User Manual GeoChaser Control
1.Introductie
The GeoChaser Control is a powerful GPS tracking system designed for tracking of vehicles
and reading out driver identification. The device has superior reception sensitivity, fast
positioning and supports four-band GSM frequencies 850/900/1800/1900, the location can
be viewed real-time on your personal 12Trace page or in the mobile App. The GeoChaser
has multiple in/outputs that can be used for monitoring or control of external devices. The
GeoChasers communicate with the GPRS/GSM network and can alert you when crossing a
virtual fencing (Geofence), low back-up battery or low communication credits.
Your GeoChaser uses the Global Positioning System (GPS). The GPS system is
maintained by the U.S. Government. Changes in availability and accuracy of the system
can adversely affect the operation of the GeoChaser. 12Trace cannot take any
responsibility for the reliability, availability and accuracy of the GPS system, as a result of
third parties. In the disclaimer of 12Trace you will find more information.
Tall buildings and metal structures can affect the determination of the position by
GeoChaser.

2. Interface Definitions:

There are 8 wires in the cable of the GeoChaser including the connection for the contact input, digital
input, analog input etc.
8) +12/24 Volt
7) GND
6) I-Button (red wire)
5) I-Button (white wire)
4) Release immobilizer,
green led
3) I-Button , red led
2) Ignition
1) unused

3. GeoChaser activation

To activate the GeoChaser he needs to be
registered.
English V1.0
Page 1 of 8
laatste wijziging: 07-8-2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GeoChaser Control and is the answer not in the manual?

Questions and answers

Related Manuals for 12trace GeoChaser Control

Summary of Contents for 12trace GeoChaser Control

  • Page 1 User Manual GeoChaser Control 1.Introductie The GeoChaser Control is a powerful GPS tracking system designed for tracking of vehicles and reading out driver identification. The device has superior reception sensitivity, fast positioning and supports four-band GSM frequencies 850/900/1800/1900, the location can be viewed real-time on your personal 12Trace page or in the mobile App.
  • Page 2 3.1 New user New users must first create an account on www.12trace.nl. Go to the site, click on the ' login ' button and then click ' create account '. You will be prompted to fill in some data. You need the product key. The product key can be found at the bottom of the GeoChaser. To activate your account you will receive an e-mail message from support@12trace.nl on your...
  • Page 3 5. Installation of the GeoChaser For optimal operation of your GPS tracking system, it is important that the GeoChaser not be completely enclosed by metal or metal-containing glass. This will may seriously disturb the functioning of the system. In General, plastic and normal glass has no negative for receiving a GPS signal.
  • Page 4 6.2 Analog input The green wire is the analog input. This can be a DC voltage from 0 to 30V. The overview shows the connections. 6.3 Digitale output The brown wire is the digital output. For example you can use this entry for a siren or horn to send control with a maximum flow of 750mA.
  • Page 5 6.4 Relay output The GeoChaser has a built-in potential-free relay contact between the 2 yellow wires. This is a normally open contact relay with a maximum switching voltage of 16VDC and a maximum continuous current of 5A. 7. Set up the GeoChaser After signing in to the website account you will get an overview of your GeoLockers and GeoChasers in your account.
  • Page 6 This means that the setting has not yet been sent to the GeoChaser. The next time this will happen if the GeoChaser connect to the 12Trace website (for example, at a location update). Using the [current location retrieval] changed settings will be immediately active.
  • Page 7 button at the top of "Save data". The stored data can be exported to Excel (csv) for processing or as an attachment to your tax return. Click the button "Enter correction " you can adjust the mileage to the counter in your vehicle. Page 7 of 8 English V1.0 laatste wijziging: 07-8-2018...
  • Page 8 12Trace is gebonden aan de Wet Bescherming Persoonsgegevens. Zij onderschrijft de Gedragscode Verwerking Persoonsgegevens. Bij de verwerking van uw persoonsgegevens gaat 12Trace zorgvuldig te werk. 12Trace gebruikt alleen die gegevens die nodig zijn voor een optimale dienstverlening. Voor zover dat niet voortvloeit uit de wet of uit v erplichtingen die 12Trace jegens u is aangegaan, worden zonder uw toestemming geen persoonsgegevens aan derden verstrekt.
