- Page 1 Operating instructions Noblesse | Noblesse eco Refrigerator/freezer...
- Page 2 These operating instructions apply to: Model designation Model number Size system Noblesse 51046 SMS 55 / Euro 60 Noblesse eco 51068 SMS 55 / Euro 60 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2019...
-
Page 3: Table Of Contents
Contents 12.2 Note for testing institutes ........ 22 Safety precautions 4 Disposal 23 Symbols used............ 4 General safety precautions........ 4 Index 24 Appliance-specific safety precautions .... 5 Service & Support 27 Appliance installation .......... 5 Instructions for use.......... 5 Using for the first time 8 Appliance description... -
Page 4: Safety Precautions
Safety precautions Symbols used Denotes important safety precau- ▪ This appliance can be used tions. Failure to observe said precautions by children aged 8 and above can result in injury or in damage to and by persons with reduced the appliance or fittings! physical, sensory or mental Information and precautions that capabilities, or lack of experi-... -
Page 5: Appliance-Specific Safety Precautions
1 Safety precautions ▪ Refer to the identification plate for in- turer or its Customer Services formation on the required mains or a similarly qualified person voltage, current type and fuse protec- in order to avoid hazard. tion. ▪ All plastering, plasterboarding, wall pa- Appliance-specific safety pering or painting work is to be carried precautions... - Page 6 1 Safety precautions ▪ WARNING: Do not locate multiple port- the appliance and fittings, as well as af- able socket-outlets or portable power fect the functioning of the appliance. If supplies at the rear of the appliance. the appliance is not working properly or ▪...
- Page 7 1 Safety precautions ▪ Avoid prolonged skin contact with frozen food. Never consume frozen food or ice cubes that are straight out of the freezer compartment or too cold. Risk of burns from freezing! ▪ Do not remove the evaporation tray on the compressor.
-
Page 8: Using For The First Time
Using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▸ Remove packaging and transport materials as well as any protective film from the in- terior. ▸ Clean the interior and accessories with lukewarm water or a mild soapy solution (wa- ter and washing-up liquid) and dry thoroughly. -
Page 9: Operating And Display Elements
4 Operation Operating and display elements Display Fast cooling Refrigerator compartment temperature display Display Freezer compartment temperature display Fast freezing Appliance switched off Buttons ON/OFF Temperature setting, confirming a setting Preselection Select special functions Operation Switching the appliance on ▸ Plug in the appliance at the mains. –... - Page 10 4 Operation Setting the temperature in the cooling compartment The temperature can be set between 2 °C and 9 °C. When the refrigerator compartment temperature is 5 °C, the temperature of the freezer zone is about -18 °C. ▸ Depress the button for 3 seconds. –...
-
Page 11: Special Functions
5 Special functions Special functions Switching the special function on Special function Symbol Remarks Fast cooling next to the tem- ▸ Hold the button perature display for depressed for the refrigerator com- 3 seconds. partment. Fast freezing ▸ Press the button next to the tem- again. -
Page 12: Fast Freezing
5 Special functions Fast freezing The fast freezing function allows large quantities of food, e.g. after a shopping trip, to be frozen more quickly. The function lowers the set temperature of the freezer compart- ment to the coldest set temperature (-24 °C) for 24 hours. The compressor operates at a higher cooling output, which increases the noise level above the normal operating noise level. -
Page 13: Glass Shelves And Door Trays
6 Glass shelves and door trays Glass shelves and door trays The height of the glass shelves in the refrigerator compartment and the door trays on the inside of the refrigerator compartment door can be adjusted. The glass half-shelf enables you to store taller vessels in an upright position. Posi- tion the glass half-shelf at the top to ensure that the air circulates well. -
Page 14: Bottle Drawer
7 Bottle drawer Bottle drawer The temperature in the bottle drawer is about 4–5 °C higher than in the rest of the refri- gerator compartment. Beverages can be chilled at a pleasant drinking temperature in the bottle drawer. The temperatures are also ideal for refrigerating citrus and tropical fruits (e.g. -
Page 15: Tips And Tricks
8 Tips and tricks Tips and tricks General information on using the appliance ▪ When closing an appliance door make sure that it forms a proper seal all the way round. The self-closing hinges help keep it closed: as the appliance doors close auto- matically if the opening angle is between 20–30°. -
Page 16: Storing Food
8 Tips and tricks Storing food The example arrangement (from top to bottom) shows the zones and areas in the appli- ance that are generally suitable for certain food and food items. In the freezer compartment: Freezing and storing food and making ice On the glass shelves: ▪... -
Page 17: Notes On Saving Energy
9 Care and maintenance ▪ Depending on the product, the following packaging materials are suitable: freezer bags, aluminium foil or plastic boxes. Freezer burn can be avoided by making the food packaging as airtight as possible. ▪ Do not refreeze food once defrosted! Only after being prepared (through cooking or frying) can it be refrozen. -
Page 18: Defrosting
9 Care and maintenance Defrosting Defrosting the cooling compartment The cooling compartment defrosts once a day automatically. During defrosting, the temperature inside the cooling compartment increases so that the ice on the rear wall melts. The water created when the ice melts collects in the defrost channel, flows through the drain hole and evaporates outside the appliance in the evaporation tray. -
Page 19: Changing The Led Lighting
9 Care and maintenance ▸ Switch the appliance «off» using the button. ▸ Absorb the water created when the ice melts with a sponge. ▸ After defrosting, clean the interior and dry thoroughly. ▸ Start the appliance again using the button. -
Page 20: Noises And Alarms
10 Noises and alarms Noises and alarms 10.1 Operating noise The appliance can make various noises during operation. Although the appliance is noise-optimized, some noise cannot be eliminated completely. This noise depends on the size of the appliance, how it is installed and the cooling requirements (e.g. fast cool- ing), the ambient temperature and the installation conditions. -
Page 21: Trouble-Shooting
11 Trouble-shooting Cancelling alarm ▸ Touch any button. ▸ Resolve problem, see Trouble-shooting. When the Sabbath mode is activated, there are no visual warning signals. Trouble-shooting This section lists faults that can be solved simply by following the instructions given. If the fault cannot be remedied, please contact Customer Services. -
Page 22: Technical Data
12 Technical data Malfunction Possible cause Solution ▪ Temperature sensor in the ▸ Contact Customer Services. Error display freezer compartment is de- – The appliance enters the emer- fective. gency mode. The freezer com- partment is cooled at the same output level as before the tem- perature sensor malfunction. - Page 23 13 Disposal Disposal 13.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 13.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸...
- Page 24 Index Alarm ..............20 Noises ..............20 Appliance disposal .......... 23 Notes ..............26 Appliance installation ......... 5 ON/OFF ............9, 28 Bottle drawer ............ 14 Operating and display elements...... 9 Operating the appliance ........9 Care and maintenance ........17 Cleaning.............
- Page 25 14 Index Using for the first time........5, 8 Validity..............2 Warning signal..........20...
- Page 26 Notes...
- Page 27 Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
- Page 28 Appliance switched off Buttons ON/OFF Temperature setting, confirming a setting Preselection Select special functions 1010864-R04 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
