- Page 1 WWW.OPTICIS.COM IPVDS-700-ED 4K HDMI IP Video Wall Controller User Manual Doc No. : OIPVDS-180730EN / Rev1.0 - 1 -...
-
Page 2: Table Of Contents
Contents 1. Product Description 1.1 Main features IPVDS-700 Control PC Application 2. Shipping Group 3. System Requirement 4. Exterior Description 5. Feature Description 5.1 Video over IP 5.2 Audio over IP 5.3 USB over IP 5.4 RS232 over IP IR over IP (TBD) 5.6 Supporting Video Resolution 5.7 Supporting Audio Format 6. -
Page 3: Product Description
1. Product Description IPVDS-700-ED, 4K HDMI IP Video Wall Controller, is an integrated control solution that enable to play multi-source of audio/video (such as PC, Media Player, DVD and Blu-ray) on the video wall system and multiple individual displays simutaneously. -
Page 4: Main Features
1.1 Main Features TCP/IP base IP network: Gigabit Ethernet Support up to 4K (3840x2160@30Hz 4:4:4 or 3840x2160@60Hz 4:2:0) input resolution Support up to 4K (3840x2160@30Hz 4:4:4) output resolution Supports Analog/HDMI audio input and output Fast switching time / low video latency Transmits HDMI/DVI video, audio, USB, RS-232, IR signal over IP network Provides HDMI loop-thru port for local display (Up to 4K 60Hz 4:2:0) Provides merge, overlay and split function on multiple video wall layout of PC program... -
Page 5: Shipping Group
2. Shipping Group □ IPVDS-700-ED □ HDMI cable 1.2m □ Mini-USB cable □ HDMI fixing screw General Items IPVDS-700-E Encoder One (1) HDMI male to male cable (1.2m). One (1) Mini-USB Cable for PC. HDMI cable fixing screw, 3-pin terminal block (male) IPVDS-700-D Decoder ... -
Page 6: System Requirement
Requirement: Windows7 or higher 3.5 Power Requirement IPVDS-700-ED supports 802.3af standard PoE (Power-over-Ethernet) and requires support of 802.3af/802.3at Type 1 of network switch. - IPVDS-700-ED is designed to give priority to power adapter when connecting external +5V AC/DC power adapter. - 6 -... - Page 7 4. External Description 4.1 IPVDS-700-E (Encoder) Encoder front panel Encoder back panel Name Description USB IN Connection with PC USB port for Keyboard/Mouse use (HID) L-IN Line input port. Connection with line out audio External IR cable port. IR Tx/Rx (Mode selection). (TBD) Function: * IR over IP, ** IR Guest Mode.
- Page 8 4.2 IPVDS-700-D Decoder Decoder front panel Decoder back panel Name Description L-OUT Line output port. Connection with line-in audio External IR cable port. IR Tx/Rx (Mode selection). (TBD) Function: * IR over IP, ** IR Guest Mode. (TBD) RS-232 RS-232 control port Local keyboard/mouse connection.
-
Page 9: Feature Description
5. Feature Description 5.1 Video over IP IPVDS-700-ED provides matrix and video wall feature with multi-cast connection and IPVDS-Wallcontroller program or API can be provided for this Each encoder and decoder requires to be assigned their own IP address, and each encoder can be connected to single/multiple decoder(s). -
Page 10: Audio Over Ip
5.2 Audio over IP IPVDS-700-E supports audio input of both HDMI Audio and Analog Line In. HDMI/Analog Line In audio will be delivered to decoder by Hot-plug of Analog Line In port. IPVDS-700-D will output delivered audio from encoder through HDMI and Analog Line Out simultaneously. Analog Line In audio gets priority when receiving both HDMI audio and Analog Line In input. -
Page 11: Usb Over Ip
5.3 USB over IP IPVDS-700-ED offers USB Virtual Hub feature which makes USB device connected on decoder (remote site) operates on PC connected with encoder. Supporting devices: HID, storage and more Concurrent connection: 1 encoder x N Decoder <= 5 USB devices Figure 6. -
Page 12: Ir Over Ip (Tbd)
5.5 IR over IP / IR Guest mode (TBD) Figure 8. IR over IP IR over IP: IR signal transmission between encoder ↔ decoder IR Guest Mode: Manage IR input/output signal from control PC 5.6 Supported Resolution Spec Support Interlace mode HDMI 1.4b up to 1080p HDMI 1.4b 2160p 30Hz HDMI 1.4b 3D... -
Page 13: Supporting Audio Format
5.7 Supported Audio Format Audio Format Support Dolby Digital 5.1 ch Dolby Digital Plus Dolby TrueHD DTS 5.1 ch DTS-HD High Resolution Audio DTS-HD Master Audio Linear PCM 2 ch 44.1/88.2/176.4/32/48/96/192 kHz Linear PCM 5.1 ch 44.1/88.2/176.4/32/48/96/192 kHz Linear PCM 7.1 ch 44.1/88.2/176.4/32/48/96/192 kHz - 13 -... -
Page 14: Installation
6. Installation 6.1 Hardware Installation Procedure Important: Follow below steps for installation procedure. If not installed properly, malfunction could happen. Step 1 Unpack the package. Step 2 Turn on PC, display, network switch (L2/L3). Step 3 Turn on the PC for IPVDS-Wallcontroller program and connect LAN cable (Cat5e/CAT6) to the network switch. -
Page 15: Reset And Factory Reset
Step 7 Connect LAN cable (CAT5e/6) from IPVDS-700-E (encoder) to RJ45 port of network switch. Step 8 Connect HDMI cable from IPVDS-700-D (decoder) HDMI OUT port to Display. (Connect keyboard and mouse for remote control.) Important: IPVDS-700-D has to be connected to each of video wall displays in order. Refer to display placement section for more detailed information. -
Page 16: Product Specification
7. Product Specification Description Network TCP/IP based IP network: 1000 Base-T Ethernet with CAT5e/CAT6 Network media * UTP CAT5e, 6 cable Max 100m Jumbo Frame 8,000 Input Resolution Max 3840x2160@30Hz 4:4:4 or 3840x2160@60Hz YCbCr4:2:0 Output Resolution Max 3840x2160@30Hz 4:4:4 Video Wall Up to 256 (16x16, 4x64, 1x256, etc.) Video Wall with multi-sources Virtual IP Matrix Supports Rows by Columns Virtual Matrix with individual displays... -
Page 17: Warranty
Opticis or authorized resellers. To request repair or service from Opticis, customer shall not open the product, nor place any part of IPVDS-700 without assistance from Opticis. Keep serial number sticker on the device. - Page 18 This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
- Page 19 Copyright © Opticis Co., Ltd. All rights reserved. Opticis HQ 7F, 166, Jeongjail-ro, Bundang-gu, Sungnam-si, Gyeonggi-do, 13558 Republic of Korea Tel: +82 (31) 719-8033 Fax: +82 (31) 719-8032 Please visit Opticis website, www.opticis.com or contact tosales@opticis.com techsupp@opticis.com if you need any technical support.
