- Page 1 GP-ASACNE6800TTTDA/ GC-4XM2G4 Userʼs Manual Rev. 1001 To reduce the impacts on global warming, the packaging materials of this product are recyclable and reusable. GIGABYTE works with you to protect the environment. 12WE6-4XM2G4-10AR...
- Page 2 Before Installting or Setting up• 安裝或設定前 安装或设置前 • インストールまたはセットアップする 前 に • 설치 또는 설정하기 전에 請用螺絲起子卸下位於轉接卡背 面的六個螺絲，再將外殼移除。 请用螺丝起子卸下位于转接卡背 面的六个螺丝，再讲外壳移除。 ドライバーを使用してアダプター カードの背面から6本のネジを外 し、 バックプレートを取り外します。 Unfasten the six screws from the back of the 나사 드라이버로 어댑터 카드 adapter card with a screwdriver and then remove 뒷면에서...
- Page 3 M2_1/M2_2/M2_3/M2_4 (M.2 Socket 3 Connectors/M.2 Socket 3插座) You can install M.2 PCIe SSDs in the connectors. 您可以安裝M.2 PCIe SSD至這些插座。 您可以安装M.2 PCI-E SSD至这些插槽。 コネクタに M.2 PCIe SSD をインストールできます。 커넥터에 M.2 PCIe SSD를 설치할 수 있습니다. M2_LED1/23/4 (M.2 Activity Indicator LEDs/M.2 動作指示燈) The LED blinks when your M.2 PCIe SSD is being accessed.
- Page 4 4 x M.2 2TB Gen4 SSDs (Note 2) Š Dimension 26.2cm x 11.5cm Š (Note 1) Supported RAID levels vary by platform. (Note 2) Included only with the GP-ASACNE6800TTTDA model. 產品規格 PCI Express x16插槽， 支援x16或x8運作規格(如安裝在x8 介面 Š 運作規格的插槽，僅支援M2_1/M2_2插座) 4 個 M.2 動作指示燈...
- Page 5 M.2 存储设备 4个M.2 2TB Gen4 SSD Š (注二) 26.2cm x 11.5cm 尺寸 Š (注一) 支持RAID的模式，可能依使用平台而不同。 (注二) 只有GP-ASACNE6800TTTDA提供此设备。 製品 の 仕様 PCI Express x16、 PCI Express x16 および x8 スロットと互換 インター Š 性があります （アダプタカードが x8 スロットに取り付け フェイス られている場合、 M2_1 および M2_2 コネクタのみを使用...
- Page 6 RAID 0, RAID 1 및 RAID 10 지원 (주 1) Š M.2 저장 장치 M.2 2TB Gen4 SSD 4 개 Š (주 2) 26.2cm x 11.5cm 치수 Š (주 1) 지원되는 RAID 레벨은 플랫폼에 따라 다릅니다. (주 2) GP-ASACNE6800TTTDA 모델에만 포함됩니다. - 6 -...
- Page 7 Installing an M.2 SSD • 安裝M.2 SSD • M.2 SSD • 安装M.2 SSD (Note) (註) (注) • M.2 SSD 설치 のインストール (注) (주) Step 1: Remove the M.2 protective films from the heatsink cover and adapter card as indicated. 步驟一： 請先撕除外殼及轉接卡上的M.2 導熱片...
- Page 8 ステップ2: ドライバーを使用して、 ネジとネジ受け を外します。 取り付ける M.2 SSD の適切 な取り付け穴を見つけ、 最初にネジ受け をねじ込みます。 次に、 M.2 SSD を斜めに コネクタへ差し込みます。 2 단계: Step 2 나사 드라이버를 사용하여 나사와 스탠드 오프를 풉니 다. M.2 SSD를 설치할 올바른 Use a screw driver to unfasten the screw and standoff.
- Page 9 Step 3: Press the M.2 SSD down and then secure it with the screw. 步驟三： 壓住M.2 SSD之後，再將螺絲鎖上。 步骤三： 压住M.2 SSD之后，再将螺丝锁上。 ステップ3 ： M.2 SSD を押し下げてから、 ネジで固定し ます。 3 단계: M.2 SSD를 아래로 누른 다음 나사로 고정하십시오. - 9 -...
-
Page 10: Regulatory Statements
"end of life" product. Restriction of Hazardous Substances (RoHS) Directive Statement GIGABYTE products have not intended to add and safe from hazardous substances (Cd, Pb, Hg, Cr+6, PBDE and PBB). The parts and components have been carefully selected to meet RoHS requirement. -
Page 11: Battery Information
Battery Information European Union—Disposal and recycling information GIGABYTE Recycling Program (available in some regions) This symbol indicates that this product and/or battery should not be disposed of with household waste. You must use the public collection system to return, recycle, or treat them in compliance with the local regulations. - Page 12 Warranty covers a returned Product. ™ These warranties are valid only for the original owner of the product. GIGABYTE will not extend their warranty to items that are purchased secondhand. This warranty is not assignable; products purchased from secondhand sources are not covered in the warranty by GIGABYTE.
- Page 13 ™ The provisions of this warranty shall not apply if, in GIGABYTE’s sole judgment, the product has been subject to misuse or neglect, improper installation, damaged in an accident, or repaired or altered in any way that affects its performance or reliability.
- Page 14 - 14 -...
- Page 15 - 15 -...
- Page 16 AORUS Gen4 AIC Adaptor GP-ASACNE6800TTTDA/ GC-4XM2G4 AORUS Gen4 AIC Adaptor GP-ASACNE6800TTTDA/ GC-4XM2G4 Sept. 12, 2019 Sept. 12, 2019...
- Page 17 Information in this manual is protected by copyright laws and is the property of GIGABYTE. Changes to the specifications and features in this manual may be made by GIGABYTE without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without GIGABYTE's prior written permission.
