Summary of Contents for Atlas Copco CLG 10
- Page 1 10, 10 US, 30, 30 US Safety and operating instructions Lubricators © 2015 Construction Tools PC AB | No. 9800 1172 01a | 2015-04-10 Original instructions...
-
Page 3: Table Of Contents
CLG 10, 10 US, 30, 30 US Contents Contents Introduction............... . 5 About the Safety and operating instructions. -
Page 5: Introduction
Safety and operating instructions Introduction Thank you for choosing a product from Atlas Copco. Since 1873, we have been committed to finding new and better ways of fulfilling our customers' needs. Through the years, we have developed innovative and ergonomic product designs that have helped customers improve and rationalize their daily work. -
Page 6: Safety Instructions
Safety and operating instructions CLG 10, 10 US, 30, 30 US Drugs, alcohol or medication Safety instructions WARNING Drugs, alcohol or medication To reduce the risk of serious injury or death to Drugs, alcohol or medication may impair your yourself or others, read and understand the Safety judgment and powers of concentration. -
Page 7: Maintenance, Precautions
CLG 10, 10 US, 30, 30 US Safety and operating instructions DANGER Ejection of the oil dosage screw hazard The spring pin is a safety stop that prevents the oil dosage screw from being ejected. If the oil dosage screw comes loose it can be ejected and cause personal injury. -
Page 8: Overview
Design and function CLG 10 and CLG 30 are designed to lubricate compressed air equipment, using mineral- or synthetic oil. No other use is permitted. Air flows into the lubricator through the inlet. Some... -
Page 9: Safety Label
Oil adjustment Installation CLG 10 and 30 are delivered with the oil dosage screw in the fully open position. The oil dosage screw can be turned through a total of four complete turns. Hoses and connections It is steplessly adjustable. -
Page 10: Maintenance
Safety and operating instructions CLG 10, 10 US, 30, 30 US Unscrew the filler plug by two turns, which opens ♦ Assembly instruction the venting duct and releases any remaining compressed air in the lubricator. When reassembling the claw couplings on the Fill the lubricator with oil. -
Page 11: Storage
CLG 10, 10 US, 30, 30 US Safety and operating instructions Make sure that there is no dirt in the oil chamber ♦ (G). Storage Clean the lubricator properly before storage, in ● order to avoid hazardous substances. ● If the lubricator is stored filled with oil, place it with the filler plug upwards to prevent oil from leaking out through the mouth of the air pipe. -
Page 12: Technical Data
Safety and operating instructions CLG 10, 10 US, 30, 30 US Technical data Machine data Pressure drop at 6 bar and Weight Volume max. flow Air flow range Dosage (free air) bar (e) Type (lb) (oz) (psi) (cfm) CLG 10 0.1-2.4... - Page 16 Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers, and drawings. www.atlascopco.com...
