Noland Engineering RS11 v3.0 Manual page 9

Oil Pressure
Oil Temperature
Engine (Coolant) Temperature
Alternator volts
Fuel Rate
Engine Hours
Coolant Pressure
Fuel Pressure
Status1
Status2
%Load
%Torque
any of the items above in bold can be assigned to any available Analog Input (A1-A4) of the RS11. For example, if the RS11 is
monitoring a single engine and all 4 analog inputs are available, they could be assigned to the top 4 items in the above list. If,
however, two engines are being supported with one RS11, you would have to divide up the available Analog Inputs (A1-A4)
between your two engines.
Transmission Parameters: This single packet message is sent once/second for each engine. It contains Gear Oil Pressure and
Temperature. Separate messages are sent for Port and Starboard engines.
Fluid Level / Capacity: This single packet message is sent once/second for each engine. It is used for "Fuel Level" but "Fuel
Capacity" can also be included if desired. Separate messages are sent for Port and Starboard engines.
