MX92
USER/INSTALLER MANUAL
Correct disposal of this product
(Electrical and electronic equip-
ment waste).
1
Week days
2
Current date
2
3
Current hour
4
4
Signal transmission
5
Programming modes
6
6
Channel
7
Up
8
Confirm/Stop
8
9
Down
10
Return
10
11
Advance
12
Time
13
Select
14
Battery
DESCRIPTION:
man • manual
Su • Sunday
auto • automatic
Mo • Monday
• random
Tu • Tuesday
We • Wednesday
Th • Thursday
Fr • Friday
Sa • Saturday
EN
1
3
5
7
9
11
12
13
14
• Power Supply
• Working temperature
• Transmission frequency
•Range
• Number of channels
• Code type
• Dimensions
V2.0
REV. 06/2017

PRE-PROGRAMMING

• When a battery is placed on the transmitter, this turns on all the characters on the display for
2 seconds. After this time stay in normal working.
• If more than 10 seconds passes without pressing any key, the remote control automatically
exits programming and returns to standby mode, without record any change.
• Factory values:
• the display shows initially: wednesday, 2014-01-01, 00:00h.
• manual mode active.
• Group 1 has the channels 1, 3, 5 and 7 memorized.
• Group 2 has the channels 2, 4, 6 and 8 memorized.

TRANSMISSION SIGNAL

Each time you press
, the display will show
sending. The signal goes off when you stop pressing the button.

Technical characteristics

3V(CR2430)
-20 to 55°C
433MHz
40m
8 channels and 3 groups
Rolling Code
45x130x12mm
in dynamic mode, indicating the signal
