- Page 1 FTI-Eb Thermal Imaging Solutions for Furnaces and Boilers Installation Guide Issue 4 30 April 2011 Publication Nº 805502 Language: English © Land Instruments International, 2018...
- Page 2 IMPORTANT INFORMATION - PLEASE READ Health and Safety Information Read all of the instructions in this booklet - including all the WARNINGS and CAUTIONS - before using this product. If there is any instruction which you do not understand, DO NOT USE THE PRODUCT.
- Page 3 Web: www.ametek-land.com For further details on all AMETEK Land offices, distributors and representatives, please visit our website. Return of Damaged Goods IMPORTANT If any item has been damaged in transit, this should be reported to the carrier and to the supplier immediately.
- Page 4 FTI-Eb Fixed Thermal Imaging System Installation Guide...
- Page 5 Installation Guide FTI-Eb Fixed Thermal Imaging System Contents Introduction A1.1 Summary Specifications A1.2 Installing the RS422/485 Serial Communications Card A1.3 Maintenance A1.4 Installation Requirements Installation diagrams Fig. 1 FTI-Eb System Overview Fig. 2a FTI-Eb Rugged Enclosure and Mounting Dimensions Fig. 2b FTI-Eb Rugged Enclosure and Mounting Dimensions Fig.
- Page 6 FTI-Eb Fixed Thermal Imaging System Installation Guide...
- Page 7 Installation Guide FTI-Eb Fixed Thermal Imaging System A1 Introduction This Installation Guide gives instructions on how to the install the Land Fixed Thermal Imaging System with FTI-Eb cameras. The system is operated via the LIPS-FTI-Eb software. These instructions are provided as a series of simple installation diagrams, covering the installation of the FTI-Eb thermal camera and its mountings, accessories and services.
- Page 8 FTI-Eb Fixed Thermal Imaging System Installation Guide A1.1 Summary Specifications Processor FTI-Eb CP: Operating Temp Range: -5 to 50°C / 30 to 120°F Sealing: IP 65 (IP 54 if fitted with optional touchscreen) Power Requirement: 100 to 240V ac 2.0A 50/60Hz Weight: 29kg / 64lb The unit weighs up to 29kg (64lb) and will require at least two...
- Page 9 Installation Guide FTI-Eb Fixed Thermal Imaging System Digital Input via NUDAM 6052 Isolated Digital Input Modules 6 bits isolated digital input VIL: 1V max VIH: 3.5V min (24V max) Impedance 1.2KΩ Isolation 5000V rms Relay Output via NUDAM 6063 Relay Output Module 7 isolated relay outputs Output type: form A...
- Page 10 FTI-Eb Fixed Thermal Imaging System Installation Guide A1.2 Installing the RS422/485 Serial Communications Card The RS422/485 Serial Comms card supplied with LIPS FTI-E for connecting the NUDAM input / outputmodules is the Amplicon 200 series, 9-way standard port. Full installation details for this type of card can be found in the User Manual supplied with the card.
- Page 11 Installation Guide FTI-Eb Fixed Thermal Imaging System • On the port which is connected to the NUDAM input / output modules go into Properties and then Port Settings • Check the box for RS485 Half Duplex • Windows will then ask to restart The connections to the RS422/485 Serial Comms card are made via the 9-way D-type connector.
- Page 12 FTI-Eb Fixed Thermal Imaging System Installation Guide A1.3 Maintenance The body of the camera, mountings and optical tube can be cleaned by wiping with a clean cloth moistened with either water or a mild, neutral detergent. The optical tube front window can be cleaned by wiping with a lens tissue. For stubborn dirt, use a lens cleaner or alcohol on a soft cloth.
- Page 13 Installation Guide FTI-Eb Fixed Thermal Imaging System A1.4 Installation Requirements To ensure safe and reliable operation of the FTI-Eb system the following installation guidelines should be followed: Ensure that the water and air supplies are connected and capable of supplying the correct flow rate.
- Page 14 Fixed Thermal Imaging System Installation Guide Water / Air Requirements: NOTE: Apply to water temperature 25 °C / 77 °F Section A Page 8...
- Page 15 Installation Guide FTI-Eb Fixed Thermal Imaging System B1 Installation diagrams This section of the Installation Guide contains a series of simple installation diagrams, covering the installation of the FTI-Eb thermal camera and its mountings, accessories and services. Section B Page 1...
- Page 16 FTI-Eb Fixed Thermal Imaging System Installation Guide Section B Page 2...
- Page 17 Installation Guide FTI-Eb Fixed Thermal Imaging System Section B Page 3...
- Page 18 FTI-Eb Fixed Thermal Imaging System Installation Guide Section B Page 4...
- Page 19 Installation Guide FTI-Eb Fixed Thermal Imaging System Section B Page 5...
- Page 20 FTI-Eb Fixed Thermal Imaging System Installation Guide Section B Page 6...
- Page 21 Installation Guide FTI-Eb Fixed Thermal Imaging System Section B Page 7...
- Page 22 FTI-Eb Fixed Thermal Imaging System Installation Guide Section B Page 8...
- Page 23 Installation Guide FTI-Eb Fixed Thermal Imaging System Section B Page 9...
- Page 24 FTI-Eb Fixed Thermal Imaging System Installation Guide Section B Page 10...
- Page 25 Installation Guide FTI-Eb Fixed Thermal Imaging System Section B Page 11...
- Page 26 FTI-Eb Fixed Thermal Imaging System Installation Guide Data + Data - Data + Data - Data + Data - Section B Page 12...
- Page 27 PRODUCT WARRANTY Thank you for purchasing your new product from Land Instruments International. This Land manufacturer’s ‘back-to-base’ warranty covers product malfunctions arising from defects in design or manufacture. The warranty period commences on the instrument despatch date from the Land Instruments International Ltd.
- Page 28 • Tel: +44 (0) 1246 417691 • Fax: +44 (0) 1246 410585 Email: land.enquiry@ametek.com • www.landinst.com A M E T E K L a n d , I n c . • 1 5 0 F r e e p o r t R d .
