ZyAura ZG106R Operating Instructions

ZG106R CO

Product Overview

Thank you for selecting ZG106R desktop CO
CO concentration, ZG106R can also measure the ambient temperature and the relative humidity. This product is developed to detect the
2
presence of CO monitor in ambient air and help people to take care of Indoor Air Quality. ZG106R can be widely used in the office building,
2
school, exhibition, shopping mall, meeting room, fitness center, restaurant and other pubic place where personal comfort, healthy is important.

Features:

□ V The built-in Datalogger can store 48 sets of CO
□ V Max/Min mode can record the maximum and minimum concentration of CO
□ V The Alarm mode the Alarm Level can be adjustable by user.
□ V The RcFS Mode can recover the original factory settings after the CO
(Display features and modes)

Mode Functions

There are several Modes which can be adjusted by user. These modes are MUTE Mode, ALTI Mode, ALARM Mode, OUTSIDE Mode, CALI
Mode, LOG Mode, MaxMin Mode and RcFS Mode in sequence.
The sound alarm can be
MUTE setting on/off under Mute
Mode.
Alarm while CO
exceed one threshold, alarm
ALARM
level can be adjusted by user
Level
the Alarm sound can be turn
on/off under Mute mode.
Calibrate the sensor while the
CALI reading deviates from the
actual CO
2
Show the Max and Min CO
MaxMin reading before being cleared
or after PowerOn.

Safety Instructions

Warning: Your safety is very important to us .To ensure to use the product correctly and safely, we would like to draw your attention to read the
warning and entire User Manual before using the product. These are important safety information and should be observed at all times.
1. Please handle the devices lightly, do not subject the product to impact or shock. Otherwise, this may cause the accuracy drift.
2. Do not immerse the product in water. Water can cause electric shock, fire or malfunction which may result in damage.
3. Do not keep the product under the hot and moisture environment. Keep the product away form the heat source or near water.
4. Please use only the included power adaptor. Improper power adaptor or power sources can cause serious damage to the product, or result in
injury or death to the user.
and Temperature Monitor Operating Instructions
2
monitor, ZG106R CO
2
, temperature and RH in the past 24 hours; one log per 30 minutes.
2
1. Power Button
2. Enter Button
3. Down Button
4. Up Button
5. Mode Button
6. LCD Display
7. LED Light
concentration
2
concentration.
2
monitor is smart, compact and easy-to-use. In addition to measuring the
2
since the device has been last turned on.
2
device has been recalibrated, altered, or damaged.
2
8. Function Label
9.Gas Entry Hole
10. Power inlet
11. RJ45 socket
12. Housing Stand
13. Battery Cover
14. AA Batteries*4
Compensate the pressure
changes with appropriate
ALTI
altitude of location when
measure.
Modify the outside CO
OUTSIDE concentration for calculating
the ventilation rate.
Show the past CO
LOG temperature and RH records
in the past 24 hours.
Recover the factory setting to
RcFS
cancel customize setting.
2
,
