Time VERSALIFT VST-7500-I Operator's Manual

Aerial device
Hide thumbs
Table of Contents

Advertisement

Quick Links

PLEASE NOTE THE ANSI A92.2 STANDARD AND THE MANUAL OF RESPONSIBILITIES CONTAINS RECENTLY
UPDATED INFORMATION. DEALERS, OWNERS, USERS, OPERATORS, LESSORS AND LESSEES MUST ADHERE TO
THESE UPDATED STANDARDS.
YOU HAVE READ AND UNDERSTOOD ALL INFORMATION IN BOTH
OPERATOR'S AND SERVICE MANUALS, PROVIDED WITH EACH
VERSALIFT.
AND IS THE SOLE PROPERTY OF TIME MANUFACTURING CO.
CONTENTS ARE NOT TO BE DISCLOSED, COPIED, OR REPRODUCED
IN ANY MANNER WITHOUT THE EXPRESSED, WRITTEN PERMISSION
OF TIME MANUFACTURING CO.
Time Manufacturing Co. 7601 Imperial Drive P.O. Box 20368 Waco, Texas 76702 Phone: 254-399-2100 Fax: 254-751-0775
Time Manufacturing Co. reserves the right to improve the design or change specifications at any time without notice.
Operator's Manual
VST-7500-I
Aerial Device
SERIAL NUMBER
29084-05
MANUAL PART NUMBER
ATTENTION:
DO NOT ATTEMPT TO OPERATE THIS VERSALIFT UNTIL
THIS MANUAL CONTAINS CONFIDENTIAL INFORMATION
03/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERSALIFT VST-7500-I and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Time VERSALIFT VST-7500-I

Summary of Contents for Time VERSALIFT VST-7500-I

  • Page 1 IN ANY MANNER WITHOUT THE EXPRESSED, WRITTEN PERMISSION OF TIME MANUFACTURING CO. Time Manufacturing Co. 7601 Imperial Drive P.O. Box 20368 Waco, Texas 76702 Phone: 254-399-2100 Fax: 254-751-0775 Time Manufacturing Co. reserves the right to improve the design or change specifications at any time without notice. 03/17...
  • Page 3 Structural components will carry a lifetime warranty for defects in material and workmanship which existed at the time of initial delivery, wear components are not covered by this statement. This warranty is...

  • Page 5: Table Of Contents

    Storing the Aerial Lift ........................4-8 Lifting Eye ..........................4-9 Manual Jib and Winch Operation ....................4-10 Hydraulic Jib and Winch Operation ................... 4-12 Jib Capacity Determination ....................... 4-12 Emergency Operation Section 5 Daily Visual Inspection Section 6 VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 7: Introduction

    TIME MANUFACTURING, AND IS NOT TO BE Time Manufacturing Company reserves the right DISCLOSED, COPIED, OR REPRODUCED to improve the design or specifications at any time WITHOUT EXPRESSED PERMISSION OF without any obligation to incorporate new features into TIME MANUFACTURING.

  • Page 8: Nomenclature

    Figure 1.1 Model VST-7500-I Nomenclature VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 9 FAILURE TO COMPLY with your REQUIRED RESPONSIBILITIES in the use and operation of the Aerial Device could result in DEATH OR SERIOUS INJURY. DANGER: READ AND UNDERSTAND THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS AERIAL DEVICE. VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 10: Decals

    It is important that the operator and ground personnel read and understand the information on the decals. If any decals are defaced, illegible or lost, they must be replaced. Refer to the “Decal Placement” illustration VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 11 VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 12 VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 13 VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 14: Think Safety

    Practice anticipating accidents and operating hazards. Then determine a corrective course of action to respond to the situation. This habit will sharpen your safety awareness, quicken your reaction time, and prevent many accidents. THINK SAFETY The following sketches illustrate some of the unsafe situations that might occur during the use or operation of the Versalift.
  • Page 15 Avoid dropping tools. Use a hand line to raise unit when the lift is being used to work on or or lower tools to/from the platform. near electrical lines. Stow the booms securely before moving the truck. Stand only on the platform floor. VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 16 Don’t climb out of a raised platform onto poles, etc. Keep the fiberglass booms clean and dry. Foreign substances on the booms conduct electricity. VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 17: What Is Insulated And What Is Not Insulated

    Area 3, Intermediate Structure – This section does not provide insulation. This area includes the lower steel portion of the upper boom, knuckle, and the VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 18: Additional Safety Considerations

    Avoid shock loads. A shock load is caused by jerking a line with a load or a sudden change in rope tension from a light load to a heavy load. Do not contact energized conductors with the VERSALIFT VST-7500-I 2-10 29084-05 03/17...

  • Page 19: Specifications

    (chassis insulating system) is installed over a supplied by Time Manufacturing Company at an rectangular 12 in. x 14 in. (305mm x 355 mm) high additional cost. Consult applicable work practices strength steel section.

  • Page 20: Vst-7500-I Option Specifications

    A magnetic drain plug attracts metal particles from the oil. SLOPE INDICATORS – Slope indicators are required on Versalift units and supplied by Time Manufacturing TWO-SPEED MANUAL THROTTLE CONTROL - Co. Slope indicators shall be installed to indicate Changes the engine/pump speed to give the operator the level of rotation bearing relative to the ground.
  • Page 21 An additional pass in the collector pole that are automatically leveled with the platform. ring is required for each control circuit. This jib provides 1000 lbs. jib capacity in any boom position. VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 22 This jib provides from 900 to 2000 lbs. jib capacity depending on the boom positions. VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 23: Vst-7500-I Dimensional Specifications

    Inner Boom Extension ......................138 in (3.5 m) Rotation ..........................360° continuous Upper Boom Insulation Gap ....................108 in (2.7 m) Lower Boom Insulation Gap ....................24 in (0.61 m) Ambient Temperature Range for Structural Integrity ........-40 to 125°F (-40 to 52°C) VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 24 VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 25 VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 26: Vst-7500-I Vehicle Specifications

    Actual GVWR and GAWR’s should be based on the weight and location of the chassis, body, lift, ballast (if required), accessories, and the payload. The curb weight of the unit will vary based on the rated platform capacity, mounting configuration, frame stiffness, and stability test requirements. VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 27 VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 29: Operation

    They may be engaged by locking the drive shaft degrees (1 foot rise in 12 feet) on units not equipped behind the transmission. If the weight is reduced with outriggers. On units with outriggers, aerial device VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 30: Aerial Lift Operations

    Caution: if an aerial device has set idle for an extended WITHOUT PROPER OUTRIGGER EXTENSION THE length of time (i.e. overnight) operate it from the lower UNIT MAY TIP RESULTING IN DEATH OR controls through its full range of motion several times SERIOUS INJURY.
  • Page 31 “Upper Control Operation” in this section. WARNING: IF THE DESICCANT IS PINK, DO NOT OPERATE NEAR ELECTRICAL Operating Where Electrical Hazards Are Present: HAZARDS. PINK DESICCANT MAY INDICATE It is imperative that the aerial device operator VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 32: Cab Control Operation

    The system is activated Figure 4.2. by pushing and holding the button momentarily to VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 33 CONNECTING OR DISCONNECTING THE HYDRAULIC TOOL HOSES MAY RESULT IN A HIGH PRESSURE HYDRAULIC OIL SPRAY. THIS SPRAY OR MIST CAN PUNCTURE OR BECOME EMBEDDED BENEATH SKIN CONTAMINATE THE EYES. THESE CONDITIONS REQUIRE IMMEDIATE MEDICAL ATTENTION. VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 34: Lower Control Operation

    (over heat) the position. backup pump motor. To stop the engine from the turret, push the toggle To activate the backup pump from the turret, push to “START/STOP” again. Allow the toggle to return to VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 35: Upper Control Operation

    Always relieve the pressure to the tool ports before To operate two or more functions at the same time, connecting or disconnecting the hydraulic tool hoses. VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 36: Storing The Aerial Lift

    To speed up the engine from the upper controls contact with the boom rest pad. The platform will push the plunger knob down once and release it. Unitrol 3-Function Control Panel Figure 4.5 VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 37: Lifting Eye

    Stay clear of the latch as it may DANGER: NEVER EXCEED THE move at any time depending on the hydraulic system RATED LOAD CAPACITY OF THE AERIAL LIFT. pressure. STRUCTURAL DAMAGE OR INSTABILITY MAY RESULT, CAUSING DEATH OR SERIOUS INJURY.
  • Page 38 JIB POLE FOR INSULATION UNLESS THE POLE HAS BEEN RATED, TESTED AND MAINTAINED FOR THE APPROPRIATE LINE VOLTAGE. THE WINCH ROPE IS NOT CONSIDERED INSULATING. IMPROPER USE OF THE JIB POLE OR WINCH ROPE MAY RESULT IN DEATH OR SERIOUS INJURY. VERSALIFT VST-7500-I 4-10 29084-05 03/17...
  • Page 39 ROPE. THE RECOIL FROM ROPE FAILURE OR HEAVY LOAD. SHOCK LOADS MAY CAUSE FALLING OBJECTS CAN CAUSE DEATH OR STRUCTURAL DAMAGE OR INSTABILITY SERIOUS INJURY TO THE OPERATOR OR RESULTING IN DEATH OR SERIOUS INJURY. GROUND CREW. VERSALIFT VST-7500-I 29084-05 03/17 4-11...

  • Page 40: Jib Capacity Determination

    MAXIMUM LIFTING CAPACITY OF THE LIFT OR THE JIB MAY CAUSE EQUIPMENT FAILURE 1. Remove any load from the jib and winch assembly. RESULTING IN DEATH OR SERIOUS INJURY. Never attempt to rotate the jib while under load. VERSALIFT VST-7500-I 4-12 29084-05 03/17...
  • Page 41 1500 lbs capacity. 3. The jib pole tilt decal reads “1000 MAX”. 4. The actual lifting capacity is the smaller of the two capacities determined in steps 2 and 3. Therefore, the actual capacity is 1000 lbs. VERSALIFT VST-7500-I 29084-05 03/17 4-13...

  • Page 43: Emergency Operation

    The speed at which the lower boom drifts down depends on the rate of oil loss. Upper and Lower Cylinder Bleeder Ports Figure 5.3 VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 44 To the outrigger boom interlock selector can be overridden conserve the battery and prevent damage to the to lower the booms and return the operator to the VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 45 (if pump damage may occur. Most hydraulic oils are equipped) or the bleeder ports and manual rotation. flammable and bodily contact with hot oil is VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 46 The aerial lift must then be operated, from the lower controls, through its full range of motion several times. Check the hydraulic oil reservoir level and refill if necessary. VERSALIFT VST-7500-I 29084-05 03/17...

  • Page 47: Daily Visual Inspection

    Torque-Seal Mark In Acceptable Condition functioning properly. Figure 6.1 EXTENSION SYSTEM - While operating the unit from the lower controls, observe the extension system during operation. First, raise the outer/inner VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 48 Replace the winch rope at the first sign of damage or deterioration. Use only non-conductive rope of the size and type specified. WINCH - Verify that the rope coils are spooling evenly. VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 49 CHECKLIST AND RECORD MAINTENANCE AND INSPECTION VERSALIFT VST-7500-I SERIAL NO.______________ VEHICLE NO.______________ Fill in date and initial boxes when each check is made. Refer to Daily Visual Inspection in this section for complete description of checks. Additional copies of this form may be obtained from Time Manufacturing Company.
  • Page 50 VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 51 VERSALIFT VST-7500-I 29084-05 03/17...
  • Page 52 VERSALIFT VST-7500-I 29084-05 03/17...
