Time Versalift SST-37-EIH Operator's Manual

Aerial device
Hide thumbs
Table of Contents

Advertisement

Quick Links

PLEASE NOTE THE ANSI A92.2 STANDARD AND THE MANUAL OF RESPONSIBILITIES CONTAINS
RECENTLY UPDATED INFORMATION. DEALERS, OWNERS, USERS, OPERATORS, LESSORS AND LESSEES MUST
ADHERE TO THESE UPDATED STANDARDS.
YOU HAVE READ AND UNDERSTOOD ALL INFORMATION IN BOTH
OPERATOR'S AND SERVICE MANUALS, PROVIDED WITH EACH
VERSALIFT.
AND IS THE SOLE PROPERTY OF TIME MANUFACTURING CO.
CONTENTS ARE NOT TO BE DISCLOSED, COPIED, OR REPRODUCED
IN ANY MANNER WITHOUT THE EXPRESSED, WRITTEN PERMISSION
OF TIME MANUFACTURING CO.
Time Manufacturing Co. 7601 Imperial Drive P.O. Box 20368 Waco, Texas 76702 Phone: 254-399-2100 Fax: 254-751-0775
Time Manufacturing Co. reserves the right to improve the design or change specifi cations at any time without notice.
Operator's Manual
SST-37/40-EIH
Aerial Device
SERIAL NUMBER
28009-09
MANUAL PART NUMBER
ATTENTION:
DO NOT ATTEMPT TO OPERATE THIS VERSALIFT UNTIL
THIS MANUAL CONTAINS CONFIDENTIAL INFORMATION
09/16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Versalift SST-37-EIH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Time Versalift SST-37-EIH

Summary of Contents for Time Versalift SST-37-EIH

  • Page 1 OF TIME MANUFACTURING CO. Time Manufacturing Co. 7601 Imperial Drive P.O. Box 20368 Waco, Texas 76702 Phone: 254-399-2100 Fax: 254-751-0775 Time Manufacturing Co. reserves the right to improve the design or change specifi cations at any time without notice. 09/16...
  • Page 3 Structural components will carry a lifetime warranty for defects in material and workmanship which existed at the time of initial delivery, wear components are not covered by this statement. This warranty is...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Introduction Section 1 Manual Structure ........................1-1 Additional Manual Features ......................1-1 Nomenclature ..........................1-2 Responsibilities / Safety Section 2 Responsibilities of Dealers, Owners, Users, Operators, Lessors and Lessees ......2-1 Decals ............................2-2 Think Safety ..........................2-6 What is Insulated and What is not Insulated ................

  • Page 7: Manual Structure

    INFORMATION AND IS SOLE PROPERTY OF Time Manufacturing Company reserves the right TIME MANUFACTURING, AND IS NOT TO BE to improve the design or specifi cations at any time DISCLOSED, COPIED, OR REPRODUCED without any obligation to incorporate new features WITHOUT EXPRESSED PERMISSION OF into products previously sold.
  • Page 8 VERSALIFT SST-37/40-EIH 28009-09 09/16...
  • Page 9 RESPONSIBILITIES (for Dealers, Owners, Users, Operator, Lessors and Lessees) DANGER: FAILURE TO COMPLY WITH YOUR REQUIRED RESPONSIBILITIES IN THE USE AND OPERATION OF THE AERIAL DEVICE COULD RESULT IN DEATH OR SERIOUS INJURY. IMPORTANT You are required by ANSI/SIA A92.2 to read and understand YOUR RESPONSIBILITIES before you use or operate the Aerial Device.

  • Page 10: Decals

    SAFETY Only properly trained operators are qualified to the locations of the decals. For your convenience operate the Versalift aerial lift. Operator training these decals are pictured on the following pages as a shall include complete instruction and understanding quick reference for reviewing safety concerns and for of the manufacturer’s manuals, employer’s work providing part numbers when ordering replacements.
  • Page 11 VERSALIFT SST-37/40-EIH 28009-09 09/16...
  • Page 12 VERSALIFT SST-37/40-EIH 28009-09 09/16...
  • Page 13 VERSALIFT SST-37/40-EIH 28009-09 09/16...

  • Page 14: Think Safety

    Then determine a corrective course of action to respond to the situa tion. This habit will sharpen your safety awareness, quicken your reaction time, and prevent many accidents. THINK SAFETY The following sketches illustrate some of the unsafe situations that might occur during the use or operation of the Versalift.
  • Page 15 Stow the booms securely before moving the truck. Maintain safe clearances from electrical power lines and apparatus. The aerial lift does not provide protection from contact or proximity to an electrically charged conductors and another conductor. Whenever tools or equipment are included with the operator in the platform the combined weight must not exceed the rated load capacity.
  • Page 16 Stand only on the platform fl oor. Don’t climb out of a raised platform onto poles, etc. Keep the fiberglass booms clean and dry. Foreign substances on the booms conduct electricity. VERSALIFT SST-37/40-EIH 28009-09 09/16...
  • Page 17 What Is Insulated and What Is Not Insulated Articulated/Telescopic and Articulated Models Area 1, Boom Tip Area – The boom tip area does Area 3, Intermediate Structure – This section not provide insulation. This area includes everything does not provide insulation. This area includes past the insulated section decal* on the upper boom.
  • Page 18 ADDITIONAL SAFETY CONSIDERATIONS Report any unusual occurrence during the operation of the aerial lift that may require repair or adjustment. Keep the work space in the truck bed clean and neat. Avoid parking on soft surfaces. Soft surfaces may suddenly collapse, shift, or sink beneath the truck’s weight.
  • Page 19 Time Manufacturing Company at an provide rigidity. The turret plate is machined fl at additional cost. Consult applicable work practices to support the rotation bearing.
  • Page 20 SLOPE INDICATORS – Slope indicators are LUBRICATION - Non-lube bearings are used at all required on Versalift units and supplied by Time points of motion. The rotation bearing is the only Manufacturing Co. Slope indicators shall be installed component that requires periodic lubrication.
  • Page 21 and unrestricted in either direction. An electric and - This system provides for aerial lift operation at hydraulic collector ring assembly provides a path for effi cient, economical engine idle speeds or faster hydraulic oil and electric signals from the pedestal engine speeds for hydraulic tool operation.
  • Page 22 is available with this option. CHASSIS INSULATION SYSTEM (Lower Boom Insert) - The fi berglass insert provides a insulation gap of 12 in. (305 mm) on the unit. The insert is mounted on the steel boom sections, then adhesive is pumped in under pressure to fi ll all voids. A fi...
  • Page 23 SST-37-EIH DIMENSIONAL SPECIFICATIONS Horizontal Reach .........................27 ft 9 in. (8.5 m) Standard Platform Capacity....................300 lbs. (136 kg) Maximum Platform Capacity....................450 lbs. (204 kg) Outer Boom Lift Eye Capacity ..................... 500 lbs. (227 kg) Height to Bottom of Platform ..................... 37 ft. 0 in (11.3 m) Working Height ........................42 ft.
  • Page 24 SST-37-EIH Platform Travel VERSALIFT SST-37/40-EIH 28009-09 09/16...
  • Page 25 VERSALIFT SST-37/40-EIH 28009-09 09/16...
  • Page 26 SST-40-EIH DIMENSIONAL SPECIFICATIONS Horizontal Reach .........................27 ft 9 in. (8.5 m) Standard Platform Capacity....................300 lbs. (136 kg) Maximum Platform Capacity....................450 lbs. (204 kg) Outer Boom Lift Eye Capacity ..................... 500 lbs. (227 kg) Height to Bottom of Platform .....................40 ft. 0 in (12.2 m) Working Height ........................45 ft.
  • Page 27 SST-40-EIH Platform Travel VERSALIFT SST-37/40-EIH 28009-09 09/16...
  • Page 28 VERSALIFT SST-37/40-EIH 3-10 28009-09 09/16...
  • Page 29 SST-37-EIH VEHICLE SPECIFICATIONS Recommended Chassis Mounting: Frame Section Modulus (per frame rail) ................9.25 in. (152 cm Frame Resisting Bending Moment (per frame rail).......... 333,000 in.-lbs. (37,600 N-m) Cab to Rear Axle Dimension ....................60 in. (1.52 m) With Torsion Bars (Front and Rear) Platform Platform Capacity...
  • Page 30 SST-40-EIH VEHICLE SPECIFICATIONS Recommended Chassis Mounting: Frame Section Modulus (per frame rail) ................9.25 in. (152 cm Frame Resisting Bending Moment (per frame rail).......... 333,000 in.-lbs. (37,600 N-m) Cab to Rear Axle Dimension ....................60 in. (1.52 m) With Torsion Bars (Front and Rear) Platform Platform Capacity...
  • Page 31 VERSALIFT SST-37/40-EIH 3-13 28009-09 09/16...
  • Page 32 VERSALIFT SST-37/40-EIH 3-14 28009-09 09/16...
  • Page 33 OPERATION This chapter provides operators and ground crew prior to operation. Refer to slope indicators provided with recommended aerial lift operating procedures, on the chassis to show whether the aerial device is descriptions and detailed operating information positioned within limits permitted. Slope reduces about the controls at each control station.
  • Page 34 “Hydraulic Oil Recommendation”. outriggers see “Outrigger Controls” in this section. Caution: if an aerial device has set idle for an extended length of time (i.e. overnight) operate DANGER: NEVER OPERATE WITHOUT it from the lower controls through its full range of EXTENDING THE OUTRIGGERS (IF EQUIPPED).
  • Page 35 before initiating any lift movements. It is imperative that the aerial device operator understand the dangers associated with operating If there is any kind of malfunction during this test run, near electrical hazards. Due to the work involved, the shut down the unit immediately. Do not operate the ordinary uses of aerial lift often place the operator, lift again until the problem has been corrected by the others in the platform, and ground crew in the vicinity...

  • Page 36: Cab Control Operation

    POWER LINES AND APPARATUS WILL CAUSE stop system and the throttle control options. When DEATH OR SERIOUS INJURY. the light is lit the toggle switch is energizing these systems. ENGINE START/STOP (Standard) - The engine The accumulation of dirt and moisture on insulated booms degrades the insulation.
  • Page 37 operating procedures for these controls are given in the following text. OUTRIGGER OPERATION - The outriggers (if so equipped) should always be extended to provide stability for the aerial lift. The outrigger controls consist of a control selector and a control valve as shown, Figure 4.2.

  • Page 38: Lower Control Operation

    controls or the lower controls. Also this control serves as the emergency stop for the upper controls. BOOM CONTROL LEVERS - These levers operate the outer boom, inner boom, rotation, and lower boom. PLATFORM LEVELING CONTROL (Optional) - This control activates the hydraulic platform leveling to stow, unstow, or level the platform.
  • Page 39 To operate, push to engage tool power, pull to disengage. Always disengage the tool power before To operate two or more functions at the same time, connecting or disconnecting the hydraulic tool hoses. position the single-stick handle anywhere in an area between the separate paths of the desired functions.
  • Page 40 Stay clear of the latch as it may move at any time depending on the hydraulic system EMERGENCY LOWERING (Optional) - If the aerial pressure.
  • Page 41 It is preferred that the platform be stored in the upright position, preferably with a platform rest under DANGER: NEVER EXCEED THE RATED it to avoid high pressure spikes in the slave cylinder LOAD CAPACITY OF THE AERIAL LIFT. when roading the unit. A platform rest is required if STRUCTURAL DAMAGE OR INSTABILITY CAN the unit is equipped with a platform rotator.
  • Page 43 EMERGENCY OPERATION Emergency operation may be required if an operator (counter-clockwise), with a 9/16 in. wrench, on the is injured or the hydraulic system malfunctions. appropriate holding valve as shown in the following This chapter describes the controls and features fi...
  • Page 44 Crank the engine intermittently at 30 second intervals to conserve the battery. Use D A N G E R :...
  • Page 45 WA R N I N G : C O N TA C T W I T H H O T HYDRAULIC OIL MAY CAUSE SERIOUS BURNS W H I C H R E Q U I R E I M M E D I AT E M E D I C A L ATTENTION.
  • Page 47 DAILY VISUAL INSPECTION This aerial lift is designed to provide years of reliable service with minimum maintenance. A routine preventive maintenance program will assure extended aerial lift service. The operator is responsible for detecting maintenance problems during the daily visual inspection, reporting the need for adjustments or repairs, verifying that maintenance is performed at the suggested intervals, Torque-Seal Mark In Misalignment Condition...
  • Page 48 slave cylinder, hoses, and fi ttings for damage, wear, or foreign objects which may prevent proper operation. Refer to Parts & Assemblies Section of the SST- 37/40-EIH Service Manual for these components. DECALS - Identifi cation, operational, and instructional decals are installed at numerous locations on the Versalift.
  • Page 49 Fill in date and initial boxes when each check is made. Refer to Daily Visual Inspection in this section for complete description of checks. Additional copies of this form may be obtained from Time Manufacturing Company. DATE INSPECT BOOMS FOR TRASH & DEBRIS...
  • Page 50 VERSALIFT SST-37/40-EIH 28009-09 09/16...
  • Page 51 VERSALIFT SST-37/40-EIH 28009-09 09/16...
