Table of Contents SAFETY, CARE AND REGULATORY INFORMATION ..........3 CHAPTER 1 PACKING LIST ..................... 7 CHAPTER 2 SYSTEM OVERVIEW.................. 8 CHAPTER 3 SYSTEM SPECIFICATION............... 10 CHAPTER 4 OPEN FRONT BEZEL ................11 CHAPTER 5 RELEASE HARD DISK TRAY ..............12 CHAPTER 6 HARD DISK INSTALLATION..............
Safety, Care and Regulatory Information Important safety information Read and follow all instructions marked on the product and in the documentation before you operate your system. Retain all safety and operating instructions for future use. The product should be operated only from the type of power source indicated on the rating label.
Page 4
Federal Communications Commission (FCC) Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 5
NOTICE: The Load Number (LN) assigned to each terminal device denotes the percentage of the total load to be connected to a telephone loop which is used by the device, to prevent overloading. The termination on a loop may consist of any combination of devices subject only to the requirement that the sum of the Load Numbers of all the devices does not exceed 100.
Page 6
European Community Directive Conformance Statement This product is in conformity with the protection requirements of EC Council Low Voltage Directive (Safety) 73/23/EEC, EMC Directive 89/336/EEC on the approximation of the laws of the Member States relating to electro-magnetic compatibility. R&TTE Directive (applicable to products fitted with European modems) This modem does not require any physical and/or software additional switch settings from the User and is suitable for use only on telephone lines provided with Multi-Frequency Dialing facilities.
Chapter 2 System Overview Front bezel Status LED Power LED Key lock LCD display Release button Release button LCD module button: mute / ESC / up / down / ENT Front view Disk number 1~15 Hard disk tray release button Hard disk tray Hard disk access LED Hard disk power LED...
Page 9
Light definition Color Blank Power Blue System power on System power off Status System ready System not ready HDD power LED Blue HDD connected HDD not connected HDD access LED Green HDD access HDD no access LCD module display...
GR-ES915 iSCSI Storage Array Controller Processor iStor GSATX-816 Cache Memory 512MB ECC+REG DDR SDRAM Up to 4GB Host Channel iSCSI, Gigabyte *8 Disk Channel Serial ATA-I/Serial ATA-II RAID Level 0,1,10,5,JBOD Backup Battery Unit Supported Platform Support Operation System Independent Disk Support...
Chapter 8 Enter Administrator Web UI 1. Power-up the GigaStorATX Storage Controller. 2. Wait for a while until (3mins-5mins) GigaStorATX is getting ready. 3. In the browser’s address bar, type the default IP address (192.168.1.1) for the GigaStorATX management console and press the Enter key.
Page 16
6. Click the OK button. A screen appears with a progress bar as the connection is being made to the GigaStorATX. Once the connection is made, the main screen appears. Note: Please check the software manual CD for detail software operating information.
