SPARE PARTS LIST

MOTOR SET,550
WEIGHT/A,WT416G
WEIGHT/B(2),WT740G
ORING(2),Ø124MM
ORING(2),Ø120MM
PJ6179 WIRE CONNECT CABLE
PJ6183 WEIGHT(4),WT120G
PJ6399 PROPULSION MOTOR
PJ6400 PROP. MOTOR MOUNT
PJ6401 SERVO&H.W MOUNT
PJ6402 ROUND FRAME SET
PJ6403 SEMI-ROUND FRAME SET
PJ6404 OUTER RING FRAME
PJ6405 FR COVER PLATE
PJ6406 FR MARINE CANOPY
PJ6407 FR CABIN
PJ6408 OUTER HULL(L)
PJ6409 OUTER HULL(R)
TOP CABIN FRAME
PJ6410
RR RUDDER BRACKET
PJ6411
PJ6412 TAIL FIN SET
PJ6413 RR CONE FRAME
PJ6414 FR ELEVATOR BRACKET
PJ6415 FR ELEVATOR SET
PJ6416 RR ELEVATOR SET
PJ6417 5 BLADE PROP.,D62x40
PJ6418 FUSE HOLDER
PJ6419 CAMERA BRACKET
PJ6420 BATT. CONNECT WIRE
WEIGHT/C(2),WT540G
PJ6421
BT P. MACH SCREW,M3X8S(20)
PD0877-S
BT P. MACH SCREW,M3X10S(20)
PD0878-S
BT P. MACH SCREW,M3X12S(20)
PD0879-S
PD0884-S F.T P. MACH SCREW,M3X8S(20)
PD0889-S BT P. TAP SCREW,M3X10S(20)
PD0961 SET SCREW,M3X3B(20)
PD0975 O-RING,Ø3(20)
PD0982 NYLON STRAP,2.5(SMALL,20)
PD1712-S BT P. TAP SCREW,M2.6X8S(20)
PD7478 O-RING,Ø6(20)
PD7795-S BT P. MACH. SCREW,M3X16S(20)
PD7801 F.T P. MACH. SCREW,M4X60S(4)
PD7802
F.T P. MACH. SCREW,M6X38S(12)
PD7803
PDS.K MACH. SCREW,M3X4S(20)
PD7804
PDS.K MACH. SCREW,M3X6S(20)
PD7805
PDS.K MACH. SCREW,M3X8S(20)
PD7806
PDS.K MACH. SCREW,M3X5S(20)
PD7807
SET SCREW,M3X3S(20)
PD7808
SET SCREW,M3X4S(20)
PD7809-S BT P. TAP SCREW,M2X8S(20)
PD7810-S BT P. TAP SCREW,M2X10S(20)
PD7811-S
BT P. TAP SCREW,M3X12S(20)
PD7812-S BT P. TAP SCREW,M3X16S(20)
PD7813 NUT,M4(20)
PD7814 NUT,M6(20)
PD7815 NUT,M10(20)
PD7816-S LOCK NUT,M3S(20)
PD7817 WASHER,Ø3S(20)
PD7818 WASHER,Ø6S(20)
O-RING,Ø4(20)
PD7819
PD7820 O-RING,Ø9.5(20)
PD7821 O-RING,Ø15(20)
PD7823 SPRING WASHER,Ø4S(20)
PD7824 SPRING WASHER,Ø6S(20)
PD7825 SPRING WASHER,Ø10S(20)
PD7830 WASHER,Ø4S(20)
2540S CHARGER,6S
LIFE BATTERY,5000mAH
2853
8091 ESC,BLC -25M
8175 STD SERVO/DS1903
8603S SEA WOLF COMMANDER
