Classic Bubbler
Cold Beverage Dispensers
Table of Contents
Unpacking & Installation Instructions ................... 3
Assembly .............................................................. 4
Product Preparation ............................................. 5
Disassembly .......................................................... 6
Routine Maintenance ............................................ 7
Helpful Hints .......................................................... 7
Preventative Maintenance ..................................... 8
Troubleshooting Guide ........................................... 9
Parts Identification ................................................. 10
MCX Mag-Drive Impeller ........................................ 12
Prior authorization must be obtained from GMCW for
all warranty claims.
Retain this manual for future reference.
© GMCW, 2004
Printed in USA
Operation Manual
D Series
E Series
Premix
™
(800) 695-4500 (USA & Canada only)
GMCW
™
4003 Collins Lane
Louisville, KY 40245 USA
(502) 425-4776
Fax: (502) 425-4664
Email: info@gmcw.com
www.gmcw.com
0214 Form # CC-377-07
Part # 3682
Advertisement
Table of Contents
Related Manuals for GMCW Crathco Classic Bubbler D Series
Summary of Contents for GMCW Crathco Classic Bubbler D Series
-
Page 1: Table Of Contents
Helpful Hints ............7 Preventative Maintenance ........8 Troubleshooting Guide ........... 9 Parts Identification ..........10 MCX Mag-Drive Impeller ........12 Prior authorization must be obtained from GMCW for all warranty claims. Retain this manual for future reference. GMCW ™... -
Page 2: Unpacking & Installation Instructions
SET-UP UNPACKING Your dispenser is packed in 2 cartons: base pack and bowl pack. Unpack base by opening bottom flaps. See Figure A. 1. Roll chassis 2. Open bottom flaps. up-side down Fold back. IMPORTANT NOTES: 1. Do not leave base upside down as this can damage refrigeration system. -
Page 3: Assembly
Assembly place BeaRinG sleeVe On place pUMp cOVeR OVeR GUiDe pin GUiDe pin place the pump cover over the guide pin with the spray tube toward the front. note flat sides on outside of note that the tab on the front of the pump guide pin and on inside of cover fits between the 2 locator buttons bearing sleeve. -
Page 4: Product Preparation
Assembly (cont.) FILL BOWL(S) WITH PRODUCT and place lid(s) on bowl(s). Turn spray switch on first then refrigeration. IMPORTANT: NEVER RUN REFRIGERATION UNLESS SPRAY OR AGITATE IS ON. Product Preparation BEFORE PREPARING PRODUCT: POUR CONCENTRATE INTO DISPENSER then add remaining water per product label. a) Wash hands thoroughly before handling dispenser or product. -
Page 5: Disassembly
DISASSEMBLY DRAIN ALL BEVERAGE FROM BOWLS REMOVE BOWL AND BOWL GASKET A. Remove bowl lid(s) and drip tray(s) Twist bowl back and forth B. Drain through valve then while lifting up. Bowl gasket C. Tip unit forward, gently press spray will be around bottom of tube back a short distance to lift the bowl. -
Page 6: Routine Maintenance
ROUTINE MAINTENANCE: For all Models Cleaning Your Dispenser To optimize performance or when using dairy products, clean unit daily. Regular cleaning of bowl components will result in maximum pumping efficiency, proper seating and sealing, and prevention of leaks at the valve O-Ring and bowl gasket by removing dried-on beverage solids and pulp from mov- ing sealed parts. -
Page 7: Preventative Maintenance
(Remove dust and lint edges may cause personal injury or Figure H from fins with a soft brush and vacuum.) damage to machine. 5) For further information, visit www.gmcw.com or call +1-502-425-4776. Part #s for Preventative Maintenance Bearing sleeve and impeller Description... -
Page 8: Troubleshooting Guide
• Unplug unit and re-bend fan blade to correct alignment If you still need help, call an authorized service center in your area or call GMCW’s Technical Service Department. You can reach Technical Service at (800) 695-4500 (USA & Canada only) or 1-502-425-4776 Monday-Friday, 8:00 AM-6:00 PM Eastern Standard Time. -
Page 9: Parts Identification
STANDARD BOWL ASSEMBLY PARTS 1010A 2266 2484 1013 1161/3587 1288 1261 1734 1090 1092 1012 3220 1741 1742 1735 1740 Part # Description Models Used On 1010A Dispense Valve w/ O-ring All standard (non-whipper) 1012 O-ring for Dispense Valve 1013 Standard Bowl Gasket All D15, D25, D35, HD and WD models (for 5 & 3 gallon bowls) 1090... - Page 10 MINI BOWL ASSEMBLY PARTS 1010A 2802 1012 1994 2914 3220 1008 3587 2910 3629 2999 3335 2010 2012 2660 3330 2232 2231 2682 Part # Description 1008 Mini Bowl Impeller (red) 1010A Dispense Valve w/ O-ring 1012 Dispense Valve O-ring 1994 7 Liter Bowl 2010 Mini Bowl Gasket 2012...
-
Page 11: Mcx Mag-Drive Impeller
(1742 may also be used on 60 Hz units) used on 60 Hz units) (or 3 gal.) Tel +1-502-425-4776 • Fax +1-502-425-4664 • 1-800-695-4500 • www.gmcw.com • email: info@gmcw.com © GMCW, 2004 0214 Form # CC-377-07 Part # 3682 PRINTED IN USA...
