- Page 1 3DLevelScanner OPERATING INSTRUCTIONS Level / Volume measurement in solid applications with mapping capabilities Changing the market from level to volume...
-
Page 2: Table Of Contents
Table of contents ABOUT THIS DOCUMENT ......................... 4 ..........................4 YMBOLISM USED ..........................4 OR YOUR SAFETY Authorized personnel ........................4 1.2.1 Appropriate use .......................... 4 1.2.2 Warning about misuse ........................ 4 1.2.3 1.2.4 General safety instructions ......................4 CE conformity..........................5 1.2.5 1.2.6 Safety information for Ex areas .................... - Page 3 DIMENSIONS ..........................33 APPENDIX ............................35 12.1 ........................... 35 ECHNICAL DATA 12.2 ........................36 MBIENT CONDITIONS 12.3 ........................36 ROCESS CONDITIONS 12.4 ......................... 36 ROCESS TEMPERATURE 12.5 ......................36 LECTROMECHANICAL DATA 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved...
- Page 4 Figure 8: Software Tool connection ......................... 17 Figure 9: Empty and Full Calibration......................22 Figure 11: 3DLevelScanner M with horn antenna in threaded version ............33 Figure 12: 3DLevelScanner M with horn antenna in flange version..............33 Figure 13: 3DLevelScanner M housing......................34 Figure 14: Voltage diagram ..........................
-
Page 5: About This Document
Inappropriate or incorrect use of the device can give rise to application-specific hazards, e.g., vessel overfill or damage to system components through incorrect mounting or adjustment. If the 3DLevelScanner is used in a manner not specified in this manual, the protection provided by the 3DLevelScanner will be impaired. 1.2.4... -
Page 6: Ce Conformity
For your safety considered during installation and all common safety regulations and accident prevention rules. 1.2.5 CE conformity The 3DLevelScanner conforms to CE's EMC and NSR standards. CE conformity is as follows: EMC (2004/108/EC) - Emission EN 61326: 1997 (class B) -
Page 7: Product Description
The 3DLevelScanner employs an array of three antennas to transmit low frequency pulses and to receive echoes of the pulses from the contents of the silo, bin, or other container. -
Page 8: Advantages
Product description Advantages Advantages Practice-oriented device versions - The 3DLevelScanner S is available with both thread and flange fittings. Service and maintenance-friendly - Thanks to the non-contact measuring principles, the 3DLevelScanner S is particularly easy to service and maintain. The only volume measurement device for solid applications... -
Page 9: Mounting
Mounting Installation position Mounting Installation position Install the 3DLevelScanner M where you can easily reach it for mounting and connecting. You can install the housing in eight different positions. In each position, the housing can be rotated 45°. Moisture Use the recommended cable (see Connections, page 13) and tighten the cable connection. -
Page 10: Installation Location
Installation Location Installation Location When mounting the 3DLevelScanner M, a distance of at least 400 mm from the vessel wall (500mm from the center of the scanner to the vessel wall) should be maintained. If the 3DLevelScanner M is installed in the center of the vessel, multiple echoes can occur. -
Page 11: Mounting Direction
Mounting Mounting Direction Mounting Direction The 3DLevelScanner must be mounted in the right direction in order to scale and adjust the position of the unit. The mounting direction is indicated by a sticker labeled 0 on the instrument (see image below). The 0 must point to the center of the vessel (including square vessels and open bins). -
Page 12: Socket
Socket pieces should be positioned so that the antenna end protrudes at least 10 mm (0.4 inch) out of the socket. Important Note : Rails/frames should never interfere with the 70 beam angle transmitted and received (see figures below). Figure 4: Recommended socket mounting 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 13: Sensor Orientation
Inflowing Material Do not mount the devices in or above the filling stream. The optimal position is as far away from the inflowing material. Figure 5: Inflowing material 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 14: Connections
Connections General Requirements Connections Note on safety Always observe the following safety instructions: Connect only in the complete absence of line voltage If overvoltages are expected, overvoltage arresters should be installed. A safety certified power supply which provides double insulation between the primary and output must be used for powering the unit. -
Page 15: Wiring Plans
For more information about the connections, refer to “Different ways of connecting to 3DLevelScanner” document for additional help in connecting to the 3DLevelScnner using various interfaces (HART / RS485 / GSM / GPRS / Ethernet / Modbus). 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 16: Adjustment
Adjustment 3DlevelScanner M - LCD Panel Adjustment The 3DLevelScanner M can be set up and operated using one of the following: An adjustment software tool (3DLevel Manager) GSM / GPRS communication using 3DLink Pro 3DlevelScanner M - LCD Panel Figure 7: 3DLevelScanner M front panel LCD... - Page 17 When all three buttons are pressed the message “Hardware locked” is displayed. When all three buttons are pressed again, the message “unlock parameter.” Appears. Enter the unlock parameter (100) and confirm by pressing E. 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved...
-
Page 18: Adjusting The Scanner Using The Software Tool
"APM 3DLevel Manager Software Operating Instructions" manual. 2. The example above is an RS485 connection. There are more possibilities to connect to the 3DLevelScanner M using a different interface or protocol – for more help refer to "Different ways of connecting to 3DLevelScanner" manual. -
Page 19: Operation
A three digit identifier is displayed on the right-hand side of the function on the display. The first two digits identify the function group. The third digit indicates the individual function within the function group. 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 20: Switching On
Switching on Switching on After 3DLevelScanner M is connected to the power supply, it carries out a self-test for approx. 30 seconds. After the initialization is complete, the following is displayed, allowing you to select a language and distance units. -
Page 21: Basic/Default Screen
6.5.2 Parameter adjustment Because the 3DLevelScanner M is primarily a distance measuring device, the distance from the sensor to the product surface is measured. In order to have the actual product level displayed, an allocation of the measured distance to the height percentage must be carried out. -
Page 22: Medium Selection
[E] key. 6.5.5 Performing empty calibration adjustment Move from the measured value display to the main menu by pressing [E]. group selection ->basic setup safety settings linearization 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 23: Figure 9: Empty And Full Calibration
Enter the appropriate distance value in DU (corresponding to the percentage value) for the empty vessel (e.g., distance from the sensor to the vessel bottom). Save the settings by pressing [E] and move on to "Full Calibr". 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 24: Performing Full Calibration Adjustment
BD is compromised, it may cause device malfunction. After basic calibration, enter a safety distance (SD) in the safety distance (015) function. If the level is within this SD, the 3DLevelScanner M signals a warning or an alarm, depending on your selection in the 'in safety distance' (016) function. -
Page 25: False Echo Storage
Manager software. It is preferable and more comfortable to make all the configurations in the 3DLevel Manager after mounting and connecting the unit. For more information of how to connect to the 3DLevelScanner refer to the "Different ways of connecting to 3DLevelScanner" manual. -
Page 26: Basic/Default Displayed Screen
Basic/default displayed screen Basic/default displayed screen Linearization screen Main Menu Main Menu Lineariz. Mode 041 Custom Operation 040 Clear the table? 007 Conformation Linear Activate Table Table is cleared Custom Edit Table Clear Table Set point num. 043 Set Level 044 Set Volume 045 Next Point 040 Point num. -
Page 27: Extended Calibration Screen
Extended calibration screen Extended calibration screen Output screen 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 28: Display Screen
Display screen Display screen 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 29: Measured Parameters
Measured Parameters Measured Parameters 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 30: Device Info
Device Info Device Info Device Reset 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 31: Maintenance And Fault Rectification
9.2.1 24 hours support If you fail to solve the problem with the methods suggested here, please contact APM Customer Support. The service is available 7 days a week around the clock. Since we offer this service world-wide, the support is only available in the English language. -
Page 32: Replacing The Electronics
If there is no electronics module available on site, it can be ordered from your local APM agency. Device repair If it is necessary to repair the 3DLevelScanner please proceed as follows: Download a return form from our Web site www.apm-solutions.com, under "Services – RMA Request Form". -
Page 33: Dismounting
Dismounting Dismounting procedure Dismounting Dismounting procedure 10.1 Warning! Before dismounting, be aware of dangerous process conditions such as pressure in the vessel, high temperature, corrosive or toxic products etc. Take note of the chapters Mounting, page 8, and Connections, page 13 and carry out the listed steps in reverse order. -
Page 34: Dimensions
Dimensions Dismounting procedure Dimensions Figure 10: 3DLevelScanner M with horn antenna in threaded version Figure 11: 3DLevelScanner M with horn antenna in flange version Dimensions are in mm (inch). -
Page 35: Figure 13: 3Dlevelscanner M Housing
Dimensions Dismounting procedure Figure 12: 3DLevelScanner M housing Dimensions are in mm (inch). 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 36: Appendix
Current limitation 22mA Load 4-wire sensor See load diagram Integration time 0…9999 s, adjustable Figure 13: Voltage diagram HART Load Voltage Limit EEx ia device Voltage limit non-Ex/Exd ia device Supply Voltage 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 37: Ambient Conditions
ATEX II ½D, 2D, Ex ibD/iaD 20/21 T110 ATEX II 2G Ex ia/ib IIB T4 FM Intrinsic safety CL I,II, DIV I, GP CDEFG CSA Intrinsic safety (pending) IECEx IEC EEx ia IIC T6 (pending) 3DLevelScanner Operating Instruction. © 2009 APM all rights reserved... -
Page 38: Figure 15: Accuracy
15 of the FCC regulations FCC 47 CFR part 15:2007, subpart B, class A The 3DLevelScanner complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 39 © 2009 APM Automation Solutions Ltd. All rights reserved. Information in this info@apm-solutions.com document is subject to change without notice. APM Automation Solutions Ltd. and the APM Logo, are trademarks, and the 3DLevelScanner is a registered www.apm-solutions.com trademark of APM Automation Solutions Ltd.
