Summary of Contents for Wido WD040210144
- Page 2 WD040210144 / WD040210180 Thanks for your purchasing a WIDO product. We are confident that you will appreciate the quality of the product and you will be entirely satisfied with your purchase. Please read carefully the user safety and operating instruction on how to operate this product correctly...
- Page 3 WD040210144 / WD040210180...
- Page 4 WD040210144 / WD040210180...
-
Page 5: Component List
COMPONENT LIST 1) Keyless chuck 2) Mode selector ring 3) Gear shifter 4) Spirit level 5) Forward and reverse rotation control lever & trigger lock 6) Double ended bits 7) Battery pack release button 8) Battery pack 9) Variable speed trigger switch 10) Work light 11) Battery charger 12) Charger base... -
Page 6: General Power Tool Safety Warnings
14.4V/18V CORDLESS DRILL & SCREW DRIVER GENERAL POWER TOOL SAFETY WARNINGS: Warning: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"... - Page 7 14.4V/18V CORDLESS DRILL & SCREW DRIVER f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
- Page 8 14.4V/18V CORDLESS DRILL & SCREW DRIVER ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR POWER TOOL: 1) Be sure your battery pack voltage is the same as your tool nameplate voltage. 2) Wear ear protectors when using the tool for extended periods. Exposure to noise can cause hearing loss.
- Page 9 14.4V/18V CORDLESS DRILL & SCREW DRIVER 7) To unplug charger from outlet when you do not use the charger. 8) If the charger supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. SYMBOLE To reduce the risk of injury, user must read instruction manual Warning...
-
Page 10: Technical Data
14.4V/18V CORDLESS DRILL & SCREW DRIVER TECHNICAL DATA: Model WD040210144 WD040210180 Voltage 14.4V D.C. 18V D.C. Battery Ni-Cd Ni-Cd Steel Φ10mm Φ10mm Capacities Wood Φ25mm Φ25mm Wood screw ST5.5×65mm ST5.5×65mm No load speed 0-350 0-350 (/min) High 0-1400 0-1400 Max. Torque 28N.m... - Page 11 14.4V/18V CORDLESS DRILL & SCREW DRIVER OPERATING INSTRUCTIONS NOTE: Before using the tool, read the instruction manual carefully. 1. INTENDED USE This tool is intended for twist into or twist out screw, also suitable for drilling hole in metal, wood, plastic or similar materials.
-
Page 12: Screwdriving Operation
14.4V/18V CORDLESS DRILL & SCREW DRIVER 5. WORK LIGHT Pull the switch trigger to light up the work light. The work light keeps on lighting while the switch trigger is being pulled (See Fig 5). 6. FORWARD AND REVERSE ROTATION CONTROL LEVER 1) This tool has a reversing switch to change the direction of rotation. -
Page 13: Drilling Operation
14.4V/18V CORDLESS DRILL & SCREW DRIVER slowly and then increase the speed gradually. Release the switch trigger as soon as the clutch cuts in (See Fig 10). Note: • Make sure that the driver bit is inserted straight in the screw head, or the screw and /or bit may be damaged. -
Page 14: Troubleshooting
14.4V/18V CORDLESS DRILL & SCREW DRIVER TROUBLESHOOTING 1. If your tool will not operate, change a fresh battery. 2. If the tool doesn’t work properly, check the drill bit for sharpness, replace drill bit if worn. 3. If a fault cannot be rectified, return the tool to an authorized dealer for repair. DISPOSAL OF AN EXHAUSTED BATTERY PACK To preserve natural resources, please recycle or dispose of the battery pack properly. -
Page 15: Explosive View
14.4V/18V CORDLESS DRILL & SCREW DRIVER EXPLOSIVE VIEW... -
Page 16: Part List
14.4V/18V CORDLESS DRILL & SCREW DRIVER PART LIST DESCRIPTION Q’TY DESCRIPTION Q’TY Screw for chuck Planetary gear Inner threaded ring Motor with gear l l a t f i Small steel ball Cylindrical spirit level t i r i c t i Planetary carrier Double ended bit i r r... - Page 20 MADE IN CHINA www.widopt.com Copyright @ WIDO Machinery Co., Ltd. All rights reserved.
