REVISION RECORD Description Date Author Initial Revision 10/16/2018 Robert P. TABLE OF CONTENTS Limitations and Installations ............................3 Equipment Limitations: ............................... 3 Airworthiness Limitations: ............................4 Instructions for Continued Airworthiness ........................4 Installation Procedures ............................... 4 Wire Sizes .................................. 5 Removal ..................................
Installation Guide: sales@aeroleds.com Sunspot 36 4313 and 4314 P/N 01-1030-4313 or P/N 01-1030-4314 LED Landing or Taxi light Sunspot 36 4313-H and 4314-H P/N 01-1030-4313-H or P/N 01-1030-4314-H LED Landing or Taxi light with mailto:sales@aeroleds.com built-in pulse recognition mode...
Airworthiness Limitations: The Airworthiness Limitations section is FAA approved and specifies maintenance required under 14 CFR, §43.16 and 14 CFR, §91.403 of the Federal Aviation Regulations unless an alternative program has been FAA approved. There are no new (or additional) airworthiness limitations associated with this equipment and/or installation.
Wire Sizes Reference: AC43.13-1B, Chapter 11, §4 and §5 for appropriate wire sizing and fuse/breaker protection Removal Prepare the aircraft for maintenance: Make sure all switches are in the OFF/NORMAL position, attach maintenance warning tags, pull landing/taxi light circuit breakers. Reference airframe manufacturer’s current maintenance manual to remove any light covers to gain access to lamp assembly(s) and bracket(s).
Wiring Diagrams Wiring Diagram for Single Sunspot with Pulse Photo 2-1 Fuse/breaker should be rated for wire size per AC43.13-1B Wiring Diagram for Single Sunspot Without Pulse Photo 2-2 Fuse/breaker should be rated for wire size per AC43.13-1B 0019-0015 Installation Instructions SunSpot 36-4313_4314 Rev IR Page 6 of 9...
Wiring Diagram for Dual SunSpots with Wig-Wag Photo 2-3 Fuse/breaker should be rated for wire size per AC43.13-1B 0019-0015 Installation Instructions SunSpot 36-4313_4314 Rev IR Page 7 of 9...
Wiring Diagram for Four LED SunSpots with Wig-Wag Photo 2-4 Optional Diode (D1): If all four lights are desired to turn on when landing, place a Diode rated for 15 Amps at 14V between the landing and taxi wires Fuse/breaker should be rated for wire size per AC43.13-1B 0019-0015 Installation Instructions SunSpot 36-4313_4314 Rev IR Page 8 of 9...
Page 9
DO-160E Section Compliance Level A3E3 0019-0015 Installation Instructions SunSpot 36-4313_4314 Rev IR Page 9 of 9...
