- Page 1 AGD-200 Wireless glass-break detector Firmware version 1.00 agd-200_en 03/19 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.eu...
- Page 2 The rating plate of the device is located on the enclosure base. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
- Page 3 The AGD-200 detector enables detection of a break of plate, tempered and laminated glass. It is designed for operation within the ABAX 2 / ABAX two-way wireless system. This manual applies to the detector with firmware version 1.00 (or newer), which is supported by: ...
- Page 4 AGD-200 SATEL The detector operating mode is turned on remotely. If the detector is used in the INTEGRA / VERSA alarm system, the operating mode may depend on the partition state (partition disarmed – passive mode; partition armed – active mode). For more information, refer to the ABAX 2 / ABAX controller manual / the INTEGRA 128-WRL control panel manual.
- Page 5 SATEL AGD-200 4. Installation There is a danger of battery explosion when using a different battery than recommended by the manufacturer, or handling the battery improperly. Be particularly careful during installation and replacement of the battery. The manufacturer is not liable for the consequences of incorrect installation of the battery.
-
Page 6: Specifications
AGD-200 SATEL with serial number which shall be entered when registering the detector in the system can be found on the electronics board. In the INTEGRA / VERSA alarm system, the detector is identified as AGD-100. Simultaneous operation of the detector by the ABAX 2 and ABAX controller / INTEGRA 128-WRL alarm control panel is not possible. - Page 7 SATEL AGD-200 Detection range ......................up to 6 m Complied with standards..........EN 50130-4, EN 50130-5, EN 50131-5-3 Environmental class according to EN50130-5 ................. II Operating temperature range................-10°C...+55°C Maximum humidity ......................93±3% Dimensions ....................20 x 102 x 23 mm Weight..........................39 g...
