Instruction Manual
HAND-HELD ELECTROSTATIC VOLTMETER
ARS-H002ZA
※ Read this instruction manual before using the product in order to achieve maximum
performance.
※ Keep this instruction manual within your reach after reading so that it can be used at any time.
※ Warranty is on the last page of this manual. Please read the contents and keep it carefully.
28, Namyang-ro 930 beon-gil, Hwaseong-si, Gyeonggi-do, Korea
Tel 82.31.299.5453 Fax 82.31.357.2610
Advertisement
Table of Contents
Related Manuals for DONG IL TECHNOLOGY ARS-H002ZA
Summary of Contents for DONG IL TECHNOLOGY ARS-H002ZA
- Page 1 Instruction Manual HAND-HELD ELECTROSTATIC VOLTMETER ARS-H002ZA ※ Read this instruction manual before using the product in order to achieve maximum performance. ※ Keep this instruction manual within your reach after reading so that it can be used at any time.
-
Page 2: Table Of Contents
DONG IL TECHNOLOGY LTD CONTENTS 1. Features …………………………………………………………………………3 Page 2. Specification ……………………………………………………………………4 Page 3. Package contents………………………………………………………………5 Page 4. Parts name and functions……………………………………………………6 Page 5. Dimension ………………………………………………………………………8 Page 6. Performance ……………………………………………………………………9 Page 7. Operating Instruction ………………………………………………………10 Page 7.1 Power supply[Battery use] 7.5 Ion Balance mode... -
Page 3: Features
100V. In case of Ion Balance mode, it is able to be displayed in unit of 1V. ▶ Rotary sensor head ARS-H002ZA has a rotary head which makes convenient measurement in narrow space. Also a sensing plate for ion balance is designed with rotary integrated structure, so it is more convenient for use and storage of the product. -
Page 4: Specification
DONG IL TECHNOLOGY LTD 2. Specification Dimension(Size) 134.0mm(L) x 68.6mm(W) x 26.0mm(H) Input Voltage +9VDC ±10%(Alkaline battery use) Sensor Oscillating Chopper Type (DIT) Measurement Distance 25mm (±0.5mm) Fixed Precision mode : ±2kV (±10%) Electrostatic mode Expansion mode : ±20kV (±10%) -
Page 5: Package Contents
1.2m USB cable is provided. ④ Earth CABLE--------------------------------------------------------------------------------------------------1ea 3m Earth cable is provided. ⑤ Instruction Manual -----------------------------------------------------------------------------------------1ea Please read this instruction manual before using the product. ① ARS-H002ZA main body ② Battery (6LF22 or 6LR61) ※ Battery is provided in main body ※... -
Page 6: Parts Name And Functions
DONG IL TECHNOLOGY LTD 4. Parts name and functions < Main body name and functions > < Main body (front) > < Main body(rear)> ① ⑦ ② ⑧ ⑨ ④ ⑥ ③ ⑤ Name Description ① SENSING PLATE Use for measuring ION BALANCE ②... - Page 7 DONG IL TECHNOLOGY LTD 4. Parts name and functions < Main body(left) > ④ ① ② < Main body(right) > ③ < Main body(upper) > ⑤ ⑥ Name Description ① U.A.R.T External FIRMWARE terminal ② USB Terminal USB terminal for real time monitoring with PC ③...
-
Page 8: Dimension
DONG IL TECHNOLOGY LTD 5. Dimension < Front View > < Top View > < Side View >... -
Page 9: Performance
DONG IL TECHNOLOGY LTD 6. Performance Display data according to charged voltage Precision mode Charged Voltage(kV) Display data according to charged voltage Expansion mode Charged Voltage(kV) -
Page 10: Operating Instruction
DONG IL TECHNOLOGY LTD 7. Operating Instruction ARS-H002ZA is a portable electrostatic voltmeter, which is affected by environment. Please read carefully the operating instruction below for an exact measurement. 7.1 Power supply[Battery use] 1) Battery socket is disconnected to prevent battery consumption during distribution. - Page 11 DONG IL TECHNOLOGY LTD 7. Operating Instruction 7.3 Setting zero point adjustment In case that the initial value is not “0” though following the measuring set-up(7.2), Please set zero point adjustment as below. 1) Setting zero point adjustment on Electrostatic mode ①...
-
Page 12: Ion Balance Mode
DONG IL TECHNOLOGY LTD 7. Operating Instruction 3) Check the measured value and polarity of voltage on DISPLAY. [ex1. measuring +1.25kV] [ex2. measuring -12.5kV] When “HHH” or “LLL” is displayed, the level of static electricity is over measurable range. Warning!! In this case please stop measuring because integral sensor can be damaged. -
Page 13: Hold Function
DONG IL TECHNOLOGY LTD 7. Operating Instruction 3) Position the sensing plate at ionizer to measure ion balance. Please approach the sensing plate on ionizer to measure ion balance as much as distance between ionizer and object. Ion balance value could be different according to the distance. -
Page 14: Automatic Power Off Function
DONG IL TECHNOLOGY LTD 7. Operating Instruction 4) After checking the fixed value, press [HOLD] button once again. Then, “HOLD” is disappeared and the value and bar graph are changed in real time. Warning!! 1) When the product is turned off on HOLD status, the fixed value is not saved. -
Page 15: Remote Monitoring System By A Software
6) After completing the settings, click “connect” button. Then the program starts. 8.3 Case of disconnecting to monitoring program 1) Check the status of USB cable connecting ARS-H002ZA and PC. 2) Check that the port number of USB driver is same as the port number of software. -
Page 16: Attention
DONG IL TECHNOLOGY LTD 9. Attention ARS-H002ZA is a portable electrostatic voltmeter, which includes susceptible parts. Please read carefully the attention below before use. 1) After Reading the instruction manual, use the product according to instruction manual. 2) Make sure to keep the product away from water/oil/solvent/power/etc. -
Page 17: Trouble Shooting
DONG IL TECHNOLOGY LTD 10. Trouble shooting Problems Check points 1) Check the battery connection 2) Check the battery charge status Power is not supplied 3) If there is no problems above, contact to manufacturer or sales agents. 1) Check that ground cable is connected properly... -
Page 18: Warranty
We provide cost effective, innovative products best suited to your application needs. Warranty We, Dong Il Technology Ltd. Manufactured this product under a strict quality control system and warrants it for1 year of period from the shipment date However, we don’t have any responsibility for...
