ZyAura ZG1163R Operating Instructions

ZG1163R CO

Product Overview

Thank you for selecting ZG1163R desktop CO
concentration, ZG1163R can also measure the ambient temperature and the relative humidity. This product is developed to detect the presence of CO
ambient air and help people to take care of Indoor Air Quality. ZG1163R can be widely used in the office building, school, exhibition, shopping mall, meeting
room, fitness center, restaurant and other pubic place where personal comfort, healthy is important.

Features:

□ V The built-in Data logger can store 48 sets of CO
□ V Max/Min mode can record the maximum and minimum concentration of CO
□ V The Alarm mode the Alarm Level can be adjustable by user.
□ V The RCFS Mode can recover the original factory settings after the CO
1.Enter Button 4. Mode Button
2. Down Button 5. LCD display
3. Up Button 6.Green LED Display (<800ppm)
(Display features and modes)

Mode Functions

There are several Modes which can be adjusted by user. These modes are Mute Mode, ALTI Mode, ALARM 1 Mode, ALARM 2 Mode, OUTSIDE Mode, CALI Mode,
LOG Mode, MaxMin Mode and RcFS Mode in sequence.
The beep alarm can be setting
MUTE
on/off under Mute Mode
The first alarm level can be
ALARM 1
adjusted by user
Modify the outside CO
OUTSIDE concentration for calculating
the ventilation rate
Show the past CO
LOG Temperature and RH records in
the past 24 hours
Recover the factory setting to
RcFS
cancel customize setting

Safety Instructions

Warning: Your safety is very important to us .To ensure to use the product correctly and safely, we would like to draw your attention to read the warning and entire User Manual
before using the product. These are important safety information and should be observed at all times.
1. Please handle the devices lightly, do not subject the product to impact or shock. Otherwise, this may cause the accuracy drift.
2. Do not immerse the product in water. Water can cause electric shock, fire or malfunction which may result in damage.
3. Do not keep the product under the hot and moisture environment. Keep the product away form the heat source or near water.
4. Please use only the included power adaptor. Improper power adaptor or power sources can cause serious damage to the product, or result in injury or death to the user.

Caring for product

To ensure you receive the maximum benefit from using this product, please observe the follow guidelines.
1. Cleaning— Disconnect the power before clean. Use a damp cloth, do not use the liquid cleaning agent, such as benzene, thinner or aerosols.
2. Repair----Do not attempt to repair the product or modify the circuitry by yourself. Please contact with the local dealer or a qualified repairman if the product needs servicing.
and Temperature Monitor Operating Instructions
2
monitor, ZG1163R CO
2
and temperature and RH in the past 24 hours; one log per 30 minutes.
2
7. Yellow LED Display (800-1200ppm)
8. Red LED Display (>1200ppm)
9.Gas Entry Hole
2
,
2
monitor is smart, compact and easy-to-use. In addition to measuring the CO
2
since the device has been last turned on.
2
device has been recalibrated, altered, or damaged.
2
Compensate the pressure
changes with appropriate
ALTI
altitude of location when
measure
The second alarm level can be
ALARM 2
adjusted by user
Calibrate the sensor while the
CALI reading deviates from the
actual CO
Show the Max and Min CO
MaxMin reading before being cleared or
after Power On
10. Power inlet
11. RJ45 socket (only for factory use)
12. Ventilation Slots
concentration
2
2
2
in
2
