SELF-PROPELLED SHOWER/COMMODE CHAIR
Please ensure that these User Instructions are read prior to first use of any moving and handling practice. Prism
Medical UK recommend that prior to using any transfer equipment, a full risk assessment must be completed by a
qualified professional, in order to determine that the correct equipment, positioning and transfer procedure is suitable
for each individual.
● Ensure you are aware of the chair manufacturer's fitting instructions.
● Inspect the chair for wear and damage, with particular attention being paid to the frame, seat and wheels.
Be Aware of LOLER 1998 - (Lifting Operation and Lifting Equipment). For further information please visit:
www.hse.gov.uk/work-equipment-machinery/loler.htm
● Please ensure the arm rests and foot rests are fastened securely. Please test the brakes to ensure they are
functioning properly, before the patient is seated in the chair.
● If following inspection, there is any doubt (points 1-3), the chair should be placed aside and not used.
Your contact :
MACKWORTH M60™
USER GUIDE
PRIOR TO USE
User Manual - M60 Shower/Commode Chair V1.0 April 2015

Advertisement

loading
Need help?

Need help?

Do you have a question about the M60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mackworth M60

  • Page 1 ● If following inspection, there is any doubt (points 1-3), the chair should be placed aside and not used. Your contact : User Manual - M60 Shower/Commode Chair V1.0 April 2015...
  • Page 2: Table Of Contents

    CONTENTS Page No. Information Welcome & Warranty Terms Illustration of Key Parts Introduction to the Chair 6-8. Chair Assembly Instructions Making Adjustments Chair Safety Advice 11-12. Maintenance & Cleaning Technical Specification - Chair Dimensions Spare Parts Listing Shower/Commode Chair Product Range Company Details &...
  • Page 3 WELCOME Congratulations on your purchase. Prism Medical UK are proud that you have purchased one of our high quality shower/ commode chairs. These products have been manufactured to the highest standards to ensure optimum product strength and performance as assistive equipment. WARRANTY TERMS 1.
  • Page 4: Illustration Of Key Parts

    ILLUSTRATION OF KEY PARTS Back Upholstery Armrest Backrest Frame Armrest Brake Set Base Frame Legrest 24” Rear Wheel Front Fork Footrest Front Wheel...
  • Page 5 INTRODUCTION The shower/commode chair will arrive to you in a robust box and requires full assembly. Please be careful when removing the parts from the box. The assembly process may require two people. Please read the User Guide in full BEFORE assembling and using. All staff/carers should read this guide as a basis to ensure safe and secure use of the shower/commode chair.
  • Page 6: Chair Assembly Instructions

    CHAIR ASSEMBLY INSTRUCTIONS Carefully open the box (SAFETY NOTICE - Do not use a sharp knife / edge) remove all loose parts/excess packaging from the carton. The Chair Carton Contains:-...
  • Page 7 Assembly Instructions 1. Assemble left frame, right frame & backrest. Locate screw A and insert into horizontal bar, DO NOT tighten. Locate screw B and insert into frame. Afterwards, tighten both screws A & B. 2. Place seat and round bowl into position. IMPORTANT - ensure round bowl is fitted in the correct position/direction.
  • Page 8 3. To assemble armrests, left foot plate & right foot plate, simply click into position as highlighted. 4. To assemble left & right wheel lock, simply click into position as highlighted. To disassemble for cleaning, transportation or storage purposes, simply reverse this procedure.
  • Page 9 ADJUSTING THE ARMRESTS To adjust the height of the armrest, simply press the stud and raise the armrest to the desired height/position. Ensure they are locked in position before use. Armrests should be in place at ALL times whilst the chair is in use. ADJUSTING THE FOOTPLATES To adjust the height of the footrest, simply press the stud, adjust and then lock into position as highlighted.
  • Page 10: Chair Safety Advice

    CHAIR SAFETY ADVICE Please ensure you read the following safety advice. This will ensure all procedures are made easy and trouble free. ● Always carry out the risk assessment and plan your procedure before commencing a moving & handling practice. ● Always carry out the daily check list before using the chair. ● Always read the user manual and ensure you are familiar with the user instructions and safety features of the chair before transporting a patient. ● Always check the safe working load (SWL) of the chair is suitable for the weight of the patient. ●...
  • Page 11: Maintenance & Cleaning

    MAINTENANCE & CLEANING These are recommended to be checked on a daily or regular basis and the chair should be serviced annually by an authorised agent. 1. CHECK any screws are fastened securely. 2. CHECK the wheels/tyres for excessive wear and damage. 3.
  • Page 12 MAINTENANCE & CLEANING 1. Clean the seat and backrest thoroughly with a damp cloth and warm soapy water after each use. 2. Use a damp cloth to wipe clean the frame parts and armrests also. 3. For heavier stains a mild diluted solution may be used. A solution of 0.1% Sodium Hypochlorite is recommended but ensure the seat/backrest is rinsed thoroughly with clean water to ensure full removal of the solution.
  • Page 13 TECHNICAL SPECIFICATIONS Chair Dimensions & Weight Limit Weight Limit 18 Stone / 120 kg Seat Width 46-56 cm Seat Height 50 cm Seat Depth 42 cm Overall Width 65 cm Overall Height 90 cm Back Height From Seat 39 cm Arm Height From Seat 12-22 cm Product Weight...
  • Page 14 M60™ Spare Parts List Item Number Description NNW04-K0201 Back Upholstery BAR04-A Armrest NNW04-A29 PU Seat Pad N1.178-30 Round Bowl BWL05-A Brake NFKP5-C Front Fork NWPU5-B Front Wheel NRW24-S 24" Rear PU Wheel For pricing information, please contact Customer Services on 01924 840100.
  • Page 15: Shower/Commode Chair Product Range

    SHOWER/COMMODE CHAIR PRODUCT RANGE M80™ Tilt-In-Space Shower/Commode Chair M40™ Shower/Commode Chair M20™ Commode Chair...
  • Page 16 Alternatively, for any further help, information or advise please contact us at: Prism Medical UK Registered Office, Unit 4, Jubilee Business Park, Grange Moor, Wakefield. WF4 4TD 01924 840100 Email: info@prismmedical.co.uk www.prismmedical.co.uk Prism Medical UK Manufacturing Centre Millers Avenue, Brynmenyn Industrial Estate, Brynmenyn, Bridgend. CF32 9TD 01924 840100 Email: sales@mackworth-healthcare.com www.mackworth-healthcare.com...
