SPECIFICATION AND FEATURES

- Separation distance between measuring transducer units, up to 10 m
- Display control operating temperature range, -10..+55 degree C
- Measurement accuracy, 1%+0.01
- Laser type: Visible red 635-670 nm, <1 mW
- Detector type: CCD, length 30 mm
- Display resolution, 0.01 or 0.001 mm, (1 or 0.1 mil )
- Measuring resolution, 0.001mm
- Electronic inclinometer resolution, 0.1 degree
- Power supply: Rechargeable Li-Ion battery
- Gross weight, incl. carry case,
- Built-in application programs and options:
o horizontal shaft alignment at any shaft position, from 60°, up to 360º, up to 36
readings can be measured; auto sweep mode can be used;
o vertical (flange machine) shaft alignment;
o editable misalignment tolerances;
o setup options;
o soft foot;
o thermal growth;
o shimming simulator to calculate for expected residual misalignment;
3.9 kg
