Parts - Helmer Scientific i.Series PC100-Pro Service Manual

Helmer Scientific Platelet Incubator Pro
7

Parts

Notes
• Before replacing parts, protect items in platelet incubator from extended exposure to adverse temperature.
• Allow platelet incubator temperature to stabilize at setpoint after replacing parts or after extended door opening.
B
C
Label Description
A Display assembly
B SD Card
C Chart Recorder Battery
D Temperature Chart Recorder
E Temperature Monitor Probe
F Control and Chart Recorder Probe
G Agitator Data Port
H Agitator DC Power Connection
I Bearing, Flange Mount
J Damping Cylinder (Shock)
K Door Seal
360389/A
A
D
K
L
Model Part Number
- 800960-1
- 800973-1
- 120218
- 800971-1
- 800964-1
- 800965-1
-
-
900/1200 220430
900/1200 220210
100 800967
900 801028-1
1200 801029-1
E F
G
H
I
J
Label Description
L Door Assembly
M Power Switch
N USB Port
O Back-up Battery Switch
P Hood Assembly
- Q Door Switch
- Not Manual Door Lock Assembly
Shown
Not Electric Door Lock Assembly
Shown
Not Interior Chamber Fan
Shown
Service Manual
M
N O
P
Q
Model Part Number
100 800972-1
- 120478
- -
- 120202
900 800098-1
1200 800099-1
- 120490
100 800974-1
900/1200 801046-1
100 801027-1
900/1200 801030-1
- 801025-1
