mobile Market Same function as play store. You can use it to download the application as well, if you cannot login on play store to download the application successfully. 18. SETTINGS WIRELESS & NETWORKS Set and manage wireless access point. Wi‐Fi (View WIFI network Settings) Blue‐ Turn on/off Bluetooth function tooth Cellular data Select a SIM for data Select which SIM card for Calls call. SIM Cards SMS Select which SIM card for messages send message. Select Select the primary card primary card for use. 35 ...
Page 36
Data Flow data settings and management Usage Airplane Turn on /stop flying mode mode switch virtual private network,a network that uses the VPN internet to transfer information using secure methods You can share your phone’s mobile data connection via USB tethering or Bluetooth Tethering tethering. You can also More… & Portable share your phone’s data hotspot connection with other devices at once, by turning your phone into a portable Wi‐Fi hot spot. you can set mobile networks related options such as Data usage, Cellular Network Mode, Access networks Point Names and Network operators in Mobile Networks. DEVICE Vibrat Vibrate devices Sound General ...
Page 37
e for incoming calls & notific Adjust the volume tion Volum for the ringtone & es notifications & alarm Set your desired ringtone from Android system / ES File Explorer. Remarks: if choose Android system, the ringtone comes Phone ringto from the ne internal‐memory of the phone itself. If choose ES File Explorer, the ringtone comes from the external‐TF card Select silent only Silent Vibrate only Meeting Out‐ Loudest ring & vibrate door Notificatio ...
Page 38
Adjust the brightness of the screen by tapping and Brightness dragging the slider level , and then tapping OK Adaptive Optimize brightness level for brightness available light Wall‐ Wallpaper setting paper Displa Adjust the delay before the y Sleep system automatically hibernates Touch light Set the touch light time Daydream Set screen protection forms Font size Adjust font size interface. Auto‐ Switch orientation rotate automatically when rotating screen the device Cast the screen to the other Cast screen device nearby You could choose to use the Storag Default ...
Page 39
Check the memory & erase SD card SD card Phone Check the memory storage Batter Display battery use data y App Display the application situation in device. PERSONAL You can turn on Wi‐Fi & mobile network Location location, GPS satellites, etc through this function Screen safety Screen protect‐ security Ion setting . Make Password Passwords visible 1. Add or Security delete device Device manager. Administrati 2. Unknown ...
Page 40
Set advanced advanced settings you can open the app by p ainting a alph Gesture Gesture Settigs abet when t settings he screen is locked. Set the default Language language system Set the Keyboard default and input keyboard Language method input method & input and system Speech Voice search Adjust the mouse Mouse/TRAC KPAD pointer speed of movement 1.backup/Data reduction ...
Set and change the time and data in Date & time device. Schedule power Set the schedule time notification on & off You use the Accessibility settings to configure any accessibility plug‐ins Accessibility you have installed on your phone Developers The basic application for developers options This function enables you to view About phone some phone related information 19. SPECIFICATIONS Accessories included ‐ User manual, ‐ USB cable, ‐ Earphone‐ AC adaptor ‐ 1 battery included 41 ...
Page 42
GSM 850 / 900 / 1800 / 1900 BAND WCDMA 2100 SIM card Dual SIM card 5.5 "QHD touch Size panel LCD display LCD Display Capacitive screen Resolution 960X540 PIXELS Memory 4GB 1GB available memory for Internal memory audio‐video‐photo ‐‐‐} Use TF card for more memory USB port USB 2.0 High Speed CPU 1.0GHz Operating system Android 5.1 WIFI Support WIFI Bluetooth, G‐sensor, GSM/GPS, Support WCDMA ,SMS/MMS, Emails, FM, Calendar 1500mAH Lithium rechargeable battery Power Supply 3.7V, DC 5.0V‐‐‐1.0A Earphone Jack 3.5mm Built‐in 2 cameras: ...
Page 43
SAR (Specific Absorption Rate) = Head: 0.292W/Kg = Body: 1.305W/Kg ** The SAR (Specific Absorption Rate) for mobile phones indicates the user's maximum exposure level to electromagnetic waves when used at the ear. According to French regulations, the SAR should not exceed 2W/Kg of bw." We certify that the power supply is used as a device for disconnecting the power distribution network, which should stay easily accessible. DISCLAIMER Features and specifications are subject to change without prior notice. Certain mobile phone features may not be activated by your service provider, and / or their network setting may limit the feature's functionality. Services and some features such as GPRS, email may be dependent on the network, SIM card, as well as on the compatibility of the devices used and content formats supported and may require 43 ...
Page 44
Always contact your service provider for details or help. Talk and standby time is quoted in digital mode and are approximate; battery performance and the signal reception depend on network configuration, signal strength, type of SIM card, operating temperature, features selected as well as voice, data and other application usage pattern. The phones supports Bluetooth, A2DP, in order for Bluetooth devices to communicate with one another, they must utilize the same Bluetooth Profile. The warranty is applicable only for phones; the company is not responsible for any loss or theft. Always use INOVALLEY original Enhancements (including batteries) for safety. The use of any other type may invalidate and approval or warranty applying to the mobile phone and may be dangerous. The phone is designed to operate using Li‐ion batteries approved by the phone manufactures. Using non approved batteries with the phone may result in poor performance and damage to the phone or its enhancements. The display and products visualization here are illustrative purposes only; Display / color of the phone may differ from that shown on the manual. All features, 44 ...
Page 45
functionality and other product specifications are based on the latest available information and are correct at the time of printing; however such product specifications are subject to change without notice. Copyrights are reserved. The unauthorized copying of copyrighted material is not legalized is inimical to the provisions of the copyright laws of France. INFORMATION UNDER E‐WASTE (MANAGEMENT AND HANDLING) 1. Do’s for disposal of product a) Always drop your used electronic products, batteries, and packaging materials after the end of their life in nearest collection point or collection centre b) Separate the packaging material according to responsible waste disposal options and sorting for recycling. c) The battery can easily be removed from the product for recycling. 2. Don’t of disposal of equipment a) Never dump E‐waste in garbage bins or municipal solid waste stream. b) Do not dispose of your product as unsorted municipal waste. c) Do not throw used batteries into household ...
Page 46
waste. d) Do not dispose damaged or leaking Lithium Ion (Li‐Ion) battery with normal household waste. 3. Information on the consequences of improper handling, accidental breakage damage and improper recycling of the end of life product. a) If batteries are not properly disposed of, it can cause harm to human health or the environment. b) Placing of batteries or devices on or in heating devices, such as microwave ovens, stoves, or radiators and improper disposal of batteries may lead to explosion. c) If the battery terminals are in contact with metal objects, it may cause a fire. 46 ...
