Williams AV Digi-Wave 300 Series User Manual

Digital transceiver/receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Digi-Wave
300 Series
™
DLT 300 Digital Transceiver and DLR 360 Digital Receiver
USER MANUAL
DLT 300
DLR 360
The Digi-Wave 300 Series is not backward compatible with previous generation transceivers or receivers.
This includes the DLT 100, DLT 100 2.0, DLR 50, DLR 60, and DLR 60 2.0.
MAN 195H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Digi-Wave 300 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Williams AV Digi-Wave 300 Series

Summary of Contents for Williams AV Digi-Wave 300 Series

  • Page 1 DLT 300 Digital Transceiver and DLR 360 Digital Receiver USER MANUAL DLT 300 DLR 360 The Digi-Wave 300 Series is not backward compatible with previous generation transceivers or receivers. This includes the DLT 100, DLT 100 2.0, DLR 50, DLR 60, and DLR 60 2.0. MAN 195H...

  • Page 2: Table Of Contents

    DigiWave 300 Series Digital Transceiver and Receiver Digi-Wave™ 300 Series DLT 300 Digital Transceiver and DLR 360 Digital Receiver Contents Safety Warnings and Recycling Instructions ..............................3 System Overview ........................................4 DLT 300 Controls and Connectors ..................................5 DLT 300 Operation ........................................5 DLR 360 Controls and Connectors ..................................7 DLR 360 Operation ........................................7 Getting Started: Preprogrammed Systems ................................

  • Page 3: Safety Warnings And Recycling Instructions

    DigiWave 300 Series Digital Transceiver and Receiver Safety Warnings and Recycling Instructions HEARING SAFETY CAUTION! This product is designed to amplify sounds to a high volume level which could potentially cause hearing damage if used improperly. To protect your hearing and the hearing of others: (1) Turn the volume down before putting on the earphone or headphone, and then adjust the volume to a comfortable level, (2) Set the volume level at the minimum setting that you need to hear, (3) if you experience feedback (a squealing or howling sound), reduce the volume setting and move the microphone away from...

  • Page 4: System Overview

    “DLR”. Similarly, Master 1, Master 2 and Guest may be referred to as “M1”, “M2”, and “GST”. The Digi-Wave 300 Series is not backward compatible with previous generation transceivers or receivers (DLT 100, DLT 100 2.0, DLR 50, DLR 60, and DLR 60 2.0).

  • Page 5: Dlt 300 Controls And Connectors

    DigiWave 300 Series Digital Transceiver and Receiver DLT 300 Controls and Connectors INTERNAL SPEAKER LCD DISPLAY LED INDICATORS TALK BUTTON WITH RAISED BRAILLE DOT VOLUME / SELECT UP VOLUME / SELECT DOWN POWER / MENU HEADPHONE JACK 3.5 MM MICROPHONE JACK 3.5 MM INTERNAL MICROPHONE DOCKING / CHARGING CONNECTOR 30-PIN...
  • Page 6 DigiWave 300 Series Digital Transceiver and Receiver MICROPHONE LEVEL ADJUSTMENT This setting adjusts the input level of either (1) the internal microphone, or (2) an external microphone plugged into the mic jack. · Hold the button for two seconds to enter mic level adjustment. Use to adjust the level.

  • Page 7: Dlr 360 Controls And Connectors

    DigiWave 300 Series Digital Transceiver and Receiver BATTERY CHARGING HEADPHONE LANYARD SLOT JACK 3.5 MM · The DLT 300 uses an internal rechargeable Lithium Polymer battery. · Use the 30 Pin connector, located on the bottom of DLT 300, to charge the battery. Charge by either (1) using an external STRENGTH DLT NO.
  • Page 8 DigiWave 300 Series Digital Transceiver and Receiver · If the units are synchronized, briefly push the power button to show group assigned (0 to 99). · The DLR will automatically power down after 5 minutes if not synchronized with a DLT. CHANGE GROUPS ·...

  • Page 9: Getting Started: Preprogrammed Systems

    DigiWave 300 Series Digital Transceiver and Receiver Getting Started: Preprogrammed Systems If a system has been purchased, you should not need to perform any programming. The system will have been configured to your order. Turn Master 1 on first so other units can pair. Guest units will turn off after 5 minutes if they cannot find a master. 1.

  • Page 10: Before Programming The Digi-Wave™ System

    DigiWave 300 Series Digital Transceiver and Receiver Before Programming the Digi-Wave™ System Depending upon the mode chosen, up to six people can talk in a group at any given time. The M1 will have first priority, M2 has second priority and Guest units have third priority. When two or more people are talking in a group, the participants can hear their voices with the DLTs or DLRs.
  • Page 11 DigiWave 300 Series Digital Transceiver and Receiver 1-way - Repeater Mode: (Units out of range of the primary unit(s) receive their broadcast from these units) 1-way - Interpretation with Relay Mode: This allows the interpreter to quickly switch between listening to the Floor or the Relay. For example, the floor may be speaking in English and the interpreter is interpreting English to Spanish.

  • Page 12: Programming The Digi-Wave™ System: 1-Way Modes

    DigiWave 300 Series Digital Transceiver and Receiver Programming the Digi-Wave™ System: 1-way Modes There are 4 basic steps to programming a Digi-wave system: Set Mode: 2-way or 1-way Set Priority: Master 1, Master 2, and Guest Set Channel Set Group Number Most of the programming is done on the DLT(s);...

  • Page 13: Programming The Digi-Wave™ System: 2-Way Modes

    DigiWave 300 Series Digital Transceiver and Receiver Programming the Digi-Wave™ System: 2-way Modes There are 4 basic steps to programming a Digi-wave system: Set Mode: 2-way or 1-way Set Priority: Master 1, Master 2, and Guest Set Address Set Group Number Most of the programming is done on the DLT(s);...

  • Page 14: Programming The Digi-Wave™ System: Optional Settings

    DigiWave 300 Series Digital Transceiver and Receiver Programming the Digi-Wave™ System: Optional Settings Original (save) DLT Secure Key Code: When a group has been set up and the same Secure Code has been entered into all the DLTs, the DLTs without this Secure Code entered cannot listen in on the group.
  • Page 15 Original (save) DigiWave 300 Series Digital Transceiver and Receiver Secure Key Code fig. 1 Secure Key Code fig. 2 SLOC fig. 3 Tone Control fig. 4 Quick Group Change fig. 5 Original (save) DLT Quick Group Change Secure Key Code fig. 1 Secure Ke “Groups”...

  • Page 16: Example 1: Tour Guide (2-Way, Up To 4 Open Microphones)

    1-way Modes 2-way Modes Speak Only Simultaneous DigiWave 300 Series Digital Transceiver and Receiver (Main Speaker) Interpretation Repeater Receive Only Relay Intercom Tour Guide Receive Only Example 1: Tour Guide (2-way, up to 4 open microphones) 6 talkers max 4 talkers max HOW IT WORKS 1-way Modes 2-way Modes Up to four (4) people can have open microphones (TALK button on) and be talking at the same time.
  • Page 17 DigiWave 300 Series Digital Transceiver and Receiver 2-way Tour Guide Setup 2-WAY SETUP FOR TOUR GUIDE OPERATION (MASTER UNIT SHOWN) Press and hold POWER Press and Hold The other icons will disappear Use the buttons button for 2 seconds for 3 seconds to enter and the current mode icon to change to 2-way Tour to turn DLT ON...

  • Page 18: Example 2: Simultaneous Interpretation Mode (1-Way, Up To 14 Languages)

    DigiWave 300 Series Digital Transceiver and Receiver Example 2: Simultaneous Interpretation Mode (1-way, up to 14 languages) HOW IT WORKS The “Floor” unit (main presenter) transmits on channel 0. All interpreter units receive the Floor on channel 0, and transmit the Interpreter’s voice on channels 1-14.
  • Page 19 1-way Modes 2-way Modes Speak Only Simultaneous (Main Speaker) Interpretation Repeater Receive Only Relay Intercom Tour Guide Receive Only DigiWave 300 Series Digital Transceiver and Receiver 1-WAY SETUP FOR SIMULTANEOUS INTERPRETATION 6 talkers max 4 talkers max 1-way Modes 2-way Modes Speak Only Simultaneous (Main Speaker)
  • Page 20 DigiWave 300 Series Digital Transceiver and Receiver 2. Program the Guest unit(s). Each unit gets programmed for the channel it will be transmitting on. For example Spanish on Ch 1, 1-way Simultaneous Interpretation Setup French on Channel 2, etc. These units will have the bilingual option, but in this example we’ll leave this feature off (disabled). (Guest Unit setup for Bilingual Mode) Press and hold POWER Press and Hold...

  • Page 21: Example 3: Bilingual Mode

    DigiWave 300 Series Digital Transceiver and Receiver Example 3: Bilingual Mode HOW IT WORKS Bilingual mode is a sub-mode within Simultaneous Interpretation Mode. This mode allows the interpreter to quickly switch their output channel between Ch. 1 or Ch. 2, depending on which language/audience needs to hear them. This mode eliminates the need for the interpreter to use - and physically switch between - 2 DLT units programmed to fixed channels.
  • Page 22 DigiWave 300 Series Digital Transceiver and Receiver 1-WAY SETUP FOR BILINGUAL OPERATION 1. Program the Master unit: 1-way Modes 2-way Modes Speak Only Simultaneous (Main Speaker) Interpretation Repeater Receive Only Relay Intercom Tour Guide Receive Only 6 talkers max 4 talkers max 1-way Simultaneous Interpretation Setup (Master-Talk Only) 1-way Modes 2-way Modes...
  • Page 23 Speak Only Simultaneous (Main Speaker) Interpretation Repeater Receive Only Relay Intercom Tour Guide Receive Only DigiWave 300 Series Digital Transceiver and Receiver 6 talkers max 4 talkers max 2. Program the Guest unit(s). 1-way Modes 2-way Modes Speak Only Simultaneous (Main Speaker) Interpretation Repeater...

  • Page 24: Example 4: Interpretation With Relay Mode

    DigiWave 300 Series Digital Transceiver and Receiver Example 4: Interpretation with Relay Mode HOW IT WORKS Interpretation With Relay Mode differs slightly from Simultaneous Interpretation Mode. This mode allows the interpreter to quickly switch between listeing to the Floor on Channel 0 or the Relay on Channel 1. In this example the Floor is speaking Japanese.
  • Page 25 DigiWave 300 Series Digital Transceiver and Receiver 1. Program the Master unit: 1-way Modes 2-way Modes Speak Only Simultaneous (Main Speaker) Interpretation Repeater Receive Only Relay Intercom Tour Guide Receive Only 1-way Simultaneous Interpretation Setup 6 talkers max 4 talkers max (Master-Talk Only) 1-way Modes 2-way Modes Speak Only...
  • Page 26 1-way Modes 2-way Modes Speak Only Simultaneous DigiWave 300 Series Digital Transceiver and Receiver (Main Speaker) Interpretation Repeater Receive Only Relay Intercom Tour Guide Receive Only 6 talkers max 4 talkers max 2. Program the Guest unit(s). Each unit gets programmed for the channel it will be transmitting on. Bilingual Mode and Relay Mode cannot be used together, so these units will NOT display the bilingual option during programming.
  • Page 27 DigiWave 300 Series Digital Transceiver and Receiver 3. Finished units should look like this: Finished Units: Relay Mode Master Unit Guest Unit 1 Guest Unit 2 Guest Unit 2 (relay selected) 4. To listen to the Floor push ; to listen to the Relay push Regarding programming and operation: - In Interpretation with Relay Mode, “Bilingual Mode”...

  • Page 28: Example 5: Intercom (2-Way, Up To 6 Open Microphones)

    DigiWave 300 Series Digital Transceiver and Receiver Example 5: Intercom (2-way, up to 6 open microphones) HOW IT WORKS Up to six (6) people can have open microphones (TALK button on) and be talking at the same time. One DLT is set up as a Master 1 How it Works: 6-way Intercom unit.
  • Page 29 Speak Only Simultaneous (Main Speaker) Interpretation Repeater Receive Only Relay Intercom Tour Guide Receive Only DigiWave 300 Series Digital Transceiver and Receiver 6 talkers max 4 talkers max 2-WAY SETUP FOR INTERCOM 1-way Modes 2-way Modes Speak Only Simultaneous (Main Speaker) Interpretation Repeater Receive Only...

  • Page 30: Example 6: Repeater Mode

    DigiWave 300 Series Digital Transceiver and Receiver Example 6: Repeater Mode HOW IT WORKS An additional DLT 300 can be set-up as a repeater to increase the range of each channel. To use Repeater Mode, first set up the system using instructions under Example 2 for Simultaneous Interpretation. Then set up the repeater units as shown here. When repeater mode is used, the Repeater is configured as the Master, and all units sync to this Master Repeater.
  • Page 31 1-way Modes 2-way Modes Speak Only Simultaneous DigiWave 300 Series Digital Transceiver and Receiver (Main Speaker) Interpretation Repeater Receive Only Relay Intercom Tour Guide Receive Only REPEATER MODE SETUP 6 talkers max 4 talkers max 1-way Modes 2-way Modes Speak Only Simultaneous (Main Speaker) Interpretation...
  • Page 32 DigiWave 300 Series Digital Transceiver and Receiver Finished units should look like this: Main Speaker (Floor) Main Speaker (Floor) Interpreter Interpreter Repeater DLT Repeater DLTs DLTs Must be set to 1-way, Must be set to 1-way, Must be set to 1-way, Must be set to 1-way, Talk-Only mode, GUEST, Repeater mode, MASTER,...

  • Page 33: Differences Between Dlt 300, Dlt 100 2.0 And Dlt 100

    DigiWave 300 Series Digital Transceiver and Receiver Differences between DLT 300, DLT 100 2.0 and DLT 100 Function/Description DLT 300 DLT 100 2.0 DLT 100 With settings locked, can adjust With settings locked, can ONLY With settings locked, can ONLY adjust SLOC Power, Volume, Talk, Tone, Mic adjust Power, Volume, Talk...

  • Page 34: Differences Between Dlr 360, Dlr 60 2.0 And Dlr 60

    DigiWave 300 Series Digital Transceiver and Receiver Differences between DLR 360, DLR 60 2.0 and DLR 60 Between 08/13 and 11/13, a limited number of DLR 60’s were manufactured and sold to the marketplace. If the front of the unit says “Digi·WAVE”, you have a DLR 60.

  • Page 35: Specifications - Dlt 300 Transceiver

    DigiWave 300 Series Digital Transceiver and Receiver Specifications - DLT 300 Transceiver Dimensions 4.07”W x 2.43”H x 0.44”D (103.3 mm x 61.8 mm x 11.3 mm) Weight 2.9 oz (82 g) including battery Color Black/Silver (Front/Back) Case Material Black ABS plastic Battery type Lithium Polymer with smart charge built into transceiver;...

  • Page 36: Testing And Certification

    DigiWave 300 Series Digital Transceiver and Receiver Specifications - DLR 360 Receiver Dimensions: 2.36” W x 3.54” H x 0.63” D (60 mm x 90 mm x 16 mm) Weight: 1.7 oz. (47g) without batteries. Frequency Band: 2.4 GHz (ISM band) Modulation: FSK Multi Channel: Up to 15 simultaneous channels (one way mode) Case Material: Black ABS Plastic...

  • Page 37: Troubleshooting

    DigiWave 300 Series Digital Transceiver and Receiver Troubleshooting PROBLEM CAUSE WHAT TO DO Power does not turn-on Dead battery Charge the battery, replace battery Power turned off automatically Master device can’t be found Turn on Master unit Power doesn’t turn off Program Error Press reset button on the back of device (DLT only) Disconnection of headphone...

  • Page 38: Frequently Asked Questions

    DigiWave 300 Series Digital Transceiver and Receiver Frequently Asked Questions What is the range of the system? Up to 200 ft outdoors and up to 300 ft indoors. (Range depends on environmental conditions). What is the benefit of this system over the 72 MHz (FM) systems? •...

  • Page 39: 2-Year Warranty

    DigiWave 300 Series Digital Transceiver and Receiver 2-year Warranty Williams Sound products are engineered, designed, and manufactured under carefully controlled conditions to provide you with many years of reliable service. Williams Sound warrants the DLT 300 and DLR 360 against defects in materials and workmanship under normal use and conditions for 2 years from date of purchase.
  • Page 40 / www.williamsav.com 800-843-3544 / INTL: +1-952-943-2252 © 2018, Williams AV, LLC MAN 195I...
