Vympel Hygrovision BL Operating Manual

Dew point analyzer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
P r e c i s i o n | E c o n o m y | S a f e t y
Operating Manual
w w w . v y m p e l . d e
H y g r o v i s i o n B L
Dew point analyzer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hygrovision BL and is the answer not in the manual?

Questions and answers

Related Manuals for Vympel Hygrovision BL

Summary of Contents for Vympel Hygrovision BL

  • Page 1: Operating Manual

    P r e c i s i o n | E c o n o m y | S a f e t y Operating Manual H y g r o v i s i o n B L Dew point analyzer w w w .

  • Page 2: Table Of Contents

    TABLE&OF&CONTENTS& GENERAL&DESCRIPTION& 1.1. & URPOSE&AND& IELD&OF& PPLICATION URPOSE IELD!OF!APPLICATION YPES!OF!INSTALLATIONS NSTALLATION!AND!OPERATING!REQUIREMENTS 1.2. & XPLOSION&PROTECTION 1.3. & EASUREMENT&PRINCIPLE 1.4. & NALYZER&CONSTRUCTION ATTERY!PACK 1.5. & NALYZER&POWER&SUPPLY 1.6. & DDITIONAL&COMPONENTS&AND&ACCESSORIES ICROSCOPE Gas!flow!/!gas!pressure!control!system!(Model!001)! 001! AS!DELIVERY!SYSTEM! ! ODEL! ARTICLE!FILTER HYDROCARBONS LYCOLS!AND!HEAVY! !FILTER XTERNAL!POWER!SUPPLY!CABLE DAPTER UPPLEMENTAL!COOLING!SYSTEM RIPOD AMPLE!GAS!EXTRACTION!SYSTEM PRESSURE! ! VENTING!MODULE...

  • Page 3: Table Of Contents

    PERATING!RESTRICTIONS RECHARGEABLE REPARING!THE! !BATTERY!FOR!ANALYZER!OPERATION AMPLE!EXTRACTION 3.2. & ONNECTING&THE&ANALYZER ESTING!SEAL!INTEGRITY 3.3. & UNCTIONAL&TEST WITCHING!ON!THE!ANALYZER HECKING!THE!MICROSCOPE!LIGHTING HECKING!THE!CONDENSATION!MIRROR!AND!THE!THERMOELECTRIC!BATTERY ATE!AND!TIME ATTERY!PACK!CHARGE!STATUS WITCHING!OFF!THE!ANALYZER OPERATING&THE&HYGROVISION&BL& 4.1. & RECAUTIONARY&MEASURES 4.2. BL& ANDLING&THE& YGROVISION& MEASUREMENTS! REPARING!TO!TAKE! EATING!THE!CONDENSATION!MIRROR LEANING!THE!MIRROR DJUSTING!THE!LIGHTING!INTENSITY IRROR!SCAN! CANNING! AKING!DEW!POINT!MEASUREMENTS 4.3. &DEW&POINT&MEASUREMENT&USING&THE&PREPROGRAMMED&RATE&OF&COOLING& &HEATING&THE& & CONDENSATION&MIRROR 4.4. &...
  • Page 4 ALIBRATING!FOR!HYDROCARBONS 5.3. & IST&OF&POSSIBLE&ERROR&MESSAGES MARKINGS& PACKAGING& STORAGE& TRANSPORT& RANSPORT!CONDITIONS DECOMMISSIONING&AN&D&DISPOSAL& APPENDIX&А& 11.1. & YGROVISION & NALYZER &MAIN&COMPONENTS APPENDIX&B& 12.1. & YGROVISION &EXPLOSION&PROTECTION APPENDIX&C& 13.1. F001 VYMP5.183.001.& LOW&CONTROL&SYSTEM&MODEL & APPENDIX&D& 14.1. F001 VYMPL6.450.001.& AS&DELIVERY&SYSTEM& ODEL & APPENDIX&E& 15.1. VYMP5.880.003.& OOLING&MODULE& & ONSTRUCTION&DRAWING APPENDIX&F&...
  • Page 5 20.1. & HE& ODBUS&REGISTER APPENDIX&K& 21.1. & NIVERSAL&TERMINAL&PROGRAM & YGROVISION APPENDIX&L& 22.1. & ESCRIPTION&OF&THE&CALIBRATION&PROCEDURE&FOR&HYDROCARBONS 23.& APPENDIX&M& 23.1. CONDENSATION& XAMPLES&OF& &AND& & APPENDIX&N& 24.1. & OCUMENTATION&CHART Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 6 – VYMPEL GmbH Bahnstraße 17 40212 Düsseldorf Deutschland Tel: +49211 210 77 391 Fax: +49211 210 77 399 email: info@vympel.de www.vympel.de – Responsible for manufacturing: 143530, Russia, Mossbauer Area, Istrinsky District, Dedowsk, Shkolny Passage, No.11 Tel.: 8 (495) 992-38-60 (ext. 219) Fax: 8 (495) 992-38-60 (ext.217)

  • Page 7: General&Description

    KRAY2.844.007 (also called HV BL, Hygrovision, device, in- strument, and analyzer in the text). The Hygrovision BL is a compact portable analyzer used to es- tablish the dew point temperature of water and hydrocarbons. This portable hygrometer (hereinafter analyzer) functions ac- cording to the principal of direct measurement.

  • Page 8: P Urpose

    It is also intended for the visual monitoring of the condensation process. Hygrovision BL dew point analyzer are designed to be used for: IELD OF APPLICATION Spot checking in the field...

  • Page 9: E Xplosion&Protection

    GOST R 52350.11 it has no Ex protection markings. Attention! To ensure that the Hygrovision BL is safe with regard to explosions, it is important to regularly purge the analyzer with air and to always fill the measurement chamber with sample gas before switching the device on.

  • Page 10: M Easurement&Principle

    1.3. EASUREMENT PRINCIPLE The Hygrovision BL is a compact, portable analyzer used for tak- ing automatic and manual measurements of the dew point tem- perature of water and/or hydrocarbons. This portable chilled-mirror automatic hygrometer operates ac- cording to the principle of direct measurement and employs a ILLUSTRATION&...
  • Page 11 in the middle of the mirror’s surface (ILLUSTRATION 5). Under vertical lighting this condensation appears as an accumulation of little round black spots evenly distributed over the entire surface of the condensation mirror (ILLUSTRATION 6). In the case of hydrocarbons, precipitated condensates accumu- late in the form of a thin film on the surface of the mirror (Illustra- tion 7).

  • Page 12: A Nalyzer&Construction

    The electronic module controls the analyzer’s processes (cool- ing/heating); records the mirror temperature and regulates the photoelectric registration system. The Hygrovision BL is operated by means of control buttons and the touch screen display. Recorded dew point values can be downloaded by means of an IR port and an RS 485 interface.

  • Page 13: B Attery!Pack

    (KRAY5.549.006 ET) (included in delivery). It is strongly recommended that only the (KRAY4.841.082) connec- tion cable be used to connect the Hygrovision BL to an external power source (12 – 32V DC). This cable is designed specifically for this purpose (ILLUSTRATION 13).

  • Page 14: A Dditional&Components&And&Accessories

    the label (KRAY5.122.007ET). 1.6. DDITIONAL COMPONENTS AND ACCESSORIES Additional components include those systems and accessories that ensure the optimal performance of desired analyzer functions. Additional components fall into one of two categories: Additional components included as part of the Hygrovision •...

  • Page 15: Important Components

    ILLUSTRATION 14 is an exterior view of the microscope ICROSCOPE (KRAY3.821.003). The optical system is positioned immediately above the high-pressure chamber. Equipped with 40X magnification, this system makes it pos- sible to directly monitor processes taking place on the mirror’s surface inside the measurement chamber to visually evaluate the composi- tional quality of the gas (see also 1.3).

  • Page 16: P Article!Filter

    (KRAY6.451.017) is used for the taking of meas- urements under these conditions. This filter is included as a standard additional component with the Hygrovision BL. (ILLUSTRATION 18). The filter is installed directly in front of the fine control valve...

  • Page 17: E Xternal!Power!Supply!Cable

    Tripod (Libec TH-650DV); • Sample extraction system KRAY4.078.091(- 01); • Pressure reduction system VMPL2.848.005; • High-pressure outflow module VMPL4.078.025; • For a detailed list of the Hygrovision BL’s standard • and optional components, please refer to Table 3, Point 1.12. Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...

  • Page 18: S Upplemental!Cooling!System

    The supplemental cooling system (VMPL5.880.003) should UPPLEMENTAL COOLING SYSTEM be used when measuring dew point values below -30°C at ambient temperatures above +30°C and at pressures over 100 bar (ILLUSTRATION 21). The cooling system consists of a container filled with carbon dioxide, two connector fittings, and a regulator valve to con- trol the flow of refrigerant.
  • Page 19 In addition, the SGA is also fitted with a supplemental access point on the explosion-proof terminal box in order to connect the Hygrovision BL to an external power supply and link it to the data transfer system. ILLUSTRATION& & 23:&SGA&003&incl.&Hygrovision&BL&...

  • Page 20: C Ontrol&And&Display&Elements

    1.8. ’ HE ANALYZER S MENU To turn on the Hygrovision BL press and hold the on/off but- URNING ON THE ANALYZER ton for several seconds (Illustration 24). After the analyzer has been switched on, the touch screen will display the software version information for two to three seconds.
  • Page 21 Operating mode Shows the currently selected operating mode (Pos.1 ILLUSTRATION 26; ILLUSTRATION 27); Mode selection Used to select the desired operating mode (Pos.12, ILLUSTRATION 26; ILLUSTRATION 27); Properties Used to select and access the analyzer’s basic operating pa- rameters in order to make adjustments (Pos.2, ILLUSTRATION 26;...

  • Page 22: D Isplayed!Information

    Measurement scale Used to change the measurement scale during the measurement process (Pos. 5, ILLUSTRATION 26; ILLUSTRATION 27) Battery charge status – Pos.3 (ILLUSTRATION 26; • ISPLAYED INFORMATION ILLUSTRATION 27); Timer – Pos.4 (ILLUSTRATION 26; ILLUSTRATION • 27); Current temperature of the condensation mirror – Т; •...
  • Page 23 < > Use the icons to navigate between individual menu points. Please note that the date and time are set using the Settings menu (see also Appendix I). ILLUSTRATION& & 29:&Properties:&System&–&Date& and&time& The Hygrovision’s battery should be fully recharged as de- scribed in the manual (KRAY5.122.007 ET) when the charge falls below 20%.

  • Page 24: A Nalyzer!Check

    NALYZER CHECK In order to check the functionality of the analyzer follow these steps: Tap the icon to switch to the mirror-cleaning mode (Pos.6, ILLUSTRATION 26; ILLUSTRATION 27) The analyzer’s display will show the “Transducer cleaning mode” window (ILLUSTRATION 31) If the device is operating normally, the condensation mirror ILLUSTRATION&...

  • Page 25: T Urning!Off!The!Analyzer

    In order to visually observe the measurement process in automatic mode for hydrocarbons, the microscope lighting must be activated by tapping the icon. (ILLUSTRATION 33). ILLUSTRATION& & 33& In the automatic mode for water, the microscope lighting is switched off (ILLUSTRATION! ! 34). Visual monitoring of the measurement process in this mode is carried out with the microscope lighting turned off.

  • Page 26: Peripheral Devices

    1.9. ONNECTING PERIPHERAL DEVICES The following connection points are located on the right side of the analyzer’s housing: ХР2 – used for maintenance purposes • ХР3 – microscope lighting connection socket (Pos.5 ; • ILLUSTRATION! ! 10) XР1 – socket for connecting the analyzer to an external •...
  • Page 27 ILLUSTRATION& & 35:&Schematic&drawing&for&the&connection&of&peripheral&devices& Position of elements in illustration 35: 1 – Hygrovision BL dew point analyzer 5 – Computer terminal 2 – Microscope (KRAY3.821.003) 6 – IR Adapter (KRAY5.999.005) 3 – AC power adapter (12- 32) V / 15 W К1 –...

  • Page 28: S Pecifications

    & & & ILLUSTRATION& & 36:&Connection&of&a&computer&terminal&via&the&IR&port Attention! The terminal computer and the IR adapter (KRAY5.999.005) are not explosion-proof devices. For this reason, connection of these devices to the analyzer may only be carried out in explosion-proof zone. Attention! To ensure the analyzer’s explosion safety, unused socket connections must be se- cured with the caps included with delivery.
  • Page 29 Battery-powered operation = (8.4 – 12.6) V, 4 mА / 15 W Electrical supply (Voltage / Power) External power supply = (12 – 32) V / 15 W Battery-powered operation Operating time External power supply Unlimited Ambient -10 – +50 С...
  • Page 30 1.11. YGROVISION STANDARD EQUIPMENT & & Table 2 gives an overview of the important standard components delivered with the Hygrovision BL. The&positions&in&ILLUSTRATION& & 37,&ILLUSTRATION& & 38,&ILLUSTRATION& & 39&correspond&to&the&numbering&in&table&2.& & & Table 2. ILLUSTRATION& & 39& ILLUSTRATION& & 37& ILLUSTRATION& & 38&...
  • Page 31 – PVC pipe: inner diameter ø 6х1.5, length= 2500 mm – Mounting fittings (set) VMPL 4.161.004 Transport case KRAY 4.841.082 External power supply cable KRAY 5.122.007 Battery charger KRAY 5.549.006 AC adapter unit BP-06 KRAY 5.999.005 IR data connection line –...

  • Page 32: E Xplosion&Safety&Provisions

    GOST R 52350.0 and GOST R 52350.1. The maximal temperatures generated through internal heating, to which the electrical components and the housing of the Hygrovision BL are exposed do not exceed those allowed in GOST R 52350.0 for temperature class T5.
  • Page 33 The seals and con- nectors used for structural elements provide an IP 66 level of protection in accordance with GOST 14254. All applicable explosion protection information is displayed on the housing of the Hygrovision BL as required by regulation. Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...

  • Page 34: G Eneral&Safety&Measures

    It is strongly recommended that users of the Hygro- vision BL receive training and/or instruction provided by Vympel GmbH in order to fully comply with the above stated requirements.
  • Page 35 When in operation, the analyzer should undergo a regular visual inspection that includes the following points: Check the integrity of all the seals; • Check that all of the lids and caps are properly in place; • Check the integrity of the insulation of all the wiring (power supply and data transfer); •...

  • Page 36: Preparing&The&Analyzer& & For&Operation

    Should the packing show signs of damage, please document this, and contact customer services at INSPECTION Vympel GmbH. Carefully unpack the analyzer and its accessories. Refer to the packing list to ensure that the delivery is complete.

  • Page 37: S Ample!Extraction

    Attention! The Hygrovision’s battery must be charged/recharged only in an explosion-proof zone. When selecting a sample extraction site, the following points should be AMPLE EXTRACTION considered: The ambient temperature and the relative humidity lie within the pa- rameters listed in table 1, point 1.1; The temperature of the sample gas as it enters the measurement chamber must not be lower than temperature of the gas at the extrac- tion site.

  • Page 38: T Esting!Seal!Integrity

    Both of these systems use quick-connect couplers to attach to the analyzer’s inlet and outlet ports in order to not only reduce the time required for (de)installation but also to ensure an airtight seal at each of these points. The analyzer connects to the gas supply by means of a flexible high-pressure hose equipped with a fine adjustment valve (Pos.2).

  • Page 39: F Unctional&Test

    4. If bubbles are seen forming in the soapy emulsion it is a sign that the corresponding connection is not properly sealed. The connection seal must be reseated to ensure air tightness. Attention! In situations where the dew point of inflammable gases is being measured, it is necessary to ventilate the analyzer’s measuring chamber and the sample gas de- livery lines for 10 to 20 minutes before connecting the device to the power supply.

  • Page 40: C Hecking!The!Condensation!Mirror!And!The!Thermoelectric!Battery

    ILLUSTRATION 27). Look through the microscope to visually con- LIGHTING firm that the lighting switches on and off. Make sure that the microscope is optimally adjusted for viewing the surface of the condensation mirror. Use the focusing ring to adjustment the sharpness of the image. Activate the “Transducer Cleaning Mode”...

  • Page 41: P Recautionary&Measures

    Before taking any measurements, please make sure that the ana- lyzer and its accessory parts are all in proper working order. REPARING TO TAKE When preparing the Hygrovision BL for operation: MEASUREMENTS Affix the analyzer to a tripod or place it on a level surface;...

  • Page 42: H Eating!The!Condensation!Mirror

    Always clean the mirror before taking measurements by activating EATING THE the “Transducer cleaning mode”. CONDENSATION MIRROR Tap the icon to activate this mode (Pos.6; ILLUSTRATION 26; ILLUSTRATION 27). When the icon is tapped the “Transducer cleaning mode” menu window is opened. The information displayed in this mode includes values for the mirror temperature (T), the signal levels for hydrocar- bons (U ) and water (U...

  • Page 43: M Irror!Scan

    Scanning serves to simplify the process of registering the dew point IRROR SCAN manually. In scanning mode, the analyzer establishes an approxi- mate dew point range within which lies the actually dew point. CANNING Tap the function icon (Pos.7; ILLUSTRATION 26; ILLUSTRATION 27) to begin the scanning process.

  • Page 44: T Aking!Dew!Point!Measurements

    Dew point results registered in automatic mode are saved in the analyzers non-volatile memory and can be displayed at any time. The Hygrovision BL is equipped with an IR-Port and an RS 485 in- terface for data transfer purposes. The corresponding computer software (Appendix K) is also included in delivery.

  • Page 45: Condensation&Mirror

    4.3. DEW POINT MEASUREMENT USING THE PREPROGRAMMED RATE OF COOLING HEATING THE CONDENSATION MIRROR 1. Select the hydrocarbon measurement channel by activating the icon (Pos.11, ILLUSTRATION 45). Set the analyzer to the preprogrammed rate of cooling / heating (per ISO) mode by choos- ILLUSTRATION&...

  • Page 46: Hc &Dew&Point&Measurement&Cooling&The&Mirror&Step&By&Step

    4.4. DEW POINT MEASUREMENT COOLING THE MIRROR STEP BY STEP 1. Select the hydrocarbon measurement channel by activat- ing the icon (Pos.11, ILLUSTRATION 47). Set the analyzer to step by step cooling mode by choosing the icon (Pos.10). Tap the icon to activate the microscope lighting (Pos.8).
  • Page 47 4.5. ATER DEW POINT MEASUREMENT USING THE PREPROGRAMMED RATE OF COOLING HEATING THE CONDENSATION MIRROR 1. Select the water measurement channel by activating the icon (Pos.11, ILLUSTRATION 48). Set the analyzer to the preprogrammed rate of cooling / heating (per ISO) mode by choosing the icon (Pos.10).

  • Page 48: W Ater&Dew&Point&Measurement&Cooling&The&Mirror&Step&By&Step

    4.6. ATER DEW POINT MEASUREMENT COOLING THE MIRROR STEP BY STEP 1.&Select&the&water&measurement&channel&by&activating&the& & icon&(Pos.11,& & ILLUSTRATION 49). Set the analyzer to step by step cool- ing mode by choosing the icon (Pos.10). Tap the icon to deactivate the microscope lighting (Pos.8). 2.
  • Page 49 4.7. DEW POINT MEASUREMENT IN AUTOMATIC MODE Tap the icon to set the analyzer to automatic mode for haydrocarbons. Refer to point 1.8. When measuring the hydrocarbon dew point in automatic mode the following information will be shown on the left side of the display (see ILLUSTRATION 50): Current measurement mode HC;...
  • Page 50 Attention! Values for the dew point of water that are registered in the HC mode are approxi- mations and should only be used for purposes of general orientation. For accurate WDP values switch to the automatic mode for measuring the dew point of water. 4.8.
  • Page 51 If the message “<” is shown in the DP field it means that the dew point could not be registered during the current measurement cycle. In this situa- tion the lowest temperature to which the condensation mirror was cooled is entered in the table.

  • Page 52: S Pecial&Considerations&When&Measuring&Dew&Point&At&Very&Low&Temperatures

    4.9. PECIAL CONSIDERATIONS WHEN MEASURING DEW POINT AT VERY LOW TEMPERATURES The diagram in ILLUSTRATION 52 shows the effectiveness of EASURING DEW POINT AT the integrated cooling system with regard to controlling the tem- VERY LOW TEMPERATURES perature of the condensation mirror under a range of operating conditions.
  • Page 53 ILLUSTRATION& & 52 Please note: The analyzer’s housing temperature (T ) must remain at least housing 5 °C above the dew point being measured for the entire period of any supplemental cooling. The vortex tube-based supplemental cooling system UPPLEMENTAL COOLING (VMPL5.880.003) is available as an optional accessory module See ILLUSTRATION 53.

  • Page 54: I Nstallation!Of!The!Supplemental!Cooling!System

    Observe the following procedure when installing the supplemen- NSTALLATION OF THE tal cooling system: SUPPLEMENTAL COOLING 1. Mount all of the cooling system’s components as illus- SYSTEM trated in Appendix E: 2. Install the inlet fitting (Pos.12, Appendix E) into the venti- lation channel for supplemental cooling;...
  • Page 55 4. Should the dew point lie beyond the range of the ana- lyzer’s integrated cooling system, it is necessary to also supply sample gas to the supplemental cooling sys- tem. To do this, open the valve at Pos. 11, Appendix E. 5.

  • Page 56: U Ninstalling!The! A Nalyzer

    4.10. NINSTALLING THE YGROVISION Use the following procedure when uninstalling the analyzer: NINSTALLING THE NALYZER 1. Switch off the analyzer; 2. Close the high pressure valve on the gas delivery sys- tem (Pos. 2, ILLUSTRATION 16) 3. Use the fine control valve integrated into the flow control system (Pos.1, ILLUSTRATION 15) to adjust the pres- sure within the measurement chamber until it is reduced to coincide with the ambient atmospheric pressure.

  • Page 57: Technical&Maintenance

    5. T ECHNICAL MAINTENANCE 5.1. ENERAL INSTRUCTIONS In general, maintenance of the device consists of regular metrological recalibration, checking of the technical condition of the analyzer, and when appropriate, cleaning the mirror in accordance with Point 5.2. Any repair that requires the opening of the analyzer’s seals must be car- ried out by the manufacturer or the manufacturer’s authorized agent.

  • Page 58: C Leaning!The!Condensation!Mirror

    When installing the battery pack, screw down the lid (Pos.3; • ILLUSTRATION 11) that covers the battery pack slot until it is fully seated. Use the locking device (Pos.15; ILLUSTRATION 11) to secure the lid in place; If the analyzer is to be out of service for a period exceeding •...
  • Page 59 In “Transducer cleaning mode” the following elements are dis- played on the touch screen: Temperature of the condensation mirror Т; • Signal levels U and U (digital); • Rejection criteria (maximum acceptable signal levels) • If the U und U signal levels do not exceed the maximum ac- ceptable values, it is not absolutely necessary to clean the con- ILLUSTRATION&...
  • Page 60 Attention! Manual cleaning of the condensation mirror is ONLY to be carried out in an explosion safe environment! Use the following procedure when cleaning the condensation LEANING THE CONDENSATION mirror manually: MIRROR Switch off the analyzer; • Close the fine control valve of the gas delivery system •...
  • Page 61 In some situations it is possible to carry out a “quick cleaning” of the condensation mirror. Using the special key provided (VMPL 8.392001), unscrew the insert that houses the measurement chamber observation win- dow and remove it (ILLUSTRATION 56). Once the insert is removed the surface of the condensation mirror is accessible and can be cleaned as described above (ILLUSTRATION 57).
  • Page 62 The efficiency of the thermoelectric battery should be checked ESTING THE THERMOELECTRIC prior to calibrating the Hygrovision BL, as well as whenever the (TEB) analyzer malfunctions (Pos.6; Table 4). BATTERY Use the following procedure to check the thermoelectric battery: 1.
  • Page 63 5.3. IST OF POSSIBLE ERROR MESSAGES Table!4 contains a list of possible error messages that could be shown on the Hygrovision’s touch screen display. Table&4& Problem Possible cause Solution The analyzer won’t switch on The battery pack has no charge Recharge the battery pack The battery temperature is outside the tolerance range:...
  • Page 64 During battery-powered opera- tion, the analyzer switches itself Screw down the battery The battery pack is not securely in off from time to time. compartment lid until it is place. tightly seated. The LED indicator flickers. Check the calibration of the display by following these steps: 1.
  • Page 65 6. M ARKINGS Labeling on the analyzer’s housing provides information about: Trademarks and the name of the Manufacturer • Description of the device • Markings about ignition protection • Certifying authority and certification number • Markings about protection against the effects of solid con- •...
  • Page 66 & 8. S TORAGE The device may only be stored in a container made by the manufacturer that is specifically designed for this purpose. Such a container protects the device from mechanical damage, contamination, and the effects of aggres- sive media For transportation purposes, analyzers can be temporarily stored in the specially designed transportation packaging (max.
  • Page 67 9. T RANSPORT RANSPORT CONDITIONS Transportation requirements: Analyzers may only be transported in closed containers on board closed climate controlled vehicles. When in service, the device may only be transported in the carrying case included with delivery (ILLUSTRATION 59). ILLUSTRATION& & 59& 10.
  • Page 68 11. A А PPENDIX 11.1. -BL A YGROVISION NALYZER MAIN COMPONENTS ILLUSTRATION& & 60 Pos. Description Pos. Description Socket for connecting an external power Housing supply and the RS-485 Interface Bottom cover Locking device Gas delivery Ground terminal Measurement cell Gas inlet cover Electronics block Heat exchanger...
  • Page 69 Battery slot lid Sample gas inlet fitting Viewing window Sample gas outlet fitting Ventilation channel for additional cooling Manual mode control buttons of the analyzer housing Pressure transmitter socket Moister absorber Microscope lighting (vertical) con- Battery cover locking device nection socket Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 70 12. A PPENDIX 12.1. YGROVISION EXPLOSION PROTECTION ILLUSTRATION& & 61:&Explosion&protection&measures&KRAY2.844.007D5 ILLUSTRATION& & 62:&Explosion&protection&measures&KRAY2.844.007D5 (continues on the following page) Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 71 ILLUSTRATION& & 63:&Hygrovision&BL&explosion&protection&measures&KRAY2.844.007D5&(continuation) Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 72 13. A PPENDIX 13.1. -001 VYMP5.183.001. LOW CONTROL SYSTEM MODEL Construction drawing & ILLUSTRATION& & 64:&Construction&schematic&of&the&flow&control&system&model&001& Pos. Designation Description Qty. Note VMPL8.034.004 Housing VMPL 8.034.011 Housing VMPL 8.626.003-01 Tubing VMPL 8.626.003-02 Tubing VMPL 8.626.009 Tubing Screw М3х16 А2 DIN7991 Flow measurement device Dwyer MMF-1 Manometer 131.11.040, 0 –...
  • Page 73 14. A PPENDIX 14.1. -001 VYMPL6.450.001. AS DELIVERY SYSTEM ODEL Construction drawing ILLUSTRATION& & 65 1.) All measurements are intended as reference information. 2.) Connection to the flow-through channel (Pos. 3) as well as both ends of the hose (Pos.7) are made by holding down the quick-release mechanism.
  • Page 74 Pos. Designation Description Qty. Note VMPL8.600.004 Supporting disk DCP- 6M Flow-through channel connector «Dk-Lok» V15B-D-6M-R-S Fine control valve «DRK- Lok» DFBA-D-6M-SA Quick-coupler socket «DRK- Lok» MFH4P-TM6-4 0CM-S Hose «DRK- Lok» Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 75 15. A PPENDIX 15.1. VYMP5.880.003. OOLING MODULE ONSTRUCTION DRAWING ILLUSTRATION& & 66 ILLUSTRATION& & 67 Pos. Designation Description Qty. Note VYMP5.880.004 Vortex tube Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 76 VYMP 8.626.002 Tubing Model 131.11.40 Manometer: 0 – 25 bar «WIKA» ВВ-13АН1KN99004-S Pressure regulator «Dk-Lok» VL82B-D6M-A Ball valve (angular configuration) «Dk-Lok» DMC6M-2N-SA Connector fitting «Dk-Lok» DT2ARF-6M-4GG-6M- T-fitting «Dk-Lok» DTRA-6M-SA T-fitting «Dk-Lok» DFSA-D-6M-SA Quick-coupler plug «Dk-Lok» DFBA-D-6M-SA Quick-coupler socket «Dk-Lok» DCF 6M-2N-SA Adapter «Dk-Lok»...
  • Page 77 16. A PPENDIX 16.1. VMPL2.848.005. RESSURE REDUCTION MODULE Main view / overall dimensions ILLUSTRATION& & 68:&Main&view&/&overall&dimensions Pos. Designation Description Qty. 1, 5 V15B-D-6M-R-S Fine control valve Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 78 2, 6 Model 213.53.50 Manometer: 0 – 160bar; connector on the back: G 1/4" VMPL 5.863.004 Heating element 44-2264-221-S Pressure regulator V81A-D-6M-BF-S Ball valve 8, 9 DUB-6M-SA Coupling rail BPGC01.00-029 Terminal box BPGC01.00-027 Terminal box VMPL 6.854.002 Fold-out support VMPL 8.220.005 Locking knob Position lock Removable pedestal...
  • Page 79 17. A PPENDIX 17.1. PRESSURE GAS RELEASE MODULE Construction drawing ILLUSTRATION& & 69:&Construction&drawing:&gasUrelease&module Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 80 Pos. Designation Description Qty. DK 32 Flow regulator: Measurement media – Methane Flow volume: 0 – 1 Nl/min Connector: G 1/4" V15В-D-6M-R-S Fine control valve DFBA-D-6M-SA Quick-connect plug Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 81 18. A PPENDIX 18.1. BL’ LECTRICAL PARAMETERS OF THE YGROVISION S PLUGS The following tables list the parameters for the plugs and electrical circuits Plug ХР3: used for connecting the microscope lighting Table&5& Contact Description Circuit characteristics + LED Output signal, U : 7 V, I : 27 мА...
  • Page 82 19. A PPENDIX 19.1. ETTINGS MENU The Settings menu can be accessed from any mode by tapping ENU DESCRIPTION icon. A menu window will open displaying the icons for functions that have parameters which can be adjusted: - Automatic mode - Manual mode Transducer cleaning - Microscope lighting...
  • Page 83 To open a given function, tap the corresponding icon once to ANAGEMENT AND ADJUSTMENT select and a second time to confirm. OF FUNCTION PARAMETERS IN ETTINGS MENU Use the icons to navigate between individual pa- rameter points (ILLUSTRATION 72). Confirm parameter settings by tapping the icon.
  • Page 84 Automatic mode NDIVIDUAL FUNCTION The following automatic mode parameters can be adjusted: PARAMETER MENUS General • HC cycle • W cycle • Manual mode This menu includes all of the parameters for the scanning mode as well as those for taking dew point measurements in the stepwise cooling mode.

  • Page 85: Power Supply

    Power supply The display will switch to standby mode after a given period of time if it is not actively operated. This period can be altered in the Power supply menu. Proper adjustment of this value will maximize the period of battery-powered operation. The following options for this setting are available: In 15 seconds •...
  • Page 86 fer via the RS-485 interface. (ILLUSTRATION 81). The settings shown in the illustration are the factory default values for the Mod- bus / RTU protocol. For further information please refer to Appendix!K. & ILLUSTRATION& & 79& & Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 87 20. A PPENDIX 20.1. ODBUS REGISTER Table&8& ModBus/RTU protocol parameters: Baud rate 38400 Parity Stop-Bit Address Modbus address: 100 Table!8: Modbus input register Table&9& Register address Type Parameter description uint32_t Current time. Number of seconds elapsed since 0:00:00 Jan. 1, 1970 14-15 float Pressure...
  • Page 88 28-29 uint16_t Dp(W), in °С uint32_t Pressure at which dp(W) was 30-31 measured Dp(W) – Codes Battery pack parameters uint16_t Charge status in % 45-46 float Voltage, V 47-48 float Battery pack temperature in °C uint16_t Battery pack condition – Codes Dp(HC/W) –...
  • Page 89 Configuring the data connection Connect the Hygrovision BL analyzer to the COM port of your computer by means of the USB/RS 485 converter. Start the Hygrovision.exe program from the “bin” subfolder. After the program has loaded the following window will appear: ILLUSTRATION&...
  • Page 90 Next, click on the “Connections” drop-down menu and select “Settings”. This opens the pop-up win- dow shown in ILLUSTRATION 83. Now select the COM port to which the analyzer is connected. Confirm that the Modbus address listed corresponds to the address set in the Analyzer (the factory default address is “100”). Click “OK”...
  • Page 91 After the connection has been successfully established, dew point values will be listed in the table to the right in the main window and the sequence of temperatures registered during the measurement process will be plotted linearly on the scrolling graph. The period of observation is listed in minutes.
  • Page 92 Reading the analyzer’s current calibration values The first step in the process of calibrating the Hygrovision BL is to “read” the current values in the devices on-board calibration table. Click on the “Device” drop-down menu and select “Read”. The values stored on-board the analyzer will be called up and displayed in the table to the right.
  • Page 93 ILLUSTRATION& & 86:&Calibration&dialogue&window& To (re)calibrate the Hygrovision BL, enter the DP(W) value measured by a reference instrument in the column labeled “Calibrated”. The corresponding dew point value measured by the Hygrovision BL (that is being calibrated) is entered in the “Measured” column.
  • Page 94 22. A PPENDIX 22.1. ESCRIPTION OF THE CALIBRATION PROCEDURE FOR HYDROCARBONS In order to increase accuracy, settings for the hydrocarbon measurement channel can be fine tuned in the Hydrocarbons calibration mode. Calibration is carried out using a reference medium. The hydrocarbon dew point is given by the generator (connected to the analyzer for purposes of calibration) or determined under operating conditions with the aid of a reference analyzer.
  • Page 95 Individual calibration results are listed in the table on the analyzer’s display (T ±2 °C in 0.5 °C intervals). given The signal level that corresponds to the given HC dew point (in bold) will automatically be stored in the ana- lyzer’s memory as the HC calibration parameter.
  • Page 96 23. A PPENDIX 23.1. W CONDENSATION XAMPLES OF Microscope&lighting& & & & & & & & & & & & & & & & & & & & Side&lighting& (vertical&lighting)& Clean!condensation!mirror! The!surface!of!the!mirror!appears!dark.! The!surface!of!the!mirror!appears!light!blue.! Condensation!of!water!vapor!as!a!liquid! Many!tiny!red!dots!create!an!oval!pattern!in!the!midU Many!small!black!dots!are!evenly!distributed!across! dle!of!the!mirror’s!surface.! ! the!light!blue!surface!of!the!mirror.! ! Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 97 Condensation!of!water!vapor!as!solid!crystals! ! Many!individual!bright!red!dots!create!an!oval!pattern! Many!black!dots!are!evenly!distributed!across!the!light! in!the!middle!of!the!mirror’s!surface.! ! blue!surface!of!the!mirror..! Condensation!of!hydrocarbons! Lighter!hydrocarbons!(up!to!heptanes)!condense!as! iridescent!spots!that!quickly!cover!the!entire!mirror!as! a!rainbowUlike!film.! ! Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 98 Octane!and!heavier!hydrocarbons!condense!in!the! Hydrocarbon!condensation!is!not!visible!under!side! form!of!small!semiUtransparent!dark!spots,!gradually! lighting!so!the!mirror!remains!dark.! becoming!more!opaque!drops.! Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 99 24. A PPENDIX 24.1. OCUMENTATION CHART Page: Total number of document pages Document no. Signature Date Altered Replaced New Cancelled Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
  • Page 100 100! Manual&–&Hygrovision&BL&–&KRAY2.844007RE&...
