Section 2 - Specification

2.2 General Specification

Power Output
Prime Power 8kVA (6.4kW)
Power Factor 0.8
Frequency 50Hz
Voltages 230V AC
Engine
Make Kubota
Model D1105
Cylinders 3
8.4kW
Power
Speed 1500 rpm
Oil Qty 5.1 Litres
Starting System Electric Start 12V
12V 58Ah 600CCA
Battery
Maintenance Free
Battery Charger Engine Driven
Alternator
Make Mecc Alte
Model ECO 28 S/4
Related Output 16kVA
Bearings Single
Poles 4
Insulation Lass Class H
IP Rating IP21
Regulation +/- 1%
Base
Material Mild Steel
Paint White
8kVA Diesel Generator 8kVA Diesel Generator
Harrington Generators International
Dimensions
Length
Width
Height
Weight
Fuel
Fuel Type
Tank Capacity
Fuel Consumption
Running Time
Sound Level
Standard Features
Low Fuel Protection
High Engine Temperature Protection
Low Oil Protection
Under/Over Frequency Monitoring
Under/Over Speed Monitoring
Battery Under/Over Volt Monitoring
Automatic Mains Failure activation
Key Start
Hinged Access Doors
Output Connection
230V 32A Socket and 2 16A Sockets
Neutral tied to generator chassis.
Protection
MCB and Earth Leakage RCD on 230V output for
fixed / long term installation use.
12 12
1620mm
796mm
1131mm
577kgs
Diesel
62 litres
4 litres / hour
15.5hr
dB(A) @ 7 meters
Part No: 498-141 Part No: 498-141
